SPORT-USB
| MANUAL
Injection moulded polyurethane grips
Construction made of metal and carbon fiber
4.3-inch IPS LCD with 480x272 pixels and 60 FPS
18 RGB LEDs with adjustable brightness and color
Up to 15 different LCD dashboards
Optional non-contact clutch and optional paddles
70mm quick release holes and bolt holes
Advertisement
Table of Contents
Related Manuals for LEOXZ XF1 SPORT-USB
Summary of Contents for LEOXZ XF1 SPORT-USB
- Page 1 SPORT-USB | MANUAL Injection moulded polyurethane grips Construction made of metal and carbon fiber 4.3-inch IPS LCD with 480x272 pixels and 60 FPS 18 RGB LEDs with adjustable brightness and color Up to 15 different LCD dashboards Optional non-contact clutch and optional paddles 70mm quick release holes and bolt holes...
- Page 2 This racing wheel is designed for simulation use only. • Leoxz is responsible for revising and explaining this manual, and reserves the right to make changes or corrections to the information and explanation provided without prior notice and without any responsibility.
-
Page 3: What's Included
What's included • XF1 Sport-USB Steering Wheel • USB-XS9 Cable • Custom Stickers • M3 Allen Key • Nylon Tweezers Note: The M3 allen key can only be used to adjust the paddle and remove the front knob for easy sticking of stickers. -
Page 4: Usb Connection
USB Connection XF1 Sport-USB can only be connected via USB cable and requires a minimum input power of 5V 0.8A to ensure proper operation. Otherwise, unexpected errors may occur. The USB-XS9 cable will ensure a stable and reliable connection. Note: Make sure that the USB-XS9 cable is aligned... - Page 5 QR Installation The XF1 Sport-USB has 12 mounting holes with a diameter of 70mm for quick release installation, including 6 through holes and 6 threaded holes. It supports a maximum diameter of 88mm for the quick release. Through Holes Threaded Holes （6XΦ5)
- Page 6 Install QR From Outside Note: Using any QR must and can only be powered and signaled to the XF1 Pro via the USB-XS9 cable.
-
Page 7: Menu Setting
Menu Setting As shown in the figure, the XF1 Sport can quickly switch the screen dashboard through the “Change” button. It has over 15 built-in dashboard styles and more types will be added with firmware updates. The “Setting” button allows you to switch between different setting menus, which include options for adjusting screen brightness, LED bar brightness, clutch bite... -
Page 8: Paddle Adjustment
Paddle Adjustment All paddles can be adjusted to meet the size requirements of different people. By adjusting the two screws of the paddles, move the paddles outward or inward, and then tightened securely with the screws. Note: The operating torque of the bolts should not exceed 3Nm. - Page 9 SimBridge Plugin For Simhub XF1 Sport-USB will be compatible with simhub through simbridge and enabling LEDs customization. To use it, you need to place SimBridge in the Simhub installation directory and restart Simhub for it to take effect. Note: You can download the latest version on the website www.leoxz.com.
- Page 10 LEDs customization XF1 Sport-USB is a plug-and-play device, so you can connect it to SimHub without having to complicatedly install any drivers. The XF1 Sport-USB has up to 18 customizable RGB LEDs with adjustable colors and brightness. You can achieve various lighting effects by creating different profiles.
-
Page 11: Firmware Update
XF1 Sport-USB and update the latest firmware. Once the update is completed, XF1 Sport-USB will automatically restart. Note: You can download the latest firmware on the website www.leoxz.com. Do not operate the steering wheel during the update process, as it may cause unexpected errors. -
Page 12: Hardware Reset
Hardware Reset If the firmware update fails and the steering wheel cannot start normally, please try hardware reset to force the steering wheel to enter Bootload mode and update the firmware again. 1. Disconnect the power to the steering wheel to keep the steering wheel in a power-off state. - Page 13 Copyright © 2023 Leoxz® All Rights Reserved...
