LEOXZ XGT ULTIMATE I Manual

Hide thumbs

Advertisement

Table of Contents

XGT ULTIMATE | MANUAL
Injection moulded polyurethane replaceable grips
Aluminum alloy rear enclosure and carbon fiber panel
Supports wireless SimHub dashboards
4.3 inches IPS LCD with 800x480 pixels and 60 fps
Scratch resistant Gorilla Glass, up to 2mm thick.
3+15+3 RGB LED rpm bar and buttons
Optional non-contact hall clutch and optional paddles
Clutch with adjustable bite point
Up to 51 buttons and 2 axes
70mm quick release holes and bolt holes
GX12 threaded USB port

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XGT ULTIMATE I and is the answer not in the manual?

Questions and answers

Related Manuals for LEOXZ XGT ULTIMATE I

Summary of Contents for LEOXZ XGT ULTIMATE I

  • Page 1 XGT ULTIMATE | MANUAL Injection moulded polyurethane replaceable grips Aluminum alloy rear enclosure and carbon fiber panel Supports wireless SimHub dashboards 4.3 inches IPS LCD with 800x480 pixels and 60 fps Scratch resistant Gorilla Glass, up to 2mm thick. 3+15+3 RGB LED rpm bar and buttons Optional non-contact hall clutch and optional paddles Clutch with adjustable bite point Up to 51 buttons and 2 axes...
  • Page 2 This racing wheel is designed for simulation use only. • Leoxz is responsible for revising and explaining this manual, and reserves the right to make changes or corrections to the information and explanation provided without prior notice and without any responsibility.

  • Page 3: What's Included

    What's included • XGT Ultimate Steering Wheel • USB-GX12 Cable Custom Stickers • • Nylon Tweezers...
  • Page 4 Interface 21 RGB LED Bar compatible with Simhub 19 RGB LED Buttons compatible with Simhub 800x480 IPS LCD compatible with Simhub 14 Momentary button 2 Thumb rotary encoder 5 Front rotary encoder with push button 2 Multi-directional joystick with integrated encoder 2 non-contact hall shifter paddle 2 Optional non-contact hall clutch paddle 2 Optional non-contact hall option paddle...

  • Page 5: Quick Controls

    Quick Controls Long-pressing the option encoder allows you to access the quick control menu, enabling you to switch the steering wheel between different modes(USB mode, Wireless mode and Fanatec mode). After entering the quick control menu, you can use the left and right buttons on the right multi-directional joystick to select different menus.
  • Page 6 Wheel Mode-USB XGT Ultimate can only be connected via USB cable and requires a minimum input power of 5V 1.0A to ensure proper operation. Otherwise, unexpected errors may occur. The USB-GX12 cable will ensure a stable and reliable connection. Make sure that the USB-GX12 cable is aligned with the raised mark of the GX12 interface, otherwise it will cause permanent damage to the socket if it is inserted forcibly.
  • Page 7 Wheel Mode-Wireless To enter this mode, the steering wheel must have the Wireless Kit installed, and the XGTU Dongle should be plugged into the PC's USB port. Long-press the XGTU Dongle button to enter pairing mode, simultaneously switching the quick control menu to the <Mode>...
  • Page 8 Wheel Mode-Fanatec In this mode, the steering wheel does not require a USB connection, it can communicate directly with the Fanatec base. You can use the steering wheel to access the Fanatec Tuning Menu and configure settings on the Fanatec base. Fanatec Mode Button Mapping Due to the limited number of Fanatec buttons, only a subset of buttons on the steering wheel is functional.
  • Page 9 XGT Ultimate will be compatible with simhub through simbridge, enabling dashboard and LEDs customization. To use it, you need to place SimBridge in the Simhub installation directory and restart Simhub for it to take effect. • Download the latest version on the website www.leoxz.com.
  • Page 10 Simhub Compatibility XGT Ultimate is a plug-and-play device, so you can connect it to SimHub without having to complicatedly install any drivers. You can display various dashboards on screen and change brightness through SimHub, and you can also achieve various lighting effects by creating different profiles.
  • Page 11 Paddles Functionality The optional clutch paddles can be configured for axis mode and bite point mode. All paddles have self-calibrate functionality to ensure high accuracy. This function requires that the paddles be pressed once (from minimum position to maximum position) each time the steering wheel is started. Enter the menu on the steering wheel and select"Clutch Mode", then set it to "Bite Point".
  • Page 12 SimHub Controls By binding any controller or keyboard input, you can quickly control the XGT Ultimate dashboards switching, screen and LEDs brightness, clutch paddles and bite point value.

  • Page 13: Firmware Update

    XGT Ultimate and update the latest firmware. Once the update is completed, XGT Ultimate will automatically restart. • You can download the latest firmware on the website www.leoxz.com. Do not operate the steering wheel during the update process, as it may cause unexpected errors.

  • Page 14: Hardware Reset

    Hardware Reset If the firmware update fails and the steering wheel cannot start normally, please try hardware reset to force the steering wheel to enter Bootload mode and update the firmware again. Disconnect the power to the steering wheel to keep the steering wheel in a power-off state. Press the Reset button.
  • Page 15 Copyright © 2023 Leoxz® All Rights Reserved...
