Brixton
Bookcase
Thank you for purchasing a Mocka
Brixton Bookcase
manufacturer's assembly instructions in detail to ensure the safety
s
features of the
Bookcase i
not compromised.
A
A
B
B
dowel
bolt & nut
x32
×40
F
G
handle
screw 18mm
x3
x3
K
L
bracket
screw 14mm
x12
x36
P
Q
wall strap
screw
x12
x2
WARNING:
This furniture item can become unstable and may topple if climbed upon
and can be especially dangerous to children. Serious injury or death may result.
It is undesirable to place objects of interest to children in view on this type of
furniture item, as children may be tempted to climb to retrieve the objects the result
being that the furniture item may tip and cause injury or death.
This furniture item meets the requirements of AS/NZS 4935. However, even furniture
items that meet these requirements can tip under certain circumstances, especially when
placed on carpet, uneven or sloping flooring, or when subject to extreme use.
Attachment of the furniture item to an appropriate structural component of the building
using suitable means, as advised by a qualified tradesperson, is strongly recommended even
for those furniture items meeting the suitability requirements of AS/NZS 4935.
mocka.co.nz I mocka.com.au
. Please follow the
C
C
D
D
screw 12mm
screw 30mm
x8
x8
H
I
screw 50mm
screw 25mm
x2
x8
M
N
feet
screw
x5
x4
R
part
x3
E
E
E2
E1
slide rail
x4
J
screw 18mm
x12
O
wall plug
x2
Phillips & Flathead screwdrivers required.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Mocka Brixton Bookcase
Summary of Contents for Mocka Brixton Bookcase
- Page 1 Brixton Bookcase Thank you for purchasing a Mocka Brixton Bookcase . Please follow the manufacturer’s assembly instructions in detail to ensure the safety features of the Bookcase i not compromised. dowel screw 12mm slide rail screw 30mm bolt & nut ×40...
- Page 2 Brixton Bookcase A ttach frames (19) to main frames (18) with 8 × Insert 4 × feet (M) into main frames (18) as shown. screws (C). mocka.co.nz I mocka.com.au...
- Page 3 Brixton Bookcase Separate parts (E1) and (E2) as shown. Attach panel (2) to main frames (18) with 8 × screws (D). mocka.co.nz I mocka.com.au...
- Page 4 Bookcase Attach 2 × slide rails (E1) to the front and back sides Attach 2 × slide rails (E1) to panels (3) and (4) with 4 × screws (K). of panel (5) with 4 × screws (K). mocka.co.nz I mocka.com.au...
- Page 5 Attach panel (7) to panels (3) and (5) with 4 × nuts (A), 4 × bolts (A) and 4 × dowels (B). to panels (6) with 16 × nuts (A), 16 × bolts (A) and 16 × dowels (B). mocka.co.nz I mocka.com.au...
- Page 6 Brixton Bookcase Attach panel (2) to panels (3), (4) and (5) with 6 × nuts (A), 6 Slide panels (8) and (16) into position as shown. × bolts (A) and 6 × dowels (B). mocka.co.nz I mocka.com.au...
- Page 7 Brixton Bookcase Insert parts (F) and (G) into panels (9) and (10) Attach panel (1) to panels (3), (4) and (5) with 6 × nuts (A), as shown. 6 × bolts (A) and 6 × dowels (B). mocka.co.nz I mocka.com.au...
- Page 8 Attach parts (E2) to panels (13) and (14) with 4 × screws (K). (H). ②Slide panel (11) into position as shown. ③Attach panels (9) and (10) to panels (13) and (14) with 4 × nuts (A) and 4 × bolts (A) . mocka.co.nz I mocka.com.au...
- Page 9 Brixton Bookcase Insert 12 × screws (Q) into the cabinet, then Insert drawers into the cabinet as shown. attach panels (17) into the cabinet as shown. mocka.co.nz I mocka.com.au...
- Page 10 Brixton Bookcase 3 15 Insert parts (F) and (G) into panel (15). Attach parts (R) to panels (15) and (3) with 6 × screws (K) as shown. mocka.co.nz I mocka.com.au...
- Page 11 2 × safety strap (N). Fasten to the wall using 2 × wall anchors (M), 2 × screws (L) and 2 × screws K). Ensure unit is balanced and steady before use. mocka.co.nz I mocka.com.au...
- Page 12 Brixton Bookcase You`re done, enjoy! mocka.co.nz I mocka.com.au...
