Edsal UR-364 Quick Start Manual

These units should be placed on a level surface. Failure to do so can result in poor product performance or create a possible
safety hazard. This unit should be securely anchored to a wall or floor with suitable fasteners, which are not included. Do not
use this unit for anything other than the manufactures intended purpose. DO NOT STAND ON ANY PART OF THE UNIT, OR
USE IT AS A LADDER. Do not store aquariums on this unit. Evenly distribute the weight on each level and always keep the
heavier loads on the bottom. Use care when working with metal parts, wear gloves for protection.
Assembly is done with the rivets of the beams and braces fitting into the slots of the post. A rubber mallet may be used on the
beams and braces to seat the rivets properly. A hammer can also be used, providing one uses a cloth or a block of wood be-
tween the hammer head and the parts to prevent damage. Tap gently and be sure the rivets are straight and fully engaged.
Should you have any comments, damage, missing parts, or problems with assembly of this unit contact us:
Chat: www.edsal.com/chat or www.edsal.com/contact
Email: support@edsal.com
Phone: 773-475-3131
To obtain replacement parts please provide: Model Number, Part Number & Description, Location Purchased, and Date Purchased
Steel Storage Rack
B - Brace
D - Wood Shelf
4 Shelf
Description
A beam
B brace
C post
D shelf
E coupler
A - Beam
UR-364
60"h x 18"d x 36"w
Qty Part Number
8 UBE3502GY
8 UBE1702GY
8 UPT3002GY
4 RPB21836
4 MPCIN-GY
MODEL NUMBERS
UR-364
UR364-BLK
UR364P-BLK
E - Inside Coupler
UR364-BLK; UR364P-BLK
4 Shelf 60"h x 18"d x 36"w
Description Qty
A beam 8
B brace 8
C post 8
D shelf 4
E coupler 4
Edsal Manufacturing Co. LLC
1555 W. 44th Street
Chicago, IL 60609
www.edsal.com
US Patents & Patents Pending
C - Post
Part Number
UBE3502BK
UBE1702BK
UPT3002BK
RPB21836
MPCIN-BK
