Note:
Lifting the machine in an awkward position or
transporting it in a poorly balanced position could
result in personal injury. When transporting the
machine, assign an adequate number of persons
to the job and ensure that each person can take a
good position of not being excessively loaded.
(mass: approx. 18 kg (39-3/4 lb))
I. Accessory parts
No.
Name
1. Fixing Leg
2. Fixing Leg
Cover
3. Fixing Bracket
4. Shoulder
Screw
5. Screw
(4 × 8 mm)
6. Installation
Manual
DK-501
INSTALLATION MANUAL
Shape
Q'ty
4
4348U020AB
4
4348U099AB
4
4658U021AA
4
4658U022AA
12
9646040813
1 set
4980IXC019DA
Desk
After unpacking, be sure to get rid of the
packaging materials and keep them out of
the reach of children.
Putting the head in the plastic bag
involves danger of suffocation.
Note:
When removing the Desk from its shipping carton,
do not hold onto the reinforcement bracket (as a
personal injury or a deformed frame could result).
Reinforcement Bracket
E-1
Applied Machines: 500/420
MFP 50 ppm/42 ppm
4061IXC111DA
4348-9550-00
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Develop Ineo DK-501
Summary of Contents for Develop Ineo DK-501
- Page 1 DK-501 Desk INSTALLATION MANUAL Applied Machines: 500/420 MFP 50 ppm/42 ppm Note: Lifting the machine in an awkward position or transporting it in a poorly balanced position could result in personal injury. When transporting the After unpacking, be sure to get rid of the machine, assign an adequate number of persons packaging materials and keep them out of to the job and ensure that each person can take a...
- Page 2 II. Installation procedures 6. Install the Drawer Cover furnished with the machine (two screws furnished with the machine: 1. Turn off the machine’s sub and main power B-tight screw M3×8). switches. 2. Remove the cord clamp and unplug the power cord from the machine (one screw.) 4061IXC113DB 7.
- Page 3 10. Using the Fixing Brackets and Shoulder Screws 15. Move the machine and Desk to the installation furnished with the Desk, secure the machine to site. Then, adjust two adjusters at the front to let the Desk (at two places in the rear). the Desk sit on the floor.
- Page 4 17. Install the Fixing Leg Covers at two locations in 19. Install the Fixing Leg Covers at two locations in the front shown in the illustration (two Pieces). the rear shown in the illustration (two Pieces). Note: Note: • Insert the Fixing Leg Covers in the direction •...
