Summary of Contents for oticon miniRITE R

  • Page 1 Instructions for use SmartCharger miniRITE R miniBTE R Oticon Real™ Oticon More™ Oticon Zircon Oticon Play PX Oticon CROS PX...
  • Page 2 Introduction to this booklet This booklet guides you on how to use and maintain your new charger. Ensure you read this booklet carefully, including the Warnings section. This will help you get the most benefit from your charger. If you have additional questions about the use of your charger, contact your hearing care professional.
  • Page 3 Intended use Intended use The charger is intended to recharge the hearing aids and CROS transmitter that contain rechargeable batteries. The product is intended to be used together with the given hearing solution. Indications for There are no indications for use (diagnoses) for the charger itself.
  • Page 4: Table Of Contents

    Table of contents About Package contents Charger Temperature conditions Getting started Prepare charger Charge the hearing aids Daily use Charging time Charging the charger Power bank function Power and charge using other sources Drying your hearing aids Caring for your charger...
  • Page 5 Warnings General warnings More info Troubleshooting Conditions of use Australia only Warranty...
  • Page 6: Package Contents

    Package contents The packaging box contains the following elements: Power plug (varies from country to country) Charger Instructions for use SmartCharger miniRITE R miniBTE R Oticon Real™ Oticon More™ Oticon Zircon Oticon Play PX Oticon CROS PX Cable This booklet...
  • Page 8: Charger

    Charger What it is and does USB cable Power plug Insert in power plug For power point Battery indicator Displays charging status Charging ports of the power bank/power bank battery levels For hearing aids when charging About Getting started Daily use Warnings More info...
  • Page 9: Temperature Conditions

    Temperature conditions Temperature Charging condition Below +5°C No charging due to low temperature. (+41°F) +10°C to +35°C Best charging condition. The charging of hearing aids can (+50°F to +95°F) take up to 3.5 hours. +5°C to +10°C and Extended charging. The charging of hearing aids can take up +35°C to +38°C to 5 hours.
  • Page 10: Prepare Charger

    Prepare charger Connect to power source Step 1 Step 2 Step 3 Insert the USB plug Insert the other end of Insert the power plug into the power plug. the USB cable into the into a power point. back of the charger. The charger turns ON automatically and begins charging the...
  • Page 11 Charger is turned ON When the charger is connected to power, the charger’s power bank charging status is shown. First use - Charge the power bank’s battery When you use your charger for the first time, it is important that you fully charge the charger’s built-in battery.
  • Page 12: Charge The Hearing Aids

    Charge the hearing aids Place hearing aids in charger Charging status Place the hearing aids in the The hearing aid LED lights turn ON charging ports as shown in the when the hearing aids are correctly picture and close the lid. Make placed in the charger.
  • Page 14: Charging Time

    Ensure you fully charge your hearing aids before first use and charge them every night. That ensures that you start your day with fully charged hearing aids. If your hearing aid’s battery is completely drained, the normal charging time is: miniRITE R Fully charged 50% charged 25% charged 3 hours 1 hour 0.5 hours...
  • Page 15 The charger’s lid serves as protection and storage for your hearing aids. During charging, when you open the lid, the LEDs in your hearing aids light up to indicate their charging status. Note If you have not used your hearing aid in a long time and you then try to recharge it, it may take up to 30 seconds before the hearing aid begins charging.
  • Page 16: Charging The Charger

    Charging the charger Your charger contains a built-in lithium-ion rechargeable battery that doubles as a power bank. This lets you fully charge a pair of hearing aids a minimum of three times on a fully-charged power bank while you are on-the-go.
  • Page 17 When the charger is connected to a power source, the LEDs on your charger indicate the charging status of the power bank. The LEDs turn OFF shortly after the power bank battery is fully charged. Charging (Battery too low to recharge the hearing aids) Charging Fully charged ORANGE blink...
  • Page 18: Power Bank Function

    Power bank function When the charger is disconnected from power, the LEDs on your charger indicate the charger’s power bank battery level. You can check the remaining battery level by opening the charger’s lid. Three full charging cycles of two hearing aids Two full charging cycles of two hearing aids One full charging cycle of two hearing aids Battery too low for a full charging cycle...
  • Page 19: Power And Charge Using Other Sources

    Power and charge using other sources You can power and charge the charger’s battery from other sources than a power socket. This can be done by using the charger’s USB cable. Ensure that the power source is USB 2.0 compliant, with a minimum of 500mA output.
  • Page 20: Drying Your Hearing Aids

    Drying your hearing aids Your charger uses heat from inductive charging to dry your hearing aids when you place them in the charger ports. The drying of your hearing aids is activated when you place the hearing aids in the charger ports and charging begins. IMPORTANT NOTICE Ensure you remove the USB cable when you transport the charger.
  • Page 21: Caring For Your Charger

    Caring for your charger Always ensure that the charger is dry and clean before use. Keep the charging ports clean from dust by using a dry cloth. Do not use water or cleaning fluids to clean the charging ports. Store your charger in a dry location, e.g. in the bedroom. Ensure you keep the charger in an environment with a temperature between +5°C and +38°C (+41°F and +100°F).
  • Page 22: Warnings

    General warnings For your personal safety and to ensure If a small part is swallowed, see a doctor or correct usage, you should familiarise go to the hospital immediately. yourself fully with the following general Heat and chemicals warnings before using your charger. The charger must never be exposed to Consult your hearing care professional if extreme heat, e.g.
  • Page 23 Therefore, do not use the charger in The safety of recharging batteries using a environments with danger of explosions e.g. USB connector is determined by the external mines, oxygen-rich environments or areas signal source. When connected to external where flammable anaesthetics are handled. equipment plugged into a power socket, this equipment must comply with IEC 62368-1 or Rechargeable battery...
  • Page 24 General warnings Possible side effects the standards for human health. The otherwise non-allergenic materials It is recommended to keep the charger used in your charger may, in rare cases, at least 15 centimetres away from the cause a skin irritation or other side effects. implant, e.g.
  • Page 25 Use of third-party accessories Only use accessories, transducers, or cables supplied by the manufacturer. Non- original accessories may result in reduced electromagnetic compatibility (EMC) of your charger. WARNING X-ray/CT/MR/PET scanning, New and used button/coin batteries are electrotherapy and surgery hazardous and should be kept away from Remove your charger before X-ray children.
  • Page 26: Troubleshooting

    Troubleshooting Symptom Possible causes The hearing aids do not turn ON after being The charger did not have enough time to turn the hearing aids ON removed from the before they were removed from the charger charger Two charger LEDs show The hearing aid or charger’s temperature is too cold or too warm ORANGE blinks Three charger LEDs show...
  • Page 27 Solutions Place the hearing aids in the charger ports and try again, or use the push button to turn the hearing aids ON manually Move the charger and hearing aid to a location with a temperature between +5°C and +38°C (+41°F and +100°F) Contact your hearing care professional Verify that the power plug is correctly connected...
  • Page 28 Troubleshooting Symptom Possible causes The hearing aid LED blinks GREEN when the The hearing aid has not been in use for an extended period of time hearing aid is placed in the charger The charger is not turned ON The hearing aid or charger’s temperature is either too warm or The hearing aid LED too cold remains turned OFF...
  • Page 29 Solutions Depending on how depleted the battery in the hearing aid is, the hearing aid automatically resumes normal charging mode after a timeframe of up to 10 minutes. Ensure you leave the hearing aid in the charger during this process. Verify that the charger power plug is correctly connected or the power bank has enough battery Move the charger and hearing aid to a location with a temperature between +5°C and +38°C (+41°F and +100°F) Reinsert the hearing aid into the charger.
  • Page 30: Conditions Of Use

    Conditions of use Operating conditions Temperature: +5°C to +38°C (+41°F to +100°F) Humidity: 5% to 93%, non-condensing Atmospheric pressure: 700 hPa to 1060 hPa Transportation and Temperature and humidity shall not exceed the below storage conditions limits for extended periods during transportation and storage: Temperature: -20°C to +60°C (-4°F to +140°F) Humidity: 5% to 93%, non-condensing...
  • Page 31 This medical device complies with Declaration of Conformity is available at the Medical Device Regulation (EU) the headquarters. 2017/745. Oticon A/S Kongebakken 9 DK-2765 Smørum Denmark www.oticon.global/doc SBO Hearing A/S Waste from electronic equipment must be handled according to Denmark...
  • Page 32 Australian Sponsor Audmet Australia Pty Ltd Suite 4, Level 4, Building B 11 Talavera Road North Ryde NSW 2113 About Getting started Daily use Warnings More info...
  • Page 33 Description of symbols and abbreviations used in this booklet Warnings Text marked with a warning symbol must be read before using the device. Manufacturer The device is produced by the manufacturer whose name and address are stated next to the symbol. Indicates the medical device manufacturer, as defined in EU Regulation 2017/745.
  • Page 34 Description of additional symbols used on labels Keep dry Indicates a medical device that needs to be protected from moisture. Catalogue number Indicates the manufacturer’s catalogue number so that the medical device can be identified. Serial number Indicates the manufacturer’s serial number so that a specific medical device can be identified.
  • Page 35 Description of additional symbols used on labels Firmware version used in the device. Unique device identifier Indicates a carrier that contains unique device identifier information.
  • Page 36 International warranty Your device is covered by an legal rights that you might have under international limited warranty applicable national legislation governing issued by the manufacturer for a sale of consumer goods. Your hearing period of 12 months from the date care professional may have issued a of delivery to you.
  • Page 37: Australia Only

    The rights given under this warranty are Australian customers should contact in addition to other rights and remedies Oticon Australia at under a law in relation to the good or Suite 4, Level 4, Building B, 11 Talavera services to which the warranty relates Road, North Ryde NSW 2113.
  • Page 38: Warranty

    Warranty Certificate Name of owner: _______________________________________________________ Hearing care professional: _______________________________________________ Hearing care professional’s address: _______________________________________ Hearing care professional’s phone: ________________________________________ Purchase date: ________________________________________________________ Model: _______________________ Serial no.: ______________________________ About Getting started Daily use Warnings More info...
  • Page 40 0000026210700001...
