ENGLISH
mASt
Used to set the projector as slave in a master/slave setup.
• Press the [MENU] button or [UP/DOWN] buttons until the desired function is showing on the display.
• Press the [ENTER] button: The values can be changed.
SHnd
Used to change the effect in a stand-alone or master/slave setup.
• Press the [MENU] button or [UP/DOWN] buttons until the desired function is showing on the display.
• Press the [ENTER] button: The effect can be changed.
• Show 0: random show 1-8
• Show 1: [Clouds]
• Show 2: [Sky]
• Show 3: [Water 1]
• Show 4: [Water 2]
• Show 5: [Water 3]
• Show 6: [Inferno]
• Show 7: [Fire]
• Show 8: [Hallucination]
•
Press the [ENTER] button: the speed of the effect can be changed using the [UP/DOWN] buttons
SoUn
Used to activate the sound mode
• Press the [MENU] button or [UP/DOWN] buttons until the desired function is showing on the display.
• Press the [ENTER] button: The values can be changed.
SenS
Used to set the sensitivity of the microphone for sound mode
• Press the [MENU] button or [UP/DOWN] buttons until the desired function is showing on the display.
• Press the [ENTER] button: The values can be changed.
dmSt
Used to set the behavior when DMX is lost
• Press the [MENU] button or [UP/DOWN] buttons until the desired function is showing on the display.
• Press the [ENTER] button: The values can be changed.
• [LASt]: hold the last received values
• [mASt]: Master mode
• [bLnd]: turn off the light source
Disp
Used to invert the display
• Press the [MENU] button or [UP/DOWN] buttons until the desired function is showing on the display.
• Press the [ENTER] button: The values can be changed.
Led
Used to turn off the menu display
• Press the [MENU] button or [UP/DOWN] buttons until the desired function is showing on the display.
• Press the [ENTER] button: The values can be changed.
Temp
Used to read the current temperature of the LED
• Press the [MENU] button or [UP/DOWN] buttons until the desired function is showing on the display.
• Press the [ENTER] button: The values can be changed.
Fhrs
Used to read the active fixture time
• Press the [MENU] button or [UP/DOWN] buttons until the desired function is showing on the display.
• Press the [ENTER] button: The values can be changed.
