Protection Inputs
Reader Display Messages
When an intrusion zone door is configured to display "status," the active
protection inputs will display on the reader LCD in the same manner as the
messages for controlled and monitored inputs. The reader LCD will cycle
through messages indicating the intrusion zone state/mode, any active input
names, and text indicating the current door mode (e.g., "Present Card" or
"Unlocked.")
FIGURE 38. Location of Door Status Display Option
71
