50-3813 Chase Comfort
INSTALL MANUAL
WARNING: ONLY FOR USE ON URBANA SERIES FIREPLACES. If the information in
this manual is not followed exactly, a fire or explosion may result causing property
damage, personal injury or loss of life. Installation and service must be performed
by a qualified installer, service agency or the gas supplier.
C#4001609
CERTIFIED TO: ANSI Z21.88 / CSA 2.33 VENTED GAS FIREPLACE HEATERS
| 1
Advertisement
Related Manuals for Urbana Chase Comfort
Summary of Contents for Urbana Chase Comfort
- Page 1 50-3813 Chase Comfort INSTALL MANUAL WARNING: ONLY FOR USE ON URBANA SERIES FIREPLACES. If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Installation and service must be performed by a qualified installer, service agency or the gas supplier.
-
Page 2: Specifications
Figure 1: Power Vent Dimensions ontents The table below outlines the complete contents of the Urbana Chase Comfort Kit (50-3813). Refer to the parts diagram section of this manual for reference and ensure that your kit is complete and undamaged. - Page 3 #8 screws and a 1/4” nut drive Blower Termination #8 Screws (x4) Chase Comfort kit must be installed a minumum of 25 in above the top of the unit...
- Page 4 Installation - Termination Restrictions & Clearances To determine the location of the blower termination refer to Figure 3 & Table 2 Termination Minimum Clearances below. Note - The termination must be located within the same chase as the fireplace and can’t be attached to ducting/venting or installed in a separate bulkhead.
- Page 5 Installation - Termination Framing 1. Determine the location of the termination as directed on the previous page. NOTE: The Urbana Comfort Kit allows for a minimum wall thickness of 8” (203mm) and amaximum wall thickness of 12” (305mm). For walls thinner than 8” the framing...
- Page 6 Installation - Termination Exterior Wall Cladding Seal gaps with Silicone Figure 7: Silicone locations 11. The exterior wall finishing material can now be installed around the termination. The finishing material Figure 6: Termination installation can butt up against the perimeter of the finishing face but the thickness cannot exceed 1”...
- Page 7 Wall Switch / Rheostat - The Chase Comfort kit may be wired directly to a wall switch for simple on/off control, or to a rheostat for variable speed control. If using a rheostat, the voltage range must be set to NOT drop below 80VAC.
- Page 8 Wiring - Termination Figure 10: Front cover screws Figure 11: Front Cover removal 1. Remove the termination’s front cover by removing the four (4) screws using a 1/4” nut driver. See Figures 10 & 11. 2. To wire the blower motor, use the supplied wire nuts to connect the two loose blower motor leads to the incoming power that was routed through the rear strain relief.
- Page 9 NOTE: The Urbana Comfort Kit is equipped with a sealing one way flow door. the unit will flow air out of the chase when activated and will prevent outside air from flowing in when deactivated. An external one way duct...
- Page 10 emote CtivAtion 1. With no batteries inserted into the battery holder, 4. Keeping pressed the Power On/Off button and keep pressed Power On/Off and O buttons. pressing the O button, navigate to the fan blade. This is in Clr state. 2.
-
Page 11: Parts List
Parts List Reference Part Description Part Number Number Finishing Face 50-3770 Front Cover 50-3980 Blower Motor 50-3978 Framing Thimble Assembly 50-3768 MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 www.Urbanafireplaces.com Spring 2020 C-16010 | 11...
