Table Of Contents; Warranty; Standard Features; Control Dimensions - DART Controls 65E Series Instruction Manual

WARRANTY ............................................................................................................................................................................... 1
STANDARD FEATURES ............................................................................................................................................................ 1
CONTROL DIMENSIONS .......................................................................................................................................................... 1
MOUNTING DIMENSIONS ........................................................................................................................................................ 2
INSTALLATION .......................................................................................................................................................................... 2
HOOK-UP DIAGRAMS ........................................................................................................................................................... 2-3
INHIBITING THE CONTROL ....................................................................................................................................................... 3
TRIMPOT ADJUSTMENTS ..................................................................................................................................................... 3-4
IN CASE OF DIFFICULTY ......................................................................................................................................................... 4
MODEL SELECTION ................................................................................................................................................................. 4
SPECIFICATIONS ...................................................................................................................................................................... 4
65E SERIES PARTS PLACEMENT & LIST ............................................................................................................................... 5
65E SERIES SCHEMATIC ......................................................................................................................................................... 6
REPAIR PROCEDURE & PRODUCT LINE ......................................................................................................... BACK COVER
Dart Controls, Inc. (DCI) warrants its products to be free from defects in material and workmanship. The exclusive remedy for this
warranty is DCI factory replacement of any part or parts of such product which shall within 12 months after delivery to the purchaser
be returned to DCI factory with all transportation charges prepaid and which DCI determines to its satisfaction to be defective.
This warranty shall not extend to defects in assembly by other than DCI or to any article which has been repaired or altered by
other than DCI or to any article which DCI determines has been subjected to improper use. DCI assumes no responsibility for the
design characteristics of any unit or its operation in any circuit or assembly. This warranty is in lieu of all other warranties, express
or implied; all other liabilities or obligations on the part of DCI, including consequential damages, are hereby expressly excluded.
NOTE: Carefully check the control for shipping damage. Report any damage to the carrier immediately. Do not attempt to operate
the drive if visible damage is evident to either the circuit or to the electronic components.
All information contained in this manual is intended to be correct, however information and data in this manual are subject to
change without notice. DCI makes no warranty of any kind with regard to this information or data. Further, DCI is not responsible
for any omissions or errors or consequential damage caused by the user of the product. DCI reserves the right to make manu-
facturing changes which may not be included in this manual.
Improper installation or operation of this control may cause injury to personnel or control failure. The control must be
installed in accordance with local, state, and national safety codes. Make certain that the power supply is disconnected
before attempting to service or remove any components!!! If the power disconnect point is out of sight, lock it in dis-
connected position and tag to prevent unexpected application of power. Only a qualified electrician or service person-
nel should perform any electrical troubleshooting or maintenance. At no time should circuit continuity be checked by
shorting terminals with a screwdriver or other metal device.
Provides smooth variable speed capability for mobile equipment
●
Maintains variable speed control as batteries discharge
●
Adjustable maximum speed, minimum speed, current limit, I.R. compensation, and accel
●
Inhibit terminal permits optional start-stop without breaking battery lines
●
Speed potentiometer, knob, and dialplate included
●
Increases range or running time of battery operated equipment through high efficiency
●
Automatic current limit foldback decreases current limit to 50% of setpoint when heatsink temperatures reach
●
80 C. - provides protection from overheating
o
MODEL
65E40
65E60

TABLE OF CONTENTS

WARRANTY

WARNING

STANDARD FEATURES

CONTROL DIMENSIONS

WIDTH LENGTH
inches (centimeters)
3.7 (9.40) 7.0 (17.8)
6.7 (17.1) 9.0 (22.9)
DEPTH WEIGHT
oz. (gms.)
1.70 (4.32) 13.4 (379)
2.27 (5.77) 34.0 (962)
1
