8 Power down the QCA147 cabinet.
9 Remove the QCA147 rear panels and EMI back panel.
10 Remove the QPF37A Alarm Adapter Plug in the QCA147 cabinet.
11 Verify that the alarm cable is installed between the QCA147 and the
first QCA137 cabinets.
12 Install connector J1 of the NT8D46BL cable into connector AL1
(P0678258 Filter Connector) of the QCA147 cabinet.
13 Install connector J1 of the NT8D46BE cable into connector P1 of the
NT8D46BL cable.
14 Install connector J2 of the NT8D46BC cable into connector P2 of the
NT8D46BL cable.
15 Reinstall the QCA147 EMI back panel and rear panels.
16 Power down the second QCA137 cabinet.
17 Remove the second QCA137 rear panels and EMI back panel.
18 Install connector J1 of the NT8D46BC cable into connector AL1
(P0678258 Filter Connector) of the second QCA137 cabinet.
19 Reinstall the second QCA137 EMI back panel and rear panels.
20 Power up the QCA147 and QCA137 cabinets.
21 Set all circuit breakers in the rear of the AEM pedestal to OFF (down),
then connect the AEM column to the power supply.
22 See the Application Module installation and upgrade guide
(553-3201-210) for instructions on installing the Application Module
and powering up the column.
