14 Installing a stand-alone AEM
Table 1xxx
Pedestal wire gauge requirements with two 30-amp 48 V dc feeds (see Note 1)
Length
0 - 3 m (10 ft)
0 - 6 m (20 ft)
0 - 9 m (30 ft)
0 - 12 m (40 ft)
0 - 15 m (50 ft)
0 - 18 m (60 ft)
0 - 21 m (70 ft)
0 - 24 m (80 ft)
0 - 27 m (90 ft)
0 - 30 m (100 ft)
0 - 60 m (200 ft)
over 60 m (200 ft)
Note 1: Two 30-amp feeds are typically adequate for a column with four modules (five wires
total-two 30-amp battery/battery return pairs plus logic return).
Note 2: When using dual conduit, the wires must be run in battery/battery return pairs, with
one pair in one conduit and the other pair, plus logic return, in the other conduit.
Note 3: Five single runs of #4 AWG wire are used from the distribution point to the NT6D53
junction box near the pedestal; #10 AWG wire in a single conduit (supplied with the junction
box) is run from the junction box to the pedestal.
Note 4: Five double runs of #4 AWG wire are used from the distribution point to the
NT6D53 junction box near the pedestal; #10 AWG wire in a single conduit (supplied with the
junction box) is run from the junction box to the pedestal.
Legend: Yes = Wire size is adequate for the distance
No = Wire size has too high a voltage drop and is inadequate for the distance.
553-3201-200 Standard 1.0 April 1993
Single Dual conduit
conduit #6 AWG
#8 AWG (Note 2)
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
No Yes
No Yes
No Yes
No No
No No
No No
No No
Junction box
(single #4 AWG) (double #4 AWG)
(Note 3)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
Junction box
(Note 4)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
