Part No.PL501048100002

Rev: A

Jun 2022

Operation

Manual

产品说明书

PRODU

C T MAN U AL

GTJZ1012E/1012E/3346E

GTJZ1212E/1212E/4047E

0608E (2132E)

G T JZ

for Sinoboom Poland

0808E (2732E)

G T JZ

0808E (2732E)

G T JZ

0808E (2732E)

Table of Contents

Need help?

Do you have a question about the GTJZ1012E and is the answer not in the manual?

Questions and answers

Summary of Contents for Sinoboom GTJZ1012E

Page 1 Operation Part No.PL501048100002 Rev: A Manual Jun 2022 产品说明书 PRODU C T MAN U AL GTJZ1012E/1012E/3346E GTJZ1212E/1212E/4047E 0608E (2132E) G T JZ for Sinoboom Poland 0808E (2732E) G T JZ 0808E (2732E) G T JZ G T JZ 0808E (2732E)
Page 3 Operating, servicing and maintaining this vehicle or equipment can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle or equipment in a well-ventilated area and wear gloves or wash your...
Page 4 : No.128, East Jinzhou Avenue, Ningxiang High-tech Industrial Park, Changsha, Hunan, China Zip Code : 410600 Copyright © Hunan Sinoboom Intelligent Equipment Co., Ltd. All Rights Reserved The final interpretation right of this manual belongs to Hunan Sinoboom Intelligent Equipment Co., Ltd.
Page 5 See the nameplate on your machine to identify the model and serial number.(See Decals/Nameplates Inspection of the Operation Manual for details.) Trade identification MODELS SERIAL NO. Imperial Metric GTJZ1012E 1012E 3346E ANSI/CSA: From PL0104800100 to Present CE: From PL0106700100 to Present GTJZ1212E 1212E...
Page 6 This Page Intentionally Left Blank...
Page 7 This manual covers the basic parts information of one or more products. Therefore, please use this manual according to your needs. If you find problems in the manual or have suggestions for improve- ment, feel free to share your feedback with Sinoboom, and we will address these issues as soon as possible.
Page 8 This Page Intentionally Left Blank...
Page 9: Table Of Contents
Testing the Platform Controller 3 Safety ....... 3-1 (SINOBOOM) ......6-3 Testing the Platform Controller (DTC) . 6-5 Safety Definitions .
Page 10 GTJZ1212E ......7-11 SINOBOOM system ....7-11 DTC system .
Page 11: Introduction
The owner or administrator of the machine shall also provide the manufacturer’s maintenance information to the person responsible for maintaining the machine. If you have any questions, contact Hunan Sinoboom In- telligent Equipment Co., Ltd.. GTJZ1012E&1212E Operation Manual © Jun 2022...
Page 13: Performance Parameters
PERFORMANCE PARAMETERS Table 1-1 GTJZ1012E Specifications 1012E (METRIC) 3346E (IMPERIAL) MEASURE DIMENSION PARAMETERS Max. platform height 32ft 10in. Max. working height 39ft 4.5in. Max. horizontal extension 0.9m Length 2.45m Width 1.17m 3ft 10in. Height (stowed, rails folded) 1.86m 6ft 1in.
Page 14 PERFORMANCE PARAMETERS Table 1-1 GTJZ1012E Specifications (continued) 1012E (METRIC) 3346E (IMPERIAL) MEASURE Max. noise 72dB POWER PARAMETERS Hydraulic tank capacity 3.3 gal (imperial)/4 gal (US) Hydraulic system capacity (including tank) 7.5 gal (imperial)/9 gal (US) Hydraulic system pressure 21MPa 3046 Psi Battery specification (quantity ×...
Page 15 3.3 gal (imperial)/4 gal (US) Hydraulic system capacity (including tank) 7.5 gal (imperial)/9 gal (US) Hydraulic system pressure 21MPa 3046 Psi Battery specification (quantity × voltage, 4×6V, 240Ah capacity) Power system voltage 24VDC Control voltage 24VDC GTJZ1012E&1212E Operation Manual © Jun 2022...
Page 16 The ground bearing data is approximate values not considering different options and only applicable when it is safe enough. e) The loads of persons, accessories, tools and materials are factored into the rated platform capacity. © Jun 2022 GTJZ1012E&1212E Operation Manual...
Page 18 24. Steer Cylinder √ 25. Steer Wheel √ 26. Drive Reducer, DC √ 27. Ground Controller √ 28. Power Unit √ 29. Hydraulic Oil Tank √ 30. Rear Wheel √ 31. Right turntable cover √ © Jun 2022 GTJZ1012E&1212E Operation Manual...
Page 19 Note: The platform heights are as follows (from ground to platform floor) when the down limit switch disengages: • GTJZ1012E: 2.8±0.3m (9ft 2in±10in) • GTJZ1212E: 2.8±0.3m (9ft 2in±10in) GTJZ1012E&1212E Operation Manual © Jun 2022...
Page 21: Safety
Failure to notify the manufacturer within SAFETY DEFINITIONS 48 hours of the incident involving the machine of Hunan Sinoboom Intelligent Equipment Co., Ltd. may void the product's warranty. This safety alert symbol appears with most safety statements. It means atten-...
Page 22: Electrocution Hazards
Table 3-1 Minimum Safe Distance Voltage Minimum Safe Distance (Phase to Phase, kV) (m/ft) 0-50 3.05 (10) 50-200 4.60 (15) 200-350 6.10 (20) 350 -500 7.62 (25) 500 -750 10.67 (35) 750 -1000 13.725 (45) © Jun 2022 GTJZ1012E&1212E Operation Manual...
Page 23 • Do not replace key parts that platform controller to lower the affect machine stability with platform. If you intend to lower the GTJZ1012E&1212E Operation Manual © Jun 2022...
Page 24: Work Environment Hazards
Sinoboom, it must be approved or guided by the manufacturer. © Jun 2022 GTJZ1012E&1212E Operation Manual...
Page 25: Unsafe Operation Hazards
Maximum Slope: • Improper securing of the machine to another object by just sitting it against, fastening or binding. GTJZ1012E: 25% (14°） GTJZ1212E: 25% (14°） • Stunt or imprudent use of the machine. Climbing capacity means the maximum allowable tilt •...
Page 26: Fall Hazards
The battery is vital to maintaining the stability of the machine. • Do not place or attach any suspended load onto any part of the machine. • Do not use the machine as a crane. © Jun 2022 GTJZ1012E&1212E Operation Manual...
Page 27: Collision Hazards
• Maintain good judgment and plan- ning when using the controller on the ground to operate the ma- chine. Maintain proper distance between operator, machine and fixed object. GTJZ1012E&1212E Operation Manual © Jun 2022...
Page 28: Crush Hazards
NOTICE chine. Maintain proper distance between operator, machine and To avoid machine damage, follow all operation and fixed object. maintenance requirements in the Operation Manual and the Maintenance Manual. © Jun 2022 GTJZ1012E&1212E Operation Manual...
Page 29: Bodily Injury Hazards
During operation, keep the left and right doors of the chassis closed and locked. Only trained service personnel can open the left and right doors to repair the machine. GTJZ1012E&1212E Operation Manual © Jun 2022...
Page 30: Welding And Polishing Requirements3-10
Before welding, grinding and polishing operations, al- ways ensure you read and understand all operation and maintenance requirements in the Operation Manual and the Maintenance Manual. © Jun 2022 3-10 GTJZ1012E&1212E Operation Manual...
Page 31: After Using The Machine
5. Block the wheels with the wheel wedges. 6. Charge the battery. NOTICE After using the machine, the power off switch must be disconnected. GTJZ1012E&1212E Operation Manual 3-11 © Jun 2022...
Page 33: Jobsite Inspection
Operators must identify and avoid workplace hazards when mov- ing, installing and operating the machine. Unless approved by Sinoboom, never operate the ma- chine in a hazardous site. The following items present danger on the jobsite: •...
Page 35: Pre-Operation Inspection
4. The operator should go through a professional train- ing based on this operation manual, and should be certified as a qualified operator in operation of this machine. GTJZ1012E&1212E Operation Manual © Jun 2022...
Page 36: Conducting A Pre-Operation
Tires and wheels • The folding platform’s ability to support the platform • Safety arm side rail and proper installation of safety pin with • Limit switches and horn wire rope • Alarms and LEDs © Jun 2022 GTJZ1012E&1212E Operation Manual...
Page 37: Inspect Hydraulic Oil Level
POWER RATIO DESCRIPTION The battery has been fully charged. 90-100% The battery is at 70% of its capacity. The battery is at 50% of its capacity. The battery is at 30% of its capacity. GTJZ1012E&1212E Operation Manual © Jun 2022...
Page 38: Indoor/Outdoor Mode Verification
The indoor mode must not be used in outdoor applications. For indoor/outdoor mode setting method, please refer Indoor/Outdoor Mode Setting-GTJZ1212E, page 7-11. © Jun 2022 GTJZ1012E&1212E Operation Manual...
Page 39: Pre-Operation Function Test
Only qualified maintenance technicians can repair the machine according to the manufacturer’s regulations. After any maintenance, the operator must perform an- other pre-operation inspection before conducting a pre- operation function test. Figure 6-1 Ground controller GTJZ1012E&1212E Operation Manual © Jun 2022...
Page 40 ON position. 2. Turn the key switch to the ground control position. 3. Ensure the relevant indicator light comes on and no error message appears. Emergency stop button © Jun 2022 GTJZ1012E&1212E Operation Manual...
Page 41: Testing The Platform Controller
1. Pull out the emergency stop buttons on the ground and platform controllers to the ON position. 2. Turn the key switch of the ground controller to the Figure 6-2 Platform controller (SINOBOOM) platform control position. Emergency stop button 8. Emergency stop 1.
Page 42 3. Hold the enable button on the joystick, and press on the right side of the thumb rocker switch for Drive and brake functions steer function, the machine should steer right. Drive high/low speed select switch © Jun 2022 GTJZ1012E&1212E Operation Manual...
Page 43: Testing The Platform Controller (Dtc)
10. Lift function 3. Enable switch enable switch 4. Platform up 11. Horn 12. Drive/steer 5. Platform down function enable switch 13. Drive high/low 6. Drive forward speed select switch GTJZ1012E&1212E Operation Manual © Jun 2022...
Page 44 Drive and brake functions or ground controller to the OFF position. All functions should not operate. 2. Pull out the emergency stop button on the platform and ground to the ON position. Horn button © Jun 2022 GTJZ1012E&1212E Operation Manual...
Page 45: Testing The Drive Speed
3. —SINOBOOM system：Move upwards the lift func- tion enable switch on the platform controller, the in- 3. Hold the enable button on the joystick, and press dicator light should be on.
Page 46: Testing The Emergency Lowering
4km/h（2.5mph）, or 25～30s for a move the machine from service. driving distance of 30m（98ft 5in）. Turtle speed testing： 6. —SINOBOOM system：Move upwards the lift func- NOTICE tion enable switch on the platform controller, the in- If the time for a driving distance of 30m（98ft dicator light should be on..
Page 47: Testing The Tilt Protection Function
The wooden boards should measure(L × W × H): 50mm × 100mm × 100mm (2in. × 4in. × 4in.). GTJZ1012E&1212E Operation Manual © Jun 2022...
Page 48: Testing The Pothole Guard
10℃ (50°F) or above, or the hydraulic oil temperature is below 15℃ (59°F), and the alarm sounds when the rated load is not reached (the ground or platform display shows OL), please re-calibrate the weight sensor. © Jun 2022 6-10 GTJZ1012E&1212E Operation Manual...
Page 49 PRE-OPERATION FUNCTION TEST NOTICE Weight calibration must be performed by qualified personnel trained by Sinoboom. GTJZ1012E&1212E Operation Manual 6-11 © Jun 2022...
Page 50 PRE-OPERATION FUNCTION TEST This Page Intentionally Left Blank © Jun 2022 6-12 GTJZ1012E&1212E Operation Manual...
Page 51: Operating The Machine
If more than one operator uses the same ma- chine at different times of the same work shift, they must all be qualified operators and follow all the safety rules and instructions in this Operation Manual. GTJZ1012E&1212E Operation Manual © Jun 2022...
Page 52: Emergency Towing/Dragging
10. After the towing is completed, re-energize the ma- chine, the brake can operate properly. 11. Remove the chokes as needed. SINOBOOM system 1. Chock the wheels from rolling. 2. Ensure the path of travel is clear of obstructions. © Jun 2022 GTJZ1012E&1212E Operation Manual...
Page 53: Operation From Ground
To drive： performance. When the platform display indiciates a low battery level, the drive speed and lift speed of the The drive function cannot be operated from the ground machine will go down. controller. GTJZ1012E&1212E Operation Manual © Jun 2022...
Page 54: Dtc System
Before operating the machine with the platform control- backward the joystick to drive the machine forward/ ler on the ground: backward. 2. Speed up: slowly move the joystick off center. © Jun 2022 GTJZ1012E&1212E Operation Manual...
Page 55: Extending/Retracting The Platform
DRIVING ON A SLOPE FOLDING/UNFOLDING THE RAILS Before driving on a slope: 1. Determine the climbing ability of the machine. GTJZ1012E: 25% (14°） UNSAFE OPERATION HAZARD GTJZ1212E: 25% (14°） • Do not fold the rails while the machine is working.
Page 56: Charging The Battery
The charging site should maintenance-free and lithium batteries, and the latter be well-ventilated and if charging two batteries do not need maintenance. the battery indoor, a fan can be used for better ventilation. © Jun 2022 GTJZ1012E&1212E Operation Manual...
Page 57 -20℃~45℃. Add deionized water. Put back the bucket cover and connect the Charging the lead acid battery (requiring water refilling plug. maintenance) GTJZ1012E&1212E Operation Manual © Jun 2022...
Page 58: Charger Operating Instructions
If excessive distilled water is added and the electro- lyte overflows, use water mixed with bicarbonate (baking soda) to neutralize the acid, and blot up the liquid with a suction pipe. Figure 7-4 © Jun 2022 GTJZ1012E&1212E Operation Manual...
Page 59: Green Power Charger
(A). * Process will time out and profile will remain unchanged if there is 15 seconds of inactivity, a profile number is allowed to display three times, or if AC power is cycled. GTJZ1012E&1212E Operation Manual © Jun 2022...
Page 60: Green Power Charger
Discover AGM US Battery Flooded Trojan T125 Trojan T1275 (two in series and two in tandem) Note: the default curve code is B04. © Jun 2022 7-10 GTJZ1012E&1212E Operation Manual...
Page 61: Indoor/Outdoor Mode Setting
“Id”on the screen, and the battery on the bottom-right on the display screen of the level will be displayed again after the combined platform controller will be on, and the maximum keys are released.The maximum height of the GTJZ1012E&1212E Operation Manual 7-11 © Jun 2022...
Page 62 At this time, restore the joystick to the neutral position and release the joystick, then hold the "- enable switch" of the joystick and push the joystick forward, the platform will continue to rise to 11.9m (39 ft). © Jun 2022 7-12 GTJZ1012E&1212E Operation Manual...
Page 63: Transporting And Lifting The Machine
7. Keep the machine horizontal when lowering the fork NOTICE frame. Do not pull/drag the machine unless an emergency, failure or loss of power occurs. Refer to Emergency Towing/Dragging, page 7-2. GTJZ1012E&1212E Operation Manual © Jun 2022...
Page 64: Lifting The Machine With A Crane
5. Lift the machine according to the following figure. NOTICE During transportation, retract the extension platform so that the extension platform is secure at the slots. Ensure that the extension platform cannot extend or shake out of the main platform during transportation. © Jun 2022 GTJZ1012E&1212E Operation Manual...
Page 66 TRANSPORTING AND LIFTING THE MACHINE This Page Intentionally Left Blank © Jun 2022 GTJZ1012E&1212E Operation Manual...
Page 67: Maintenance
• Conduct a quarterly inspection on machines that as stated in operation manual and maintenance have been out of service for a period lasting longer than three months. manual. GTJZ1012E&1212E Operation Manual © Jun 2022...
Page 68: Following Amaintenance Schedule
A+B+C hours and the box marked “REPAIRED” shall be checked. Select the appropriate inspection procedure based Every year or every 1000 hours A+B+C+D on the inspection type. © Jun 2022 GTJZ1012E&1212E Operation Manual...
Page 69 B-5 Inspect Hydraulic Oil Tank Air Filter B-6 Inspect Brake Manual Release Function B-7 Inspect Emergency Lowering B-8 Inspect Brake Device B-9 Test Full Lift/Lower Time B-10 Test Drive Speed B-11 Inspect Tilt Protection GTJZ1012E&1212E Operation Manual © Jun 2022...
Page 70 Condition Malfunction D-1 Inspect Scissor Arm Installation Bearing D-2 Inspect Chassis Slider D-3 Replace Hydraulic Oil Tank Return Oil Filter Element D-4 Replace Hydraulic Oil User Inspector Signature Inspection Date Inspector Title Inspector Company © Jun 2022 GTJZ1012E&1212E Operation Manual...
Page 71: Decals/Nameplates Inspection
Do not operate the engine if there are missing or badly worn safety labels. GTJZ1012E&1212E Operation Manual 10-1 © Jun 2022...
Page 72: Decals/Nameplates (Ce-Metric)
DECALS/NAMEPLATES INSPECTION DECALS/NAMEPLATES (CE-METRIC) (33) (27) (27) (27) (26) (15) (11) (10) (27) (27) (18) © Jun 2022 10-2 GTJZ1012E&1212E Operation Manual...
Page 73 DECALS/NAMEPLATES INSPECTION Description Part NO. Remarks 101048103029 GTJZ1012E decals CE-Metric 101049103025 GTJZ1212E decals CE-Metric 101048103025 LOGO-SINOBOOM 101048103030 Decal-1012E GTJZ1012E 101049103024 Decal-1212E GTJZ1212E Attention line, 50mm wide 216060000004 Decal-Main power switch 101016100031 Decal-Lifting point 101014100020 Decal-Tie-down point 101014100021 101014100013 Decal-Crush hazard...
Page 74 Description Part NO. Remarks Decal-Electrical plug 101014100030 101058103001 LOGO-IPAF 101040103008 Decal-Brake release Decal-Emergency stop switch 101055103015 Decal-Tipping hazard 101012100019 Decal-Tipping hazard 101012100008 101012100029 Decal-Crush hazard Decal-Tipping hazard 101041103020 GTJZ1012E Decal-Tipping hazard 101039103017 GTJZ1212E © Jun 2022 10-4 GTJZ1012E&1212E Operation Manual...
Page 75: Decals/Nameplates (Ce-Imperial)
DECALS/NAMEPLATES INSPECTION DECALS/NAMEPLATES (CE-IMPERIAL) (33) (27) (27) (27) (26) (10) (27) (15) (11) (27) (18) GTJZ1012E&1212E Operation Manual 10-5 © Jun 2022...
Page 76 DECALS/NAMEPLATES INSPECTION Description Part NO. Remarks GTJZ1012E decals CE-Imperial 101048100010 GTJZ1212E decals CE-Imperial 101049100001 101048103025 LOGO-SINOBOOM 101048103024 Decal-3346E GTJZ3346E 101049103016 Decal-4047E GTJZ4047E Attention line, 50mm wide 216060000004 Decal-Main power switch 101016100031 Decal-Lifting point 101014100020 Decal-Tie-down point 101014100021 101014100013 Decal-Crush hazard...
Page 77 Description Part NO. Remarks Decal-Electrical plug 101014100030 101058103001 LOGO-IPAF 101040103008 Decal-Brake release Decal-Emergency stop switch 101055103015 Decal-Tipping hazard 101012100019 Decal-Tipping hazard 101012100008 101012100029 Decal-Crush hazard Decal-Tipping hazard 101041103020 GTJZ3346E Decal-Tipping hazard 101039103017 GTJZ4047E GTJZ1012E&1212E Operation Manual 10-7 © Jun 2022...
Page 78: Decals/Nameplates (Ce-Pl)
DECALS/NAMEPLATES INSPECTION DECALS/NAMEPLATES (CE-PL) (33) (27) (27) (27) (26) (15) (11) (10) (27) (27) (18) © Jun 2022 10-8 GTJZ1012E&1212E Operation Manual...
Page 79 DECALS/NAMEPLATES INSPECTION Description Part NO. Remarks 101048103004 GTJZ1012E decals CE-PL 101049103004 GTJZ1212E decals CE-PL 101048103025 LOGO-SINOBOOM 101048103024 Decal-3346E GTJZ3346E 101049103016 Decal-4047E GTJZ4047E Attention line, 50mm wide 216060000004 Decal-Main power switch 101016100031 Decal-Lifting point 101014100020 Decal-Tie-down point 101014100021 101014100013 Decal-Crush hazard...
Page 80 Blind rivet 4×8-ZnD GB/T 12618.2 Decal-Electrical plug 101014100030 101058103001 LOGO-IPAF 101040103008 Decal-Brake release Decal-Emergency stop switch 101055103015 Decal-Tipping hazard 101012100019 Decal-Tipping hazard 101012100008 101012100029 Decal-Crush hazard Decal-Tipping hazard 101041103020 GTJZ3346E Decal-Tipping hazard 101039103017 GTJZ4047E Q-LINE(Logo) 101058103000 © Jun 2022 10-10 GTJZ1012E&1212E Operation Manual...
Page 81: Decals/Nameplates (Ansi)
DECALS/NAMEPLATES INSPECTION DECALS/NAMEPLATES (ANSI) (33) (27) (27) (27) (26) (15) (11) (10) (27) (27) (18) GTJZ1012E&1212E Operation Manual 10-11 © Jun 2022...
Page 82 DECALS/NAMEPLATES INSPECTION Description Part NO. Remarks 101048103016 GTJZ1012E decals ANSI 101049103012 GTJZ1212E decals ANSI 101048103025 LOGO-SINOBOOM 101048103024 Decal-3346E GTJZ3346E 101049103016 Decal-4047E GTJZ4047E Attention line, 50mm wide 216060000004 Decal-Main power switch 101016100031 Decal-Lifting point 101014100020 Decal-Tie-down point 101014100021 101014100013 Decal-Crush hazard...
Page 83 Decal-Tipping hazard 101012100019 Decal-Tipping hazard 101012100008 101012100029 Decal-Crush hazard Decal-Tipping hazard 101038103017 GTJZ3346E Decal-Tipping hazard 101046103013 GTJZ4047E Decal-Annual inspection 101040103015 Decal-Detachable handle support 101062103021 Stick on the right of PL0000000008 Decal-Non-insulated the #23 label GTJZ1012E&1212E Operation Manual 10-13 © Jun 2022...
Page 84: Decals/Nameplates (Csa)
DECALS/NAMEPLATES INSPECTION DECALS/NAMEPLATES (CSA) (33) (27) (27) (27) (26) (15) (11) (10) (27) (27) (18) © Jun 2022 10-14 GTJZ1012E&1212E Operation Manual...
Page 85 DECALS/NAMEPLATES INSPECTION Description Part NO. Remarks 101048103021 GTJZ1012E decals CSA 101049103015 GTJZ1212E decals CSA 101048103025 LOGO-SINOBOOM 101048103024 Decal-3346E GTJZ3346E 101049103016 Decal-4047E GTJZ4047E Attention line, 50mm wide 216060000004 Decal-Main power switch 101016100031 Decal-Lifting point 101014100020 Decal-Tie-down point 101014100021 101014100013 Decal-Crush hazard...
Page 86 Decal-Crush hazard Decal-Tipping hazard 101038103017 GTJZ3346E Decal-Tipping hazard 101046103013 GTJZ4047E Decal-Annual inspection 101040103015 Decal-Detachable handle support 101040103014 104011100021 Decal-Crush hazard Decal-Operating instructions 101048103023 Stick on the right of PL0000000008 Decal-Non-insulated the #23 label © Jun 2022 10-16 GTJZ1012E&1212E Operation Manual...
Page 87: Appendix 1: Symbols And Description
Collision hazards-Re- Electrocution hazards Electrocution hazards Keep a safe distance Tip-over hazards-Avoid lease brake on ramp on platform on the ground and from power lines uneven ground platform GTJZ1012E&1212E Operation Manual © Jun 2022...
Page 88 Indoor use handle position and down platform Outdoor use The side force Electrocution hazards Wear protective cloth- Battery explosion ing and glasses hazard No smoking No smoking Only professional Improve point Lashing points maintenance © Jun 2022 GTJZ1012E&1212E Operation Manual...
Page 89 DECALS/NAMEPLATES INSPECTION personnel can start the maintenance Tire to ground load Forklift fork position Platform carrying Carrying capacity of Hydraulic oil filler capacity fixed and extended platform Horn Tool or weight Fast/high speed Slow/low speed GTJZ1012E&1212E Operation Manual © Jun 2022...
Page 91: Appendix 2: Prepare The Work Record Before Delivery
2. Use the table to record the results. After each section is complete, mark the appropriate box. 3. Record the inspection results. If any inspection results are "NO", the machine must be stopped and re-in- spected after repair is completed and marked in the box marked "inspection". GTJZ1012E&1212E Operation Manual © Jun 2022...
Page 93: Appendix 3: Repair & Inspection Report
B-2 Inspect Rim, Tire and Fasteners B-3 Inspect Battery B-4 Inspect Hydraulic Oil B-5 Inspect Air Filter of Hydraulic Oil Tank B-6 Inspect Brake Manual Release Function B-7 Inspect Emergency Lowering B-8 Inspect Brake Device GTJZ1012E&1212E Operation Manual © Jun 2022...
Page 94 Been Repaired Condition Malfunction D-1 Inspect Scissor Arm Installation Bearing D-2 Inspect Chassis Slider D-3 Replace Return Oil Filter Element of Hydraulic Oil Tank D-4 Replace Hydraulic Oil User Inspector Signature Inspection Date Inspector Title © Jun 2022 GTJZ1012E&1212E Operation Manual...
Page 95 4. Record the inspection results. If any inspection item is marked as "NO", the machine must be stopped and re- inspected after repair is completed, and the box marked “REPAIRED” shall be checked. Select the appropriate inspection procedure based on the inspection type. GTJZ1012E&1212E Operation Manual © Jun 2022...
