User Manual
Of HD Digital Set Top Box
DTB-120CP
Important Safety Instructions
Please read this User Manual carefully to ensure proper use of this product and keep this manual for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DTB-120CP and is the answer not in the manual?

Questions and answers

Related Manuals for Denver DTB-120CP

Summary of Contents for Denver DTB-120CP

  • Page 1 User Manual Of HD Digital Set Top Box DTB-120CP Important Safety Instructions Please read this User Manual carefully to ensure proper use of this product and keep this manual for future reference.
  • Page 2 1) Read these instructions. 12) Unplug this apparatus during lighting storms or when unused for long periods of time. 2) Keep these instructions. 13) Refer all servicing to qualified service personnel. Servicing is required when the 3) Heed all warnings. apparatus has been damaged in any way, such as power-supply cord or plug is 4) Follow all instructions.
  • Page 3 16) No naked flame sources, such as lighted candles, should be placed on the apparatus. The symbol indicates that dangerous voltages constituting a risk of electric 17) Attention should be drawn to the environmental aspects of battery disposal. shock are present within this unit. 18) The use of apparatus in moderate climate.

  • Page 5: Table Of Contents

    Table of contents 6.1.2 DTV Manual Tunning ....................1 Front and Rear Panel ......................6.1.3 Program Edit ....................... 2 Remote Control ......................... 6.1.4 LCN ........................2.1 Key introduce ......................... 6.1.5 Sort by ........................2.2 Installing the Batteries ....................6.1.6 Signal Information ...................... 2.3 Using the Remote Control ....................
  • Page 6 6.3.2 SPDIF Mode ......................... 6.5.5 Antenna Power ....................... 17 6.3.3 SPDIF delay ......................... 6.5.6 Menu Timeout ....................... 17 6.3.4 Output Mode ......................... 6.5.7 Menu Transparency ...................... 17 6.4 TIME setting ......................... 6.5.6 PVR Function ....................... 6.4.1 Auto Sync ......................... 6.5.7 Restore Factory Default ....................6.4.2 Clock .........................

  • Page 7: Front And Rear Panel

    9 Technical Specifications ....................7. CI+ Interface: The interface for CI+ module. 1 Front and Rear Panel 1. REMOTE CONTROL SENSOR: Used to receive the signal from the remote control. 2. LED DISPLAY WINDOW: Used to display channel number. 3. STANDBY INDICATOR: Used to visually show power state of the set top box, the green LED will be light if turned on the set top box and the red LED will be 1.

  • Page 8: Remote Control

    7. MAINS CABLE: This is used to connect to your main power supply. decreases volume. 10. TV/RADIO: Switches from TV function to Radio function and from Radio to TV. 2 Remote Control 11. RECALL: Used to switch between the last two viewed 2.1 Key introduce channels.

  • Page 9: Installing The Batteries

    22. MENU: Open main menu. The diagram inside the Battery Compartment shows the correct way to install the 23. FAVOURITE: Open the favorite mode. batteries. 24. 0-9(Numeric Buttons): Press to enter channel numbers or numeric input when changing settings. 25. FWD: Searches for wards during media play. 26.

  • Page 10: Connections

    3 Connections Caution: Make sure to check the voltage specification of the wall outlet is the same rating with the receiver. To prevent the risk of electric shock, do not open the cover or the back of the receiver.

  • Page 11: First Time Installation

    (1) Select [OSD Language] ， press RIGHT/LEFT or UP/DOWN button to select a language. Note: When connecting the receiver to other equipment, e.g., TV, VCR and amplifier, make sure to refer to relevant user manual for instruction. Also, make sure you disconnect all the equipments from the mains supply before the connection.

  • Page 12: Basic Operation

    5.2 Channel Search (DTV Manual Tuning) 5 Basic Operation To access the menu, press MENU and select [Channel]. The Menu provides options to 5.1 Channel Search (Auto Tuning) adjust the Search Channel settings. To access the menu, press MENU and select [Channel]. The Menu provides options for Press LEFT/RIGHT or NUMBER button to set your preferred frequency, then press OK to Auto Tuning.

  • Page 13: Program Edit

    (1) Set Favourite Program You can create a short list of favourite programs that you can easily access. Set Favourite TV or Radio program : 1. Press UP/DOWN button to select the preferred program then press GREEN button to set the favorite program, a heart-shaped symbol will appear and the program is marked as a favourite, again press GREEN button it will cancel this favorite program, and the 5.3 Program Edit heart –shaped symbol will disappear.

  • Page 14: Epg (Electronic Program Guide)

    Press UP/DOWN button to select the program you would like to move. (2) Delete a TV or Radio Program Press YELLOW button to toggle this program, and press UP/DOWN button to move to 1. Select the Program and then press the RED button, A message will appear. Press OK the position you preferred.

  • Page 15: Table Of Contents 6.1.2 Dtv Manual Tunning

    6.1.1 Auto Tunning To access the Auto Tunning, the Menu provides options for auto tunning settings. Press 6 Basic Setting UP/DOWN to select the option. Press OK button to start the tunning, press EXIT to exit 6.1 Channel Setting the menu. 6.1.2 DTV Manual Tunning To access the Channel Menu, press MENU button then press RIGHT/LEFT button to select [Channel].

  • Page 16: Sort By

    6.1.5 Sort by EXIT to exit the menu. If you want to sort programs, you may access the [Sort by], press EXIT to exit the menu. 6.1.6 Signal Information 6.2 PICTURE setting If you want to view signal information, you may access the [Signal Information], press To access the Picture Menu, press MENU then press LEFT/RIGHT button to select EXIT to exit the menu.

  • Page 17: Tv System

    [16:9 Pan Scan]: for 16:9 format TV; 6.2.1 TV System [16:9 Pillarbox]: for 16:9 format TV; If the video does not appear correctly, you need to change the settings. This should match [4:3 Pan & Scan]: for 4:3 format TV; the most common setting for TVs in your country.

  • Page 18: Sound Setting

    6.3 SOUND setting To access the Sound Menu, press MENU then select [SOUND]. The Menu provides 6.3.1 Balance options to adjust the sound settings. Press UP/DOWN to select an option. Press EXIT to exit the menu. To access the Balance Menu, select [Balance] to press OK button. The Menu provides options to adjust the sound balance settings.

  • Page 19: Time Setting

    6.4.1 Auto Sync 6.4 TIME setting Set the time sync setting 6.4.2 Clock To access the Time Menu, press MENU then select [TIME]. The Menu provides options to adjust the time settings. Press UP/DOWN to select an option. Press EXIT to exit the Display the current clock time 6.4.3 Time Zone menu.

  • Page 20: Sleep Timer

    6.4.6 Sleep Timer If you want to use the Sleep Timer, you need set the Sleep Timer manually. To access the sleep timer Menu, select [Sleep Timer] to press OK button. Press EXIT to exit the menu. 6.4.5 Auto Sleep To set the Auto Sleep mode, select [Auto Sleep] to press OK button to set auto sleep mode.

  • Page 21: Antenna Power

    6.5.3 Subtitle Language 6.5.6 PVR Function To access the Subtitle Language setting Menu, select [Subtitle Language] to press OK To access the PVR Function setting Menu, select [PVR Function] to press OK button. The button. The Menu provides options to adjust the Subtitle Language settings. Press EXIT Menu provides options to adjust the PVR Function settings.

  • Page 22: Lock System

    6.6.2 Set Password Set or change the password for system. Enter your old password or the default password '0000'. You will then be asked to enter your new password. To confirm re-enter your new password. Once it is confirmed, press EXIT to exit the Menu. 6.6.3 Block Program To lock or unlock programs, select [Block Program] to press OK button.

  • Page 23: Media Player

    7.1.2 Movie Setup 7.1 Media Player - Subtitle Specific: set subtitle specific in normal, small or big mode. if no USB device plugged into it, a warning message "Not Find Any Device" displays, - Subtitle BG: set subtitle BG in Gray, white, Transparent or YellowGreen mode. otherwise you can select the Movie, Music ,Photo or other type in this menu and press - Subtitle FontColor: set subtitle font color in Red, Green or Blue mode.

  • Page 24: Photo Setup

    7.1.3 Photo Setup -Slide Time: adjust slide show interval to off, 5, 10, 15, 20 or 30 seconds . -Slide Mode: adjust slide show effect as mode 1~60.

  • Page 26: Troubleshooting

    8 Troubleshooting suddenly or mosaic Problem Potential Reasons What to do No picture Power isn't connected Connect the power The power switch is not on Switch on the power Screen shows Not connect DVB-T cable Plug in the DVB-T cable Incorrect setting Set up correct parameter No Signal...
  • Page 27 Resolution 1080P, 1080i, 720P, 720X576(PAL), 720X480(NTSC), 576P, 576i, 480P, 480i Decoding Aspect Rate 4:3(Letterbox, Pan& Scan)16:9 Video MPEG2 Transport MP@ML.HL MPEG4 AVC/H.264 HP@L4 Audio MPEG2 Audio Layer I&II Others Compliance DVB-T[EN300744], DVB-T2[EN302755] Sound Mode Right, Left, Stereo...
