Important safety instructions to be kept with the product
To prevent fire and electric shock, do not expose this receiver to rain or
moisture. In order to avoid any possible risk of electric shock, never
attempt to open the unit. In case of breakdown, reparation should be
made by qualified technicians. No part of this unit should be repaired by
users.
WARNING!
Presence of dangerous tension inside apparatus! Do not open. Risk of electric shock!
No part should be repaired by users. The maintenance of the receiver should be
carried out exclusively by qualified persons.
If the power cord is damaged, it must be replaced or repaired by the manufacturer, its
after-sales service, qualified electrician or persons of similar qualification in order to avoid
possible danger.
The product must be installed in accordance with national regulations.
The used batteries must be disposed of safely. Throw them in collection bins provided is
prohibited (inquire after your retailer for more details) in order to protect the environment.
Proper Installation
- Place the receiver on a flat, firm and stable surface. Do not put it on a carpet or rug.
- Do not place the receiver on top of another device, such as an amplifier. This may lead to
overheating.
- Do not put anything above the unit (for example, CDs or magazines).
Sufficient Ventilation
- Place the receiver in a well-ventilated location to prevent accumulation of internal heat.
Allow a gap of at least 10cm to the rear and the top of the unit, as well as a space of 5cm to
both sides to avoid overheating.
- Do not obstruct any ventilation openings with items such as newspapers, tablecloths,
curtains, etc.
Protecting the Receiver from High Temperatures, Humidity, Water and Dust
- The receiver should not be exposed to dripping water or splashing.
- No objects filled with liquids, such as vases, shall be placed on the unit.
- Do not place any objects that might damage your unit near it (e.g. liquid filled objects or
candles).
- Do not place any source of flames such as lit candles on the receiver.
- This receiver is to be used in a temperate climate and should not be used in a tropical
climate.
Electricity Supply
Please read attentively
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Denver DMB-119CI
Summary of Contents for Denver DMB-119CI
- Page 1 Important safety instructions to be kept with the product Please read attentively To prevent fire and electric shock, do not expose this receiver to rain or moisture. In order to avoid any possible risk of electric shock, never attempt to open the unit. In case of breakdown, reparation should be made by qualified technicians.
- Page 2 - Please unplug the receiver in case of prolonged non-use. - If the power cord is damaged, it must be replaced or repaired by the manufacturer, its after-sales service, qualified electrician or similar qualifications to those to avoid possible danger. - This device must be connected to a 240V ~ 50Hz electrical network.
-
Page 3: Table Of Contents
Contents 1. Installation of STB ......................6 1.1 Front Panel ........................6 1.2 Rear Panel ........................6 1.3 Connection ........................7 2. IR ............................9 2.1 Remote ........................... 9 3. Basic functions ........................10 3.1 First Installation ......................10 3.2 Volume adjustment and Mute ..................10 3.3 TV/RADIO programs switch ................... - Page 4 OSD Transparency ....................... 14 Preferred Subtitle ......................14 Hard Hearing ........................ 14 Preferred Audio ......................14 Multimedia ........................14 PVR Config ......................... 15 7. System Setting ......................... 15 7.1 Timers .......................... 15 7.2 Child Lock ........................16 7.3 Date Time ........................16 7.4 Common Interface .......................
- Page 5 10.7.1 E-Book browser ......................10.8 ISO..........................22 11. Upgrade ......................... 23 11.1 USB Upgrade ......................23 12. Troubleshooting ......................24...
-
Page 6: Installation Of Stb
1. Installation of STB 1.1 Front Panel : Switch between Standby mode and active mode. 2 CH-: Down channel 3 CH+: Up channel 4 On/off: Power lamp, red color in Standby mode, green color in active mode 5 IR : Receives the remote control signal 6 LED: Display the state and the channel number 1.2 Rear Panel 1. -
Page 7: Connection
4.TV SCART Connector Use this connector to connect your receiver to your video recorder using a SCART cable. Your video signal will now be looped through your receiver to your TV set. 5. SCART VCR Connect the external video input 6. - Page 8 connector at the back of the receiver. 1.3.2 Connecting to TV 1. Connect the scart connectors at the back of the receiver to the scart connectors on your TV set. Connect the HDMI connector at the back of the receiver to the HDMI connector on your TV set.
-
Page 9: Remote
2. IR 2.1 Remote 1、 『STANDBY』 switch of power supply 2、 『RECALL』return to upper menu or previous program palyed. 3、 『AUDIO』 audio pid switch and left/right channel 4、 『MUTE』 mute control 5、 『TV/RADIO』 TV/RADIO switch 6、 『FAV』 enter channel/Fav list 7、... -
Page 10: Basic Functions
3. Basic functions 3.1 First Installation First installation shall setup some important configures. User can select OSD Language、 Country、 Time Zone、 Active Antenna and LCN from this menu，when it is set completely，User can use “Start Search”to search channels. 3.2 Volume adjustment and Mute 1. -
Page 11: Audio Language Switch And L/R Channel Switch
3.8 Audio language switch and L/R channel switch Press “AUDIO” key to switch the language of sound of current programs and switch among “stereo” “left” “right”(stereo left channel right channel). 3.9 Electronic programs guide (EPG) 1. You can press key “EPG” on the remote controller to enter into the EPG page to know more about the programs to be played. -
Page 12: Installation
4. Installation Please input its password (0000) when entering into installation menu each time. Auto Search Auto search will scan all frequency and all programs based on your country setting. Manual Search Manual Search is for someone who know about how to select the exact frequency to scan. Channel Filter All channels or only unencrypted channels are set to be searched by selective settings. -
Page 13: Channel
5. Channel Channel Manager Channel manager page includes channel deleting, moving, locking and rename. Favorite List 1. As shown in the figure below via “Main menu->channel-> Favorite list” 2. User can set channel favorite list. -
Page 14: Preference Setting
6. Preference Setting OSD Language User can select OSD language OSD Tiemeout User can select OSD Timeout 6.3 OSD Transparency User can adjust OSD Transparency Preferred Subtitle User can set 1 and “2 Preferred subtitle language. Hard Hearing Enables/Disables the “hearing impaired” 6.6 Preferred Audio User can set 1 and “2... -
Page 15: Pvr Config
PVR Config It contains six options as fallow： 1、 PVR File Format： Either of options, TS/PS 2、 File Size： Any of options, 4G/3G/2G/1G, can be selected to set the size of the file to be recorded 3、 Timeshift： Any of options, AUTO/OFF/ PAUSE, if AUTO is selected, timeshift operation will perform automatically on the background, if OFF is selected, timesshift operation will stop;... -
Page 16: Child Lock
Date：Specifies the timer date Program Name：Specifies the channel for which the timer is set Start time：Specifies the start time of the timer End time：Specifies the end time of the timer，be used in Recorder Type Duration：Specifies the duration time of the timer，be used in Recorder Type Mode：Specifies the frequency of the timer. -
Page 17: Av Setting
8. AV Setting TV setup provides convenient TV input mode, as shown in Figure 8.1 SPDIF Used to select AVC mode –Mute，PCM and Bitstream 8.2 Aspect Ratio Aspect Ratio can be set as 16: 9, 4: 3PanScan, 4: 3LetterBox，Full Screen； 8.3 Video Output Video Output can be set as RGB, CVBS;... -
Page 18: Multi-Media
10. Multi-Media 10.1 MOVIE 10.1.1 Movie file browser Supported file formats are MPG, AVI, VOB, DAT, ASF, MKV, RM, WMV, TS, QT. 10.1.2 Movie playback Key Stroke Action KEY_PREV Shall stop this movie and play the previous movie in the list. KEY_NEXT Shall stop this movie and play the next movie in the list. -
Page 19: Music
10.2 MUSIC WMA, WAV, AAC,and MP3 format will be supported. Key Stroke Action KEY_PREV play the previous music KEY_NEXT play the next music KEY_PLAY play current music KEY_PAUSE pause music KEY_STOP stop the music KEY_FWD fast forward the music KEY_REV fast reverse the music the highlight shall change to the corresponding item according KEY_NUM... -
Page 20: Photo Playback
Key Stroke Action KEY_ENTER press the key will play the selected photo. press KEY_RECALL shall return from file list to filter selection KEY_RECALL mode. the highlight shall change to the corresponding item according KEY_NUM to the input number KEY_YELLOW Shall show thumbnail menu. 10.3.2 Photo playback Key Stroke Action... -
Page 21: Recorder Manager
Key Stroke Action KEY_ENTER press the key will play the selected game. press KEY_RECALL shall return from file list to the filter KEY_RECALL selection mode. the highlight shall change to the corresponding item according KEY_NUM to the input number KEY_RED Change the type of game from native32 to NES 10.5 RECORDER MANAGER 10.5.1 Recorder manager browser... -
Page 22: Disk Manager Browser
10.6.1 Disk manager browser Key Stroke Action KEY_RED Show move/copy menu KEY_GREEN Show rename menu. KEY_YELLOW Delete the selected item 10.6.2 Move/Copy In Move/copy menu user can move file or folder from one side to other side. It also can copy the content at one side to other side. -
Page 23: Upgrade
KEY_STOP Stop the ISO and show the layout KEY_FWD Fast forward the ISO. KEY_REV Fast reverse the ISO. Switch to Zoom function,you can press KEY_REV and KEY_RED KEY_FWD to zoom in and zoom outt 11. Upgrade 11.1 USB Upgrade User copy the upgrade file into the USB device and plug into the device for software upgrade. -
Page 24: Troubleshooting
12. Troubleshooting There may be various reasons for the abnormal operation of the receiver. Check the receiver according to the procedures shown below. If the receiver does not work properly after checking it, please contact the dealer. Don’t open the receiver cover. This may cause a dangerous situation. Symptom Cause Remedy... - Page 25 Additional information is available at the technical department of your city. Importer: DENVER ELECTRONICS A/S Stavneagervej 22 DK-8250 EGAA DENMARK ALL RIGHTS RESERVED: COPYRIGHT DENVER ELECTRONICS A/S www.denver-electronics.com...
