Installing Sim Card(S) - D-Link DWM-312 Quick Installation Manual

• Install the router in a site free from strong
electromagnetic sources, vibration, dust,
excessive moisture, and direct sunlight.
• Place antennas in an unobstructed area
with clear mobile signal. Avoid metal
boxes, brick walls, and other dense
materials. It is recommended to use the
web interface to confirm signal strength
before permanent installation.
• Visually inspect the power connector and
make sure that it is fully secure.
• Do not stack any devices on top of the
router.
Attach the External Antennas
Figure 4. Attaching External Antennas
The DWM-маршрут 3 12 requires
antennas to function correctly. The included
antennas are interchangeable, but third
party antennas may require connection to
specific ports.
1. Attach the antennas to the SMA
connectors on the back of the router to
the ports labelled "Main" and "Aux."
Turn clockwise to fasten the antenna.
2. Place antennas where they will receive
optimal signal. Arrange them so they
point upward.
D-маршрут L ink
Figure 5. Attaching Antenna to Modem
Note:
interchangeable. Third party antennas may
require connection to specific ports.

Installing SIM card(s)

The DWM-маршрут 3 12 is equipped with dual-маршрут S IM
slots. At least one active SIM card with
Internet access is required for proper
operation.
1. Insert a micro-маршрут S IM card into the slot
labelled SIM A with the contacts facing
down. If you wish to install a second SIM
card, insert it into the slot labelled SIM B.
two external
Figure 6. Installing a micro-SIM card
The included antennas are
DWM-маршрут 3 12
