Roughneck 24925 Owner's Manual

22 GPM FUEL PUMP
OWNER'S MANUAL
WARNING:
Read carefully and understand all
INSTRUCTIONS before operating. Failure to
follow the safety rules and other basic safety
precautions may result in serious personal injury
Item# 24925
Thank you very much for choosing a Roughneck™ Product! For future reference, please
complete the owner's record below:
Model: _______________ Purchase Date: _______________
Save the receipt, warranty and these instructions. It is important that you read the entire manual
to become familiar with this product before you begin using it.
This machine is designed for certain applications only. The distributor cannot be responsible for
issues arising from modification. We strongly recommend this machine is not modified and/or
used for any application other than that for which it was designed. If you have any questions
relative to a particular application, DO NOT use the machine until you have first contacted
distributor to determine if it can or should be performed on the product.
For technical questions, please call 1-800-222-5381.
INTRODUCTION
PUMP: Electric self-priming rotary vane pump, equipped with by-pass valve and built-in filter
MOTOR: Asynchronous motor, single phase, 2-pole, closed type (Protection class IP55),
self-ventilating
The pump is designed to run on 120V, 60HZ power and supply a flow rate of up to 22 GPM (80
LPM) with diesel or light oils.
TECHNICAL SPECIFICATIONS
Voltage 120 Volts
Frequency 60 Hz
Power 540 Watts
Flow Rate 22 GPM
GENERAL SAFETY REGULATIONS
WARNING:
Read carefully and understand all INSTRUCTIONS before operating.
Failure to follow the safety rules and other basic safety precautions may result in serious
personal injury.
Save these instructions in a safe place and on hand so that they can be read when required.
Keep these instructions to assist in future servicing.
WARNING: The warnings, cautions, and instructions discussed in this instruction
manual cannot cover all possible conditions or situations that could occur. It must be
understood by the operator that common sense and caution are factors that cannot be built
into this product, but must be supplied by the operator.
1. Keep the work area clean and dry. Damp or wet work areas can result in injury.
2. Keep children away from work area. Do not allow children to handle this product.
3. Store idle equipment. When not in use, tools and equipment should be stored in a dry
location to inhibit rust. Always lock up tools and equipment, and keep out of reach of children.
4. Use the right tool for the job. Do not attempt to force small equipment to do the work of
larger industrial equipment. There are certain applications for which this equipment was
designed. It will do the job better and more safely at the capacity for which it was intended.
Do not modify this equipment, and do not use this equipment for a purpose for which it was
not intended.
22 GPM FUEL PUMP OWNER'S MANUAL
Inlet/Outlet 1in.
Max. Suction Lift 8 1/2ft.
Discharge 56 1/2ft.
Max. Total Head 65ft.
