Roughneck 37907 Owner's Manual

HEAVY-DUTY PISTON HAND PUMP
OWNER'S MANUAL
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other
basic safety precautions may result in serious personal injury.
Item # 37907
HEAVY-DUTY PISTON HAND PUMP OWNER'S MANUAL
Thank you very much for choosing a Roughneck™ Product! For future reference, please complete
the owner's record below:
Model: _______________ Purchase Date: _______________
Save the receipt, warranty and these instructions. It is important that you read the entire manual
to become familiar with this product before you begin using it.
This machine is designed for certain applications only. The distributor cannot be responsible for
issues arising from modification. We strongly recommend this machine is not modified and/or
used for any application other than that for which it was designed. If you have any questions
relative to a particular application, DO NOT use the machine until you have first contacted
distributor to determine if it can or should be performed on the product.
For technical questions, please call 1-800-222-5381.
WARNING:
Read carefully and understand all INSTRUCTIONS before operating.
Failure to follow the safety rules and other basic safety precautions may result in
serious personal injury.
Save these instructions in a safe place and on hand so that they can be read when required.
Keep these instructions to assist in future servicing.
TECHNICAL SPECIFICATIONS
Model 37907
Inlet/ Outlet 1in./ 3/4in.
Pumping capacity 24 gallons per 100 strokes
Delivery hose 3/4in. x 8ft.
Telescoping suction pipe 40in.
Fluid compatibility
If in doubt about compatibility of a specific fluid, contact supplier of fluid to check for any
adverse reactions to the wetted materials.
The pump is compatible with the following fluids:
• Diesel, Heptane, Kerosene, Stoddard Solvent, Light Oils, Mineral Spirits
Do not use the pump with the following fluids:
• Gasoline, Water, Sulfuric Acid, Naphtha, Methanol, Methyl Ethyl Ketone (MEK), Acetone,
Ammonia, Benzene, Bleach, Chlorine
WARNING:
This product should not be used for fluid transfer into aircraft. This
product is not suited for use with fluids for human consumption or fluids containing water.
GENERAL SAFETY REGULATIONS
WARNING:
Read and understand all instructions.
WARNING:
The warnings, cautions, and instructions discussed in this instruction
manual cannot cover all possible conditions or situations that could occur. It must be
understood by the operator that common sense and caution are factors that cannot be built
into this product, but must be supplied by the operator.
1. Keep the work area clean and dry. Damp or wet work areas can result in injury.
2. Keep children away from work area. Do not allow children to handle this product.
3. Store idle equipment. When not in use, tools and equipment should be stored in a dry location
to inhibit rust. Always lock up tools and equipment, and keep out of reach of children.
1 of 4
