- Page 1 C20W Series Signal Repeater User Manual PLEASE KEEP APPROPRIATELY AND CAREFULLY READ THIS USER MANUAL BEFORE INSTALLATION...
-
Page 3: Table Of Contents
The power supply voltage of repeater Ensure of grounding, waterproof and should meet the standards of security lightning protection when installing requirements the repeater The repeater should be installed and Do not open the repeater, maintain started by professionals or replace the components Keep the repeater away from heat source, do not install in a narrow space... -
Page 4: Package Content
3dBi Spring Antenna 1pc Product Description C20W series signal repeater, with the fashion and elegant shape design, delicate and exquisite appearance craftsmanship, while improving the quality of indoor mobile phone signals, it also adds a touch of fashion to the home, this positive attitude is exactly the beautiful pursuit of every happy family. -
Page 5: Connector Description
The structure is simple, easy to use and maintain. Low power consumption,low interference, stable performance. Connector Description Indoor Antenna Connector (SMA-F） 5V DC Power Connector 口。 Power Indicator Outdoor Antenna Connector （F-F） Display Description Band 8 or Band 5 Band 3 or Band 8 or Band 4... -
Page 6: Model List
C20W Series Signal Repeater Model List Model Uplink Downlink C20W-B1B3B8 890~915/1710~1785/1920~ 1980MHz 935~960/1805~1880/2110~2170 MHz C20W-B2B4B5 824~849 /1710~1755/1850~1910MHz 869~894/2110~2155/1930~1990 MHz C20W-B1B8 890 ~ 915 / 1920 ~ 1980 MHz 935 ~ 960 / 2110 ~ 2170 MHz C20W-B3B8 890 ~ 915 / 1710 ~ 1785 MHz... - Page 7 2) Install the antenna pole at the position where the signal is strongest, and fix the outdoor antenna. Pay attention that the antenna towards to base station as much as possible. 3) Connect the feeder, and wrap the joints tightly with waterproof tape to prevent water from entering.
- Page 8 C20W Series Signal Repeater 5) Connect the feeder of the spring antenna to the "INDOOR" port of the repeater. Note: If you want to increase the coverage, you can choose a wall-mounted antenna or a ommi antenna to install on the wall above the repeater.
-
Page 9: Maintenance
Maintenance Common Problems and Solutions Problems Reasonable Causes Solutions Screen and indicator lights Disconnect to power Check the power adapter and are off source power outlet and reconnect The network of sim card is Replace sim card or booster comply with that of signal booster After power on, the display is normal, but the coverage... - Page 10 Manufacturer: Guangdong Amplitec Tech Development Co.,Ltd Address: 4th Floor, 4th Building, No. 60 of Langbao West Rd, Chancheng Foshan, Guangdong China, 528000 Tel：0757-83308238，Fax：0757-83123923 Email：info@amplitec.cn Website：www.amplitec.net...
