- Page 1 User Manual of C15-WCDMA Repeaters Amplitec Corporation...
-
Page 2: Table Of Contents
User Manual of C15-WCDMA Repeaters CATALOGUE Chapter 1 Safety Warning ..................1 Chapter 2 Summary ....................2 Chapter 3 Specs and features .................. 3 3.1 Product descriptions ........................ 3 3.2 Features ........................... 3 System diagram ........................3 3.4 Electrical Specification ......................4 3.5 Mechanical Specification ...................... -
Page 3: Chapter 1 Safety Warning
User Manual of C15-WCDMA Repeaters Chapter 1 Safety Warning Users must follow the below principles: 1 Repeater should follow system requirement of communication equipment, assure good groundings and lightning protection. 2 The power supply voltage of repeater should meet the standards of security requirement;... -
Page 4: Chapter 2 Summary
Single band selective repeaters mainly applied in covering small blind and weak zones C15-WCDMA repeater is a good choice for weak signal area of WCDMA system ,such as VIP rooms , offices, houses, restaurants, apartments, packing, etc. -
Page 5: Chapter 3 Specs And Features
User Manual of C15-WCDMA Repeaters Chapter 3 Specs and features 3.1 Product descriptions (1) In Terminal: N- Female (2) LED: To monitor the status of power on/off and normal operation (3) Power Supply Terminal: External type AC-DC power supply (Operating voltage: 9 V/2A ) 3.2 Features... -
Page 6: Electrical Specification
User Manual of C15-WCDMA Repeaters 3.4 Electrical Specification Specification Item Downlink Uplink ARFCN 2110-2170 1920-1980 Maximum output (combined) ≥15dBm ≥15dBm Maximum Gain ≥65dB ≧20 dB ≦ 8dB （P-P） In band ripple Noise Figure(Uplink) ≤ 6.0 Group Delay ≤1. 5µs Inter-modulation &... -
Page 7: Appearance Diagram
User Manual of C15-WCDMA Repeaters 3.6 Appearance Diagram 3.7 Ports... -
Page 8: Chapter 4 Installation
Chapter 4 Installation 4.1 Installation requirements C15-WCDMA repeaters are mainly applied as indoor coverage WCDMA system. After connection of equipment and antenna, the distance of them should be keep as far away as possible, it’s better that there is a wall as the obstruct between them. -
Page 9: Connection
User Manual of C15-WCDMA Repeaters component 2 component 1 Installation step 2 Installation step 3 Installation Steps: 1: Use percussion drill to make four Φ6 holes on the wall according to above hole diagram, fas Installation step ten component 1 onto the wall. -
Page 10: Chapter 5 Repeater Setting
User Manual of C15-WCDMA Repeaters Chapter 5 Repeater setting Please check whether the connection of RF cable is correct (donor antenna connected to BTS port, service antenna connected to MS port), and whether every port is stable. After affirmation, please go along the followings: 5.1 Power supply connection... -
Page 11: Performance Setting
User Manual of C15-WCDMA Repeaters 5.2 Performance setting Curve chart of equipment working condition Output Power Edge Point input Power Green: Linear Red: Orange: amplification Overloading stable Picture 3: Curve of output power, input signal and attenuation value output power... -
Page 12: Chapter 6 Produce Maintenance
User Manual of C15-WCDMA Repeaters Chapter 6 Produce Maintenance 6.1 Operation and maintenance Power supply Please make sure the voltage and frequency comply with the repeater requirement. Component replacement Please do not maintain or replace components by yourself, otherwise may get an electric shock.
