USER'S MANUAL

4. CONNECTION PANELS - DESCRIPTION

4.1

INPUT SIGNALS

1
1. SPEAKERS IN hi-level MASTER input
Ch1 - Ch2 - Ch3 - Ch4 - Ch5 - Ch6 - Ch7 - Ch8 - Ch9 - Ch10 - Ch11 - Ch12
HI LEVEL MASTER inputs to connect the amplified signal wires coming from the main analog
source. Input sensitivity automatically adjustable from 2 to 15 V RMS
Channels Ch1 - Ch2 feature the AUTO TURN ON (ART) function through the connection with the source
speakers outputs. This function can be excluded using the PC software
The input signals are interfaced to the bit One HD via wiring with a multi-pin 24 poles connector as
described below.
FRONT VIEW
1 13
2 14
3 15
4 16
5 17
6 18
7 19
8 20
9 21
10 22
11 23
12 24
200 mm / 7.87 in.
Wire Size: AWG
Remark:
when connecting a speaker input cable, use Faston crimp terminals.
4
(see section 5.5)
2
(see sec. 7.4.3)
(see section 7.4.1)
10 mm / 0.39 in.
bit One HD /
3
.
.
MASTER INPUTS
1: white
13: gray
2: white
14: gray
3: white
15: gray
4: white
16: gray
5: white
17: gray
6: white
18: gray
7: white
19: gray
8: white
20: gray
9: white
21: gray
10: white IN10+
22: gray
11: white IN11+
23: gray
12: white IN12+
24: gray
4
IN1+
IN1-
IN2+
IN2-
IN3+
IN3-
IN4+
IN4-
IN5+
IN5-
IN6+
IN6-
IN7+
IN7-
IN8+
IN8-
IN9+
IN9-
IN10-
IN11-
IN12-
5
