Audison bit one Frequent Asked Questions

Audison bit one Frequent Asked Questions

Signal interface processors
Hide thumbs Also See for bit one:

Advertisement

Quick Links

question type
We have some problems with the Bit One turning on/switching off.
As indicated in the manual, Bit One could be activated or disactivated
Turning on/
pressing (for a few seconds) the DRC knob. Once the product is
switched off, if you press the DRC knob you can't turn it on again by
Switching off
means of the DRC. To turn on the unit again by means of the DRC, it is
necessary to disconnect KEY MEM and KEY ON-OFF.
Loud "POP" sound when turning on/switching off
Using the remote input and output you can hear a loud noise (bump) in
the speakers switching off the source
configuration
Failing or mistake in the parameters finalization
The Bit One doesn't work correctly once it is switched off and turned on
Acting on the Master Volume and on the Subwoofer Level there is no
After selecting MUTE in the "DSP SETTING" CHANNEL MAP, if the
"EXT. SOURCE EQ" is selected, MUTE automatically disactivates and
the sound comes out.
MUTE is still selected, both in the CHANNEL MAP and in the "OUTPUT
LEVEL", but the sound continues to be present.
When MUTE is re-activated after disactivating it, the silence condition
Bii One has been correctly installed and configured by means of the I/O
configuration wizard and then disconnected from the PC and switched
off. After turning on again the Bit One, it doesn't work
Elettromedia srl
FREQUENT ASKED QUESTIONS
question
again.
volume variation
operates correctly.
The DRC must be connected to the Bit One by means of the AC Link 1 (DRC) socket and not by means of the AC Link 2 (AMPS)
socket. Furthermore the KEY MEM and KEY SWITCH ON OFF must not be used at the same time and not even with the function
The problem could be present on some pieces with the first software versions. In this case it is necessary to proceed with the
updating of the Bit One PC firmware and software, available on the web site: http://update.audison.eu
To not hear the bump during the switching off of the source, the amplifiers must be switched off before the Bit One. The correct
1) The source is switched off disactivating the REM OUT output, that is connected with the BIT ONE REM IN.
2) The Bit One starts its switching off sequence disactivating its REM OUT. This makes the amplifier silent and it switches it off.
3) After 2 seconds the Bit One is switched off.
If during the Bit One regulation by means of the PC, the Bit One is switched off or turned on, the PC USB connection looses
sychronisim. If the Bit One switches off during the connection process with the PC it is necessary to disconnect from the PC
program and relaunch it to restore the comunication synchronism.
If during the Bit One programming phase by means of the PC the product doesn't answer the controls, it is necessary to switch off
the Bit One switching off the source or the DRC. If, after this action, you can't switch off the Bit One it is necessary to disconnect
the power source and then reconnect it. Once the Bit One is switched off it is necessary to turn it on again and then redefine the
synchronism disconnecting and reconnecting the management program by means of the PC
Probably setting the I/O wizard configuration, some "set AC-LINK provided amplifier" flags have been set on the outputs. In this
way the Bit One analogic outputs volume always remain 0dB because the volume adjustment is committed to the amplifiers with
AC-LINK that the software considers connected after the processor once set the flag.
To restore the situation it is necessary to redo the setting procedure being careful that the "set AC-LINK provided amplifier" flags
The problem can be temporarily over come disactivating and re-activating MUTE. The problem can be solved updating the
software and firmware available on the web site http://update.audison.eu . The modification is present from version 1.4 of the PC
Be careful: to not loose the configuration work done it is necessary to "finalize" it on the Bit One by means of the function "finalize
to Bit One" from the PC software File menu
1/3
answer
REMOTE IN
sequence is:
aren't selected.
management software.
rev 00

Advertisement

loading
Need help?

Need help?

Do you have a question about the bit one and is the answer not in the manual?

Questions and answers

Summary of Contents for Audison bit one

  • Page 1 As indicated in the manual, Bit One could be activated or disactivated The DRC must be connected to the Bit One by means of the AC Link 1 (DRC) socket and not by means of the AC Link 2 (AMPS) Turning on/ pressing (for a few seconds) the DRC knob.
  • Page 2 PC work with its battery, keeping it disconnected from the network power supply at least when the portable PC is connected to the Bit One by means of the USB. Once the connection is stable it is possible to connect the portable PC by means of the power supply without creating problems.
  • Page 3 How must the KEY-MEM and KEY ON-OFF be used? (for example by means of the DRC), the Bit One will not turn on at the next turning on of the vehicle. Instead, if the Bit One is on features use when the user stops the vehicle and takes out the key, it willl turn on again when the vehicle will be turned on next time.
