Nitto Kohki CIRCUIT BEVELER CB-01 Instruction Manual

INSTRUCTION
MANUAL
[Specifications]
Maximum operating pressure
Air consumption (No load)
Rated speed (No load)
Mass (weight)
Sound pressure level *1
Sound power level *1
Vibration level [Uncertainty K] *2
Chamfering capacity
Chamfer angle
Minimum workpiece thickness
Thread size of Air Inlet
Based on the ISO 15744 measurement standard.
*1
Based on the ISO 20643 measurement standard for the 3-axis composite value
*2
of frequency-weighted acceleration effective values in hand-held tools.
 Please read manual carefully before you attempt to use your tool so that you may use it 
properly and safely.
 Keep the manual handy – so you can use it whenever necessary. 
• Due to continuous product development/improvement, the specifications and configurations in
this document are subject to change without prior notice.
Manufactured by.
NITTO KOHKI CO., LTD.
Professional tool
Model: CB-01
Model
m
dB(A)
dB(A)
9-4, Nakaikegami 2-chome, Ohta-ku, Tokyo, 146-8555, Japan
Tel : +81-3-3755-1111 Fax : +81-3-3753-8791
PNEUMATIC CHAMFERING TOOL
CB-01
MPa 0.6
3 /min 0.15
min -1 28000
kg 0.5
88
99
≦
m/s 2 2.5 (1.8 [0.67])
Mild steel: 0 to C1
Stainless steel: 0 to C0.5
Aluminum: 0 to C1
45°
mm 1.5 (C0.5)
Rc 1/4
(Original instructions)
TQ13632-2
