AIR HAMMER
Please read this manual carefully before you attempt to use
your tool so that you may use it properly and safely.
AUTO CHISEL
PROFESSIONAL TOOL
Maximum Operating Pressure
Air Consumption (No Load)
Rated Speed (No Load)
Sound Pressure Level
Sound Power Level
Vibration Level
Chisel Shank Dia.
Mass (Weight)
Thread Size of Air Inlet
Due to continuous product development/improvement the specifications and configurations in this
document are subject to change without prior notice.
Keep the manual handy – so you can use it whenever necessary.
Specifications
Model
Model A-300
A-300
0.6 MPa
3
0.3 m
/min
2600 min
-1
97 dB(A)
108 dB(A)
≧ 30 m/s
2
10 mm
1.7 kg
Rc1/4
Manufactured by :
NITTO KOHKI Co., Ltd.
2-9-4, Nakaikegami, Ohta-ku,
Tokyo, 146-8555, Japan
TEL
: (81)-3-3755-1111
FAX : (81)-3-3753-8791
E-mail : overseas@nitto-kohki.co.jp
URL : www.nitto-kohki.co.jp
Original Instructions
TQ12831-1
Advertisement
Table of Contents
Related Manuals for Nitto Kohki A-300
Summary of Contents for Nitto Kohki A-300
- Page 1 Thread Size of Air Inlet Rc1/4 Due to continuous product development/improvement the specifications and configurations in this document are subject to change without prior notice. Manufactured by : NITTO KOHKI Co., Ltd. 2-9-4, Nakaikegami, Ohta-ku, Tokyo, 146-8555, Japan : (81)-3-3755-1111 FAX : (81)-3-3753-8791 E-mail : overseas@nitto-kohki.co.jp...
-
Page 2: Table Of Contents
CONTENTS page Thank you very much for your purchase of this IMPORTANT SAFETY INSTRUCTIONS …………………… 2 Nitto Kohki products. GENERAL: TOOLS …………………………………………… 2 Before using your tool, please read this manual GENERAL: PNEUMATIC TOOLS ………………………… 3 carefully so that you may use it properly to get INSTRUCTIONS FOR THIS TOOL …………………………... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY BEFORE OPERATION INSTRUCTIONS Inspect tool before use. ● Before using, check that screws are securely When using the tool, please observe the safety tightened, that any protective cover or guard is precautions below to prevent possible accident or injury. GENERAL: TOOLS securely in place, other parts are free from damage and that the tool runs as it should. -
Page 4: General: Pneumatic Tools
● When a label/nameplate gets damaged, worn or becomes missing, contact the sales agent through which you have purchased your tool or Nitto Kohki Co. Ltd, directly for a replacement. DISPOSAL When a tool is taken permanently out of service, it is... -
Page 5: Instructions For This Tool
4. PREPARATIONS parts, please contact the sales agent from whom you purchased the tool. WARNING Package Contents Qty Check A-300 Turn off the air supply and disconnect the air hose Bushing R1/4×NPT1/4 before preparation for use. Hose Nipple R1/4×1/4 Instruction Manual 4-1. -
Page 6: How To Operate The Tool
5-2. To prevent the chisel jumping (Fig.5) the tool. To prevent the Chisel jumping (Fig.5) Bushing (M16×Rc1/4) First, grasp the grip and place the Chisel to the work. Gradually press the Trigger and 90 to full operation after the cutting position has been determined. The Chisel should not jump off the work. -
Page 7: Type Of Chisels And Their Applications
No.1012 Bending Chisel 10. TYPE OF CHISELS AND THEIR APPLICATIONS Helps the serviceman in peeling and Please order with the chisel numbers below. removing slag around welds. No.1001 Blank Chisel No.1013 Fork Chisel 24 Bending iron plate, removing king pins. Disconnecting tie rod ends and ball joints. - Page 8 Lerchenstr.47 D-71144 Steinenbronn, Germany Tel: (49)-7-157-22436 Fax:(49)-7-157-22437 NITTO KOHKI CO., LTD., SHENZHEN REPRESENTATIVE OFFICE NITTO KOHKI CO., LTD., SINGAPORE BRANCH 2005C Shenzhen ICC Tower, Fuhuasanlu 168, Futian District, 10 UBI CRESCENT #01-62, Shenzhen, Guangdong, 518048 China UBI TECHPARK LOBBY D, SINGAPORE 408564,...
