DDI-9E INSTALLATION AND OPERATION MANUAL
*
If a zone number is not used in a configuration, the Syst em 3000 will skip a line when it prints the table.
In Table 7.3.2(a) zones 09 and 10 are not used, hence the em pty r ow in the table.
DIGITIZE, INC 700236-0001 REV. A
Table 7.3.2.(a)- Configuration # 1
Zone Factory Default Settings
ZONE ALM
01 01
02 02
03 03
04 04
05 05
06 06
07 07
08 08
*
11 --
12 --
13 --
14 --
15 --
16 --
17 --
18 --
Table 7.3.2.(b) - Configuration #1
English Equivalent Factory Default Settings
PROCESS
DAILY TEST
SECURE ALL
OPENING
CLOSING
AC FAILURE
AC NOW OK
LINE 1 FAULT
LINE 1 OK
GROUND FAULT
GND NOW OK
BATTERY FAIL
BATTERY OK
LINE 2 FAULT
LINE 2 OK
DATA LOSS
TBL SEC
-- 21
-- 22
-- 23
-- 24
-- 25
-- 26
-- 27
-- 28
61 71
62 72
63 73
64 74
65 75
66 76
67 77
68 78
FOR
30
--
--
--
60
70
31
35
33
37
69
79
--
--
--
2-5
