DDI-8 INSTALLATION AND OPERATION MANUAL
The DDI-8 has five field addressable switch settings to designate dialer board numbers. The
switches operate on binary code system. The DDI-8 ( System 3000 ) will recognize any number
from one to 31. Do not use zero!
For example, to designate the DDI-8 board as No. 12, turn both SW3 and SW4 to OFF. SW3 = 4
and SW4 = 8. SW3 (4) + SW4 (8) = Board Number (12). Do not duplicate board numbers!
Each card should be assigned a different number. Refer to the table below:
Board
Number
00
01
02
03
04
05
06
07
08
09
10
Note: The digit '1' indicates an 'ON' switch.
CAUTION ! If you are using a network with several DDI-8 cards it is imperative
that you do NOT duplicate card numbers in any SYSTEM 3000.
Switch number 6 is used to select the DDI-7/8 mode. On SYSTEM 3000 units with Program
S600 Standard 6 software version or higher, the factory default setting for SW6 is ON. (For
units with other software versions or CPU V refer to Section 4 Retrofits.)
Switch number 7 is reserved for system self-test. The DDI-8 default setting is OFF, (enabling
the partial diagnostic test mode.) If SW7 is changed to ON, the full diagnostic test mode is
enabled. Refer to table below.
T ab le 7.2 (b )- D D I-8 S w itch S ettin gs (W ith C P U V I)
S w itch
N u m b er
7
6
1 - 5
DIGITIZE, INC. 700208-C
Table 7.2 (a)- Card Address Switch Settings For DDI-8
Switch Board
5 4 3 2 1 Number
N/A 11
0 0 0 0 1 12
0 0 0 1 0 13
0 0 0 1 1 14
0 0 1 0 0 15
0 0 1 0 1 16
0 0 1 1 0 17
0 0 1 1 1 18
0 1 0 0 0 19
0 1 0 0 1 20
0 1 0 1 0 21
W h en 'O N '
E nables full diagno stic test
M ust be O N
C ard address 1 - 1FH (as needed)
DDI-8 SWITCH SETTINGS
Switch Board
5 4 3 2 1 Number
0 1 0 1 1 22
0 1 1 0 0 23
0 1 1 0 1 24
0 1 1 1 0 25
0 1 1 1 1 26
1 0 0 0 0 27
1 0 0 0 1 28
1 0 0 1 0 29
1 0 0 1 1 30
1 0 1 0 0 31
1 0 1 0 1 --
W h en 'O F F'
P artial diagno stic test
N o t applicable
SECTION 2
Switch
5 4 3 2 1
1 0 1 1 0
1 0 1 1 1
1 1 0 0 0
1 1 0 0 1
1 1 0 1 0
1 1 0 1 1
1 1 1 0 0
1 1 1 1 0
1 1 1 1 0
1 1 1 1 1
--
2 - 1
