DDI-8 INSTALLATION AND OPERATION MANUAL
WARNING ! There are many variations of generic dialer format. Due to the lack
of industry standards governing Digital Dialer decoding, the Customer must
thoroughly test and verify the proper operation of every dialer connected to the System
3000. Digitize, Inc. did not rely on Manufacturer's information regarding their
protocols when developing the DDI-8 interface. A Manufacturer may have made
changes to protocols without our knowledge. Digitize, Inc. is not responsible for
incompatible dialer formats.
The DDI-8 card processes dialer Alarm, Trouble and Restore conditions. The SYSTEM 3000
displays and prints the incoming DDI-8 signals. The user can specify Restoral = Yes or No for
each account number. After an alarm or trouble condition appears, the CLEAR button will
blink if an invalid account number comes through or if Restoral = N for that account number.
In this instance the operator can hit the CLEAR button when the light is blinking and the
condition will be cleared. If the dialer has a restoral feature, the user would select Restoral = Y,
and the dialer would send a restoral automatically.
If an abnormal condition occurs (i.e. the dialer is reset and no restoral will be received) the
operator may also clear the condition as follows: While the dialer message is on the display,
press DIALER LOOK UP. While the display reads "DD xxx-x pg. 1", press CLEAR to
remove the dialer Alarm or Trouble condition.
If the Alarm monitoring location subscribes to Caller ID, the following information is printed
after the first ring is received.
If the Caller ID information is being blocked by the calling party, the following information
will print:
If the calling party is out of the Caller ID service area, the following information will be printed:
Information regarding Caller ID availability in your area can be obtained from your local
telephone carrier.
NOTE: During System Initialization the following message may appear:
This message appears only if the System 3000 finds data in the one digit (123-8) format. When
the operator selects '1', the System 3000 will automatically convert the information to the two
digit (123-08) format.
1- 2
CALL ID - Area Code -Phone Number
Date - Time
CALL ID - Blocked
Date- Time
CALL ID - Out of Area
Date - Time
UPDATE DIALER
USER TEXT I.E.
123-8 TO 123-08
1=YES 2=NO ENTR
