DIGITIZE SYSTEM 3000 Conversion Manual

Hide thumbs Also See for SYSTEM 3000:
Table of Contents

Advertisement

Quick Links

Download this manual
SYSTEM 3000 to SYSTEM 3505
CONVERSION MANUAL
Digitize, Inc.
158 Edison Road
Lake Hopatcong, New Jersey 07849-2217
Tel:
(973) 663-1011
Fax:
(973) 663-4333
E-mail:
info@digitize-inc.com
Website:
http://www.digitize-inc.com
Part Number:
700254-0001
Revision:
B
Issue Date:
02/04

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SYSTEM 3000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DIGITIZE SYSTEM 3000

Summary of Contents for DIGITIZE SYSTEM 3000

  • Page 1 SYSTEM 3000 to SYSTEM 3505 CONVERSION MANUAL Digitize, Inc. 158 Edison Road Lake Hopatcong, New Jersey 07849-2217 Tel: (973) 663-1011 Fax: (973) 663-4333 Part Number: 700254-0001 E-mail: info@digitize-inc.com Revision: Website: http://www.digitize-inc.com Issue Date: 02/04...
  • Page 2 Digitize, Inc. 158 Edison Road Lake Hopatcong, NJ 07849-2217 The Digitize logo (stylized) is a registered trademark of Digitize, Inc.
  • Page 3 E-Mail: info@digitize-inc.com Website: http://www.digitize-inc.com This manual has been prepared by DIGITIZE, INC. for use by its licensees, distributors and customers. The information contained herein is the property of DIGITIZE, INC. and may not be copied, disclosed or reproduced, in whole or in part, without the prior written approval of DIGITIZE, INC.
  • Page 4 FCC NOTICE In compliance with Paragraph 15.105 of the FCC Rules and Regulations, the following notice is provided. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 5: Table Of Contents

    1.0 Preparation for SYSTEM Upgrade ........1-1 1.1 Tools......................1-1 1.2 PCB Rework....................1-1 1.3 Preparing the SYSTEM.................1-1 2.0 SYSTEM 3000 disassembly ..........2-1 3.0 3505 ASSEMBLY ..............3-1 3.1 BRACKET LOCK ASSEMBLY ..............3-1 3.2 PRINTER MECH SLIDE ASSEMBLY ............3-2 3.3 FISH PAPER INSTALLATION ..............3-3 3.4 PRINTER SLIDE AND 3505 FRONT PANEL ASSEMBLY .....3-4...

  • Page 7: Preparation For System Upgrade

    3505 24 X 2 page format. SYSTEM 3000 with CPU5 configuration can not be saved with WIN 3505. SYSTEM 3000 with CPU5 will require a new EE2 PROM Board 400349-0003 for MEM-600 chips. The 3000 CPU5 400349 board will not work in a SYSTEM 3505.
  • Page 8 SYSTEM 3000 to 3505 CONVERSION MANUAL Remove all optional configuration cards, mounting hardware and power plug. (Refer to FIG2). Note which Port # each configuration card was in. Save the hardware to re-install configuration cards on the new rear panel, Step 3.8.3.

  • Page 9: System 3000 Disassembly

    SYSTEM 3000 to 3505 CONVERSION MANUAL 2.0 SYSTEM 3000 Disassembly FIG 1a FIG 2a 2.1 Using a flat head screw driver, loosen the four screws holding the system cover in place. Refer to FIG 1a &2a 2.2 With the cover removed, pull the printer mechanism fully out. Then disconnect the printer MECH ribbon and power cable from the printer card.
  • Page 10 SYSTEM 3000 to 3505 CONVERSION MANUAL 2.3 Unscrew the pan head stopping screw with hex nut and star washer then remove the printer MECH. Refer to 4a Stopping Screw FIG 4a 2.4 Remove the four pan head screws holding the printer MECH support bracket.
  • Page 11 SYSTEM 3000 to 3505 CONVERSION MANUAL 2.6 Remove the slotted screws holding the rear panel in place. To remove the rear panel, lift up to disengage it from the motherboard. Refer to FIG 7a & 7b REMOVE REMOVE LIFT UP FIG 7a 2.6.1 Remove any additional hardware if installed from the rear panel and save for...
  • Page 12 SYSTEM 3000 to 3505 CONVERSION MANUAL 2.7.2 Remove the three screws holding the CAP bracket in place. Refer to FIG 8c FIG 8a FIG 8b FIG 8c 2.8 Remove the Male Cabinet Latch by unscrewing the flat head screws located on the bottom of the system.
  • Page 13 SYSTEM 3000 to 3505 CONVERSION MANUAL 2.10 Then remove the 3 hex nuts located on the inside. Refer to FIG 10b. Save hex nuts for re-assembly. Remove front panel assembly. FIG 10b 2.11 The SYSTEM is now ready to be rebuilt. Refer to FIG 10c FIG 10c DIGITIZE, INC.

  • Page 15: 3505 Assembly

    SYSTEM 3000 to 3505 CONVERSION MANUAL 3.0 3505 ASSEMBLY 3.1 BRACKET LOCK ASSEMBLY 3.1.1 Attach the Male Cabinet Latch(Item 2) to the Bracket Lock(Item 1) using Two of each, 4-40x5/16 screws (item 3), #4 flat washer (item 4) and #4 lock washer (item 5).

  • Page 16: Printer Mech Slide Assembly

    SYSTEM 3000 to 3505 CONVERSION MANUAL FIG 1c PRINTER MECH SLIDE ASSEMBLY 3.2.1 To attach the female cabinet latch (item 11), to the slide bracket (item 12), use two each, 4-40x7/16 screws (item 2), #4 Split washer (item 3) and #4 flat washer (item 4). Refer to DWG 2.

  • Page 17: Fish Paper Installation

    SYSTEM 3000 to 3505 CONVERSION MANUAL 3.2.2 Slide the top rod, item 1, through the upper nylon insert, and the lower rod, item 11, into the bottom nylon insert. Refer FIG 1d FIG 1d NOTE: The slide rails ends are different thread sizes, with the larger #8 thread screwing on to the front panel, and the smaller #6 thread to the back of the chassis.

  • Page 18: Printer Slide And 3505 Front Panel Assembly

    SYSTEM 3000 to 3505 CONVERSION MANUAL FIG 2a 3.3.2 Remove the top 2 pan head screws and washers from the PWR side of the card cage. Attach the protective fish paper to the card cage using the 2 pan head screws and washers. See FIG 2b & 2c...
  • Page 19 SYSTEM 3000 to 3505 CONVERSION MANUAL FIG 3a FIG 3b 3.4.2 Rotate the rails to attach them to the front panel. Tighten the top rail by hand first, and then begin to tighten the bottom rail. Tighten securely. See FIG 3c FIG 3c 3.4.3 Attach the bracket lock to the rail, by tightening the 6-32x1.128 Socket...

  • Page 20: Rear Panel Assembly

    SYSTEM 3000 to 3505 CONVERSION MANUAL 3.4.4 Once the rails are in place, attach the front panel with the 8-32 Kept Nut on the inside upper right corner of the panel. Use 2, #6 flat head screws to attach the front panel from beneath the chassis. See FIG 3e & 3f...

  • Page 21: Card Installation

    SYSTEM 3000 to 3505 CONVERSION MANUAL 3.6 CARD INSTALLATIONS 3.6.1 Insert the new power supply card, in to the slot marked PWR, pressing firmly and evenly down, until it is seated on the motherboard. See FIG 5a. FIG 5a 3.6.1.1 Connect the Black, Green and White wire coming from the EMI Filter to JP1.
  • Page 22 SYSTEM 3000 to 3505 CONVERSION MANUAL 3.6.2 Insert the new DK3X00 card, into the slot marked DISP, pressing firmly and evenly down, until it is seated on the motherboard. See FIG 5d FIG 5d 3.6.2.1 Connect the Ribbon cable from the P2 location on the DK3X00 board, to the P3 location on the rear PC board.
  • Page 23 FIG 6a NOTE: At this time, any additional or optional cards (EPROM, ZCONT., etc.) are placed in to the card cage for SYSTEM 3000 with CPU5. Remove any MEM-600 chips from old EPROM card and install in new EE2 PROM card WARNING: Make sure the chips are installed in the same chip location on the new board (i.e., U1 to U1, U2 to U2, U3 to U3 …U8 to U8).

  • Page 24: Printer Mech Installation

    SYSTEM 3000 to 3505 CONVERSION MANUAL 3.7 PRINTER MECH INSTALLATION. 3.7.1 Pull the printer slide bracket to the front of the system, use the center hole and the protruding screw holder on the printer, to line up the screw holes for attaching the printer to the bracket.
  • Page 25 SYSTEM 3000 to 3505 CONVERSION MANUAL 3.7.3 Attach the green and yellow ground wire to the upper left side of the card cage. See FIG 7c FIG 7c 3.7.4 Connect the printer power cable harness to P6 of the PRT/KB card and the printer ribbon cable to P3 of the PRT/KB card.

  • Page 26: Powering Up System 3505

    SYSTEM 3000 to 3505 CONVERSION MANUAL 3.7.6 Slide the printer in and out and look for any cables that may get caught or pinched. Secure the cables to the back of the printer and to the side of the card cage, with the cable clamps, to prevent damage. See FIG 7e FIG 7e 3.8 POWERING UP SYSTEM 3505...
  • Page 27 APPENDIX A PCB REWORK Before installation, turn on power to SYSTEM 3000. Check for 24 VDC at Pin 1 J6 Aux Port to chassis of rear panel to determine if you need to update (rework) the PCB. See Figure 1. If 24 VDC is not present, continue with the steps below. If the 24 VDC is present, continue with the T-Bar installation and disregard these instructions.
  • Page 28 SYSTEM 3000 to 3505 CONVERSION MANUAL Figure 2A – Backplane Assembly (P/N 400314) with Jumper from P1 Pin 6 to J16 Pins 7&8 Figure 2A – Backplane Assembly (P/N 400314) with Jumper through Feed Through to J16 Pins 7 & 8 DIGITIZE, INC.
  • Page 29 (4) any statements made about Digitize’s products by salesmen, dealers, distributors or agents, unless confirmed in writing by a Digitize officer. If the firmware or hardware is altered or modified by the Buyer, this firmware and hardware is not covered within this limited warranty and the Buyer bears sole responsibility and liability for that firmware and hardware.
