INSTALLATION AND OPERATION
MONACO D-5000
Digitize, Inc.
158 Edison Road
Lake Hopatcong, New Jersey 07849
Tel: (973) 663-1011
Fax: (973) 663-4333
E-mail:
info@digitize-inc.com
Website:
http://www.digitize-inc.com
MANUAL
SYSTEM 3505
to
INTERFACE
Part Number: 700273-0001
Revision: B
Issue Date: 04/07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SYSTEM 3505 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DIGITIZE SYSTEM 3505

Summary of Contents for DIGITIZE SYSTEM 3505

  • Page 1 INSTALLATION AND OPERATION MANUAL SYSTEM 3505 MONACO D-5000 INTERFACE Digitize, Inc. 158 Edison Road Lake Hopatcong, New Jersey 07849 Tel: (973) 663-1011 Part Number: 700273-0001 Fax: (973) 663-4333 Revision: B E-mail: info@digitize-inc.com Issue Date: 04/07 Website: http://www.digitize-inc.com...
  • Page 3 Digitize, Inc. 158 Edison Road Lake Hopatcong, NJ 07849-2217 The Digitize logo (stylized) is a registered trademark of Digitize, Inc.
  • Page 5 E-Mail: info@digitize-inc.com Website: http://www.digitize-inc.com This manual has been prepared by DIGITIZE, INC. for use by its licensees, distributors and customers. The information contained herein is the property of DIGITIZE, INC. and may not be copied, disclosed or reproduced, in whole or in part, without the prior written approval of DIGITIZE, INC.
  • Page 7 FCC NOTICE In compliance with Paragraph 15.105 of the FCC Rules and Regulations, the following notice is provided. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 9: Table Of Contents

    Table of Contents 1.1 SYSTEM DESCRIPTION ........................1 1.2 NEW CONFIGURATION ........................2 1.3 SOFT KEYS............................2 1.4 ZID VS. ZONE NUMBERS ........................ 2 1.5 INTERROGATING ..........................3 1.6 STATUS PRINTOUT ALL CONDITIONS ..................5 1.7 DAILY TEST ............................5 1.8 ADD/CHANGE/DELETE BT-2 BOXES ....................

  • Page 13: System Description

    Alarm, Trouble or Restore conditions. If left alone, the alarms will process as soon as the data link is restored. If the SYSTEM 3505 was asleep prior to the link fault, it will go back to sleep when the link restores, providing you did not press the CLEAR key.

  • Page 14: New Configuration

    Troubles and Restoral conditions will be processed by the SYSTEM 3505. The SYSTEM 3505 unit also allows the user to Add, change or delete BT units, as well as control the interrogation of any BT. Interrogation of all the BT units can also be initiated by the SYSTEM 3505 1.3 SOFT KEYS...

  • Page 15: Interrogating

    Simply press the soft key to initiate the interrogation. Enter 1 1, then press the Interrogate key (for BT #11) Printout illustrates successful interrogation of BT #15 Printout illustrates no response from BT #15 DIGITIZE, INC. 700273-0001 Rev. B Specifications Subject to Change Without Notice...
  • Page 16 BT unit. BT has an existing Alarm, Trouble, BAT, AC or Tamper condition. Although the Monaco system provides the SYSTEM 3505 with an ongoing status of the condition at the BT panel, you can always interrogate a BT unit to make sure the information presented at the SYSTEM 3505 is correct.

  • Page 17: Status Printout All Conditions

    KEY SELECT key above the green AC POWER LED. Look for the soft key labeled “MONACO DLY TEST”. You should activate the daily test following either a restart of the SYSTEM 3505, or if the data line between the SYSTEM 3505 and the Monaco D-5000 has been disconnected for a period of time.

  • Page 18: Add/Change/Delete Bt-2 Boxes

    SYSTEM 3505 or uploaded from the WIN3505 utility. To add a BT into the SYSTEM 3505, you need to add a “generic” text message for the desired BT number. A “generic” text message is one that the account number ends in a “-“.

  • Page 19: Set 37, Activating Bt & Zids

    BT and or ZID units. After pressing the proper soft key, the “PROG >>>…” will display indicating that the SYSTEM 3505 is updating. The SYSTEM 3505 memory by setting up the proper internal ZID and BT accounts. 1.11 SYSTEM with RLP option Press 1 6 then FUNC to print all of your accounts on the 80 Column Line Printer DIGITIZE, INC.

  • Page 20: Operation

    2.3 COMMUNICATING via a REPEATER To advise the SYSTEM 3505 that a BT is communicated to via a repeater, you need to add the capitol letters “RPTR” in the last four text locations of the BT generic message. I.e. for BT #123 you would add the RPTR, when adding or changing the text message for account 123-, in the last four character locations of page 1 of the generic message.

  • Page 21: Power Up Printout

    Each time the SYSTEM 3505 is powered up, the following will be printed: Your SYSTEM 3505 printout may not be exactly as shown, as this is for a typical SYSTEM 3505. In addition to providing you with information about your SYSTEM 3505, such as the options installed, program revision, release date, etc., the SYSTEM 3505 also provides you...

  • Page 22: Box Look Up

    You can also LOOK UP just the BT number without a zone. However, you need to add a “-“ after the BT number I.e. 11- then press lookup. DIGITIZE, INC. 700273-0001 Rev. B Specifications Subject to Change Without Notice...
  • Page 23 BT number for say ZID 0123, simply enter 1 2 3, then press the “Find BT # for ZID”. After pressing the “Find BT# for ZID” soft key, the upper right of the display will indicate the full account number, I.e. BT-ZID or in this case 11-0123. DIGITIZE, INC. 700273-0001 Rev. B Specifications Subject to Change Without Notice...
  • Page 24 If the ZID you entered has no associated BT number, the display will indicate 9999-XXXX, where XXXX is the entered ZID number. DIGITIZE, INC. 700273-0001 Rev. B Specifications Subject to Change Without Notice...

  • Page 25: Trouble Reporting

    3 TROUBLE REPORTING 3.1 24 HOUR TROUBLE REPORT The SYSTEM 3505, per the NFPA requirement, will print out an automatic Trouble report once each 24 hour period. You can control the time that this report is printed via the SET menu.
  • Page 26 DIGITIZE, INC. 700273-0001 Rev. B Specifications Subject to Change Without Notice...

  • Page 27: Typical Alarm/Trouble Display & Printout

    Entering 1 8 then pressing FUNC will printout the BT units in ZID order installed in the SYSTEM 3505. Selecting 00, 01, 02 or 03 then pressing FUNC will put the SYSTEM 3505 in the sleep mode, as well as update the sleep soft key to the last selected FUNC.

  • Page 28: Bt & Zid Printouts

    3.4 BT & ZID PRINTOUTS The SYSTEM 3505 provides a means to print the installed BT list as well as the ZID’s installed. To print the BT units installed, enter 1 7 on the keypad, then press the FUNC key.
  • Page 29 Digitize by telephone or in writing. Buyer will prepay all freight charges to return any products to the repair facility designated by Digitize and include the RMA number on the shipping container. Digitize will, at its option, either repair the defective products or parts or deliver replacements for defective products or parts on an exchange basis to Buyer, freight prepaid to the Buyer.
