Combi Select DK-5 4050 Series Instruction Manual

Combi stroller instructions manual dk-5 4050
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Be sure to carefully read this instruction
manual before using the product to ensure
proper use of the stroller and keep it for
future reference. Record the following infor-
mation for quick reference.
Note: Illustrations are only representative and not actual.
Attach copy of sales receipt.

Parts List

Make sure you have all the parts listed below before using your stroller. If any parts are missing,
call Consumer Affairs at 1-800-99-COMBI.
Body
Combi USA, Inc. • 1962 HWY 160 W, Suite 100 • Fort Mill, SC
DK-5
Canopy
Consumer Affairs 1-800-992-6624
DK-5
4050 Series
Instruction Manual
Date Purchased: ______________________________________
Model Number: 4050-_______
Color: _________________________________________________
Fabric Pattern: ________________________________________
Seat
Cushion
Combi Connection
Infant Car Seat
29708 • www.combi-intl.com
Located on the rear right leg.
Stroller
Pack
Instruction
Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Select DK-5 4050 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Combi Select DK-5 4050 Series

Summary of Contents for Combi Select DK-5 4050 Series

  • Page 1: Parts List

    Make sure you have all the parts listed below before using your stroller. If any parts are missing, call Consumer Affairs at 1-800-99-COMBI. DK-5 Canopy Body Combi USA, Inc. • 1962 HWY 160 W, Suite 100 • Fort Mill, SC DK-5 Instruction Manual Date Purchased: ______________________________________ Model Number: 4050-_______...
  • Page 2 Name of Parts - Stroller with Seat Cushion Handle Canopy Headrest Buckle Armrests Buckle Tongue Guardrail Button Guardrail Cover Footrest Swivel Lock Seat Cushion Hook and Attachment Seat Cushion Snap and Hook Name of Parts - Stroller with Infant Restraint...
  • Page 3 Combi® reserves the right to modify the products in its line during the course of the year. Non contractual media. Colors are as accurate as the media in which they appear allows. Avoid serious injury from falling or sliding out.

  • Page 4: Opening The Stroller

    Opening the Stroller 1. Lift up on stroller lock lever to unlock. 2. Grasp handle on left and right sides. Pull handle outward. 3. While holding release lever, pull handle up to open stroller. 4. Before use, ensure both stroller locking mechanisms are in the locked position.

  • Page 5: Folding The Stroller

    3. Press and hold release button while lifting handle up and pushing rear stroller wheel forward. 4. Grasp left and right side of stroller and fold handle inward. 5. Ensure auto lock is locked. 6. Slide indicator left to lock.

  • Page 6: Using The Brakes

    Infant seat must be attached to stroller in rear facing position only. ALWAYS check stroller lock lever on the child seat to ensure it is in the locked position before use. Never force the infant seats stroller release lever from unlock to locked position.
  • Page 7 Stroller with Seat Cushion 1. Locate the stroller buckle. 2. Pull the stroller buckle from the storage position. 3. Attach belt from seat cushion to hook on stroller frame. Attachment will be confirmed with an audible “click”. 4. Attach hook and snap from seat cushion to attach- ments on stroller frame.
  • Page 8 Adjusting Seat Positions CAUTION Be careful when reclining the backrest while your baby is in the stroller to pre- vent abrupt changes in seating position. To Recline Pull center ring of recline adjuster. Head rest will automatically raise when seat is reclined.

  • Page 9: Removing Canopy

    Using the Canopy Attaching Canopy 1. Fully insert the canopy attachment (male) to the canopy holder (female). Connection will be confimred with an audible “click”. 2. Attach snaps on backside of canopy to snaps on front side of canopy. 3. Attach snaps on lower portion of canopy to snap on the back of the seat cushion.

  • Page 10: Using The Harness

    Unbuckling the Harness 1. Press levers down on right and left harness hooks to detach from buckle tongues. 2. Press buckle button down (with Combi logo) and detach buckle tongues from buckle. Page 10 Avoid serious injury from falling or sliding out.

  • Page 11: Using The Shoulder Strap

    3. To prevent the shoulder strap from twisting, route the two upper belts around the stroller handle grips and snap to secure. 4. Fold the Stroller and adjust the shoulder strap to a length suitable for you. Removing Shoulder Strap When the strap is not in use, remove it from the handle and store in the basket.

  • Page 12: Routine Maintenance

    Routine Maintenance STORE IN A COOL AND DRY AREA, especially in the summer. Do not store the stroller in the trunk of a vehicle. SEAT CUSHION The seat cushion is machine washable. Set to gentle cycle using cold water and a mild detergent. Do not use bleach.

  • Page 14: Parts Order Form

    Shipping and Handling Fees: Add $8.00 for orders $34.99 and under. Add $13.00 for orders $35.00 and over. Note: Additional shipping charges will apply outside of the Continental U.S. Combi USA reserves the right to change pricing at any time.
