Summary of Contents for Combi Cozy Light Compact

  • Page 1 Cozy Light Compact Instruction manual 简体中文 说明书...
  • Page 2 • Do not allow your child to stand in or on the stroller, it may be dangerous. • Do not lean on or hang loads on the handle. • Do not hang parcels or accessory items (except Combi original accessories) on the stroller, otherwise tipping over may happen to stroller.
  • Page 3 IMPORTANT : KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. WARNING (Incorrect operation may cause serious injury or death) • Keep your child’s fingers/hands away from moving/folding parts when folding or unfolding or adjusting the stroller. • Do not apply a lifted seat to baby who cannot sit straight by itself, the most reclined position is recommended for newborns.
  • Page 4 CAUTION (Incorrect operation may cause injury or component damage) • Make sure all snaps are secured when attach the seat cushion to stroller. Otherwise accident or damage to stroller may happen. • Loose the shoulder belts and support the backrest with the other hand before lowering the seat angle with a child seated.
  • Page 5 CAUTION (Incorrect operation may cause injury or component damage) • Do not get hold of an opened front guard to pull the baby stroller. • Even have stopper, this stroller may also be accidental slip or overturned. • Do not leave baby stroller at road side or slope even when it is not in use. •...
  • Page 6 CAUTION (Incorrect operation may cause injury or component damage) • When traveling on vehicles such as subways / high-speed rails, please mind that the wheels of your baby strollers are not caught by the door, and please mind the gap between the platform and the train.
  • Page 7 重要-使用前请详细阅读本说明书并妥善保存作日后参考之用 警告(错误操作可能引致重大伤害或死亡) 不按照本使用说明书指引使用手推车,可能对幼儿造成重大伤害。 幼儿的安全是您的责任。 • 本产品适用于一个月初生儿至15kg(大约三岁)的幼儿。 • 停止手推车时,请使用停车锁。 • 不论有否承载婴儿,停车时勿过分信赖停车锁的性能。 • 即使已使用停车锁,如载有婴儿,应随时留意手推车附近,以防任何危险发生。 • 切勿将小配件放近幼儿,以免幼儿吞下而造成窒息的危险。 • 为了防止幼儿窒息的危险,在拆开包装后,请将塑料袋之类的包装物料丢弃。 • 过分超载,错误折叠以及使用未经认可的附件会对手推车造成损坏。 • 乘载幼儿时必须系上安全带,安全带包含中央带,腰带和肩带。前护栏不能防止幼儿从 座垫上站起来。请确认安全带没有松脱,以免幼儿突然跌出手推车。 • 为防止幼儿突如其来的动作令其跌出手推车,即使已经扣上安全带,也请经常留意幼儿, 小心使用。 • 肩带扣在插扣片上时,请勿交叉肩带,以免肩带对幼儿颈部造成压迫。 • 请勿使用已破损的座垫,以免座垫不能发挥其应有功能,或令幼儿误吞内里的棉花等。 • 座垫起保护作用,推车未安装座垫时禁止儿童使用,否则可能有造成伤害的风险。 • 当儿童乘坐时,看护人不要离开。 • 使用前一定要确认开关锁已锁上,否则手推车会有突然折起的危险。 • 不要让幼儿操作前护栏以免其意外跌倒。 • 不可让幼儿站立在车上,这是十分危险的。 • 切勿把身体靠于或把重物挂于把手上。 •...
  • Page 8 重要-使用前请详细阅读本说明书并妥善保存作日后参考之用 警告(错误操作可能引致重大伤害或死亡) • 不应在无人照顾下把婴儿单独留于婴儿车内,以免发生危险。 • 使用手推车前请确保推车所有锁定装置都已处于锁定状态,如安全带长度调整,座垫扣 环扣上,推车已完全展开。 • 为了防止意外发生,孩子乘坐时必须系上安全带。 • 当靠背角度少于150度时,不适合6个月以下幼儿使用。 • 在把手上放置任何负载都会影响车辆的稳定性。 • 请一直将五点式安全带扣上,以确保宝宝乘车时的安全。 • 此产品不宜于跑步或溜冰时使用。 • 请勿让小孩玩耍本品。 • 为避免伤害,当产品在折叠和展开时,请确保你的孩子远离产品。 • 使用时应远离高温、火源、水池或电源等邻近范围。 • 请勿使用未经制造商认可的附属物。请勿使用非原厂供应的零件替换或自行改装手推车。...
  • Page 9 注意(错误操作可能引致受伤或组件损坏) • 安装座垫时,请确保所有带扣等已经装好,以免引致意外或造成损坏。 • 在已承载幼儿的状态下调整座席角度时,请先将肩带调松,然后以另外一只手支持着靠 背调节,请注意勿让座席角度突然改变。 • 调整座席角度后,请重新调整安全带至适当长度。 • 除开折手推车外,请勿触碰开关掣。 • 当打开和收折推车时,请注意及避免可装拆的座垫、手推车的安全带、被子及玩具夹在 手推车车体上。 • 当越过不同段差时,若强行附加力量于前车轮上使之与段差碰撞,可能引起手推车损坏 和故障,当越过段差时,即使是微小段差区的地方也应减缓推行,并踏上后脚支架及往 后按下把手往前行,确保前车轮越过段差才可通行。 • 当幼儿乘坐时,请勿在手扶梯上使用或搬动手推车。 • 用户必须对本产品作定期保养。 • 每次使用前请检查配件是否在运输过程中被损坏。 • 请勿将手推车作承载幼儿以外的用途,否则会引致损坏。 • 请勿用力拉动、扭动、压下前护栏,以免引致损坏。 • 假如放低椅背使用时座位太窄,可以将靠背调高一点使用。但注意幼儿应已差不多能独 自坐直,才可这样使用。 • 请勿让成年人坐上手推车,或在上面放置重物,以免损坏手推车。 • 请避免连续长时间使用,特别是在夏天。 • 避免将手推车存放于高温,接近热源的地方或车厢内,因高温可使手推车损坏或变形。 • 请定期检查所有螺丝是否上紧。 • 有关火车上的使用: 本产品并非以火车上的使用为目的所设计的产品。假如阁下自行决定于火车上使用,请...
  • Page 10 注意(错误操作可能引致受伤或组件损坏) • 跨越火车轨道和汽车道的十字道口等时,请提高前轮跨越间隙,以免前轮意外卡在沟内引 致翻倒。 • 禁止连续长时间使用:连续长时间使用会对幼儿造成负担。躺卧姿势的连续使用时间上 限为2小时,坐着姿势的则为1小时。 • 感觉有异物卡住时,请勿强行折叠,以免造成损坏。应先打开手推车,确认后再操作。 • 收折前请将转向轮翻往内侧然后锁定。如果不将转向轮锁定在内侧位置,收折后手推车 将较易翻倒。 • 请勿承载太尖或太大的东西于置物篮中,以免置物篮损坏。 • 请定期清洁以及检查手推车。请勿使用非中性的清洁剂清洁车架。 • 请注意勿让油分附在幼儿有机会舔到的地方,如前护栏,扶手等。 • 如发现车轮外胎磨耗严重,影响推行,请联系客服中心(或当地经销商)进行更换。 • 当放置和移开幼儿时请锁定停车装置。 • 为了手推车的稳定性,请勿将其他产品连接到推把、靠背的背部、手推车的侧面等部位。 • 请牢牢系上安全带,但注意不要过紧。 • 切勿搬动承载了婴孩的手推车,以免手推车突然收折。或手执前护栏等地方搬动手推车, 以免手推车意外滑脱或令前护栏松脱以致手推车掉下。 • 在乘坐如地铁/高铁等交通工具时,请注意手推车的车轮不要被车门夹住,并请留意站台 和车之间的缝隙。 • 当幼儿的脚接触到地面和车轮时,请勿使用手推车,有可能造成脚受伤。 • 假如幼儿头部超出靠背前端时,请勿使用躺卧角度。...
  • Page 12 List of components 25. Stopper 1. Handle 13. Ventilation window 26. Canopy snap 2. Front guard buttons 14. Top window cover 27. Elastic 3. Front guard cover 15. Shoulder belt and waist belt buckle 28. Seat reclining buckle 4. Front guard 16.
  • Page 13 Unfolding the stroller 打开手推车 Hold the handle and pull it upward by rotating it from bottom to top until it clicks. The handle will return to the straight status. Hold the handle with one hand and the canopy with the other, and then pull the canopy upward by rotating it from bottom to top to restore it to the position parallel to the handle.
  • Page 14 Unfolding the stroller 打开手推车 咔嚓声 咔嚓声 WARNING 警告...
  • Page 15 Using the swivel wheels 使用转向轮 Swivel wheels not in use – Lift the swivel wheel locks to lock,It can fix the forward direction of the wheel. To use the swivel wheels – Press down the swivel wheel locks (right and left) to release. NOTE: Press down the swivel wheel locks and 向内...
  • Page 16 Using the stopper 使用停车锁 To lock the wheels, press the stoppers down which are 前轮 located at wheels on both left and right sides. 停车锁 Try to push the stroller back and forth slightly to ensure 解锁 that the stoppers are properly engaged. To release the stoppers, lift the stoppers to unlock.
  • Page 17 Adjusting the covering size of canopy 遮阳篷大小的调节 Hold the canopy stay and pull the canopy forward for full coverage. Hold the canopy stay and pull the canopy backward for reduced canopy coverage. 用手拉住遮阳篷前支杆向前调节,即可展开遮阳篷。 用手拉住遮阳篷前支杆向后调节,即可收拢遮阳篷。 Using the top window and ventilation window 使用天窗和透气窗 Open top window by releasing snaps.
  • Page 18 Adjusting the waist/shoulder belt length 调节肩带、腰带的长度 Pull the waist belt end to direction A to shorten. Loose and pull out the waist belt to direction B, then pull it inward to extend the length to direction C. Use the same method on waist belt to adjust the shoulder belt. NOTE: Always leave at least 3cm at the belt end.
  • Page 19 Reclining the backrest 调节靠背角度 Support the backrest with one hand before reclining the backrest The headrest will be lifted automatically after the backrest is reclined. pull the reclining cords as illustrated to raise the seat back. NOTE: Raising the backrest may be difficult while a child is leaning on the backrest. The reclining belt sometimes is twisted,correct the twisted reclining belt by the following steps:Set the backrest down to the lowest.Hold the belt mounting part and turn to the direction of the twisted reclining belt.
  • Page 20 Folding the stroller 收折手推车 Slide to release the safety lock of direction as illustrated. Hold the switch while lifting the handle, and then press the handle to fold the stroller primarily. Unbutton the hood and the seat cushion. Hold the handle with one hand and rotate the canopy from top to bottom with the other hand. Press the handle joint switch as illustrated to operate to the top of the groove until a click is heard, Then use the other hand to rotate the handle from top to bottom until it overlaps with the canopy.
  • Page 21 Folding the stroller 收折手推车 Clicks 咔嚓声 WARNING 警告...
  • Page 22 Basket 置物篮 The basket can carry a maximum weight of 5kgs. You can attach and remove it using the belts and snaps according to step 最大载重量: Pulling the U-shaped buckle ,fastening belt to see if it is secured. 后 置物篮的最大载重量是5kg。 、...
  • Page 23 Detaching the seat cushion 座垫的拆除方法 Press the crotch buckle release button and release the harness. Detach the snap on the seat cushion from the leg support bar (if the leg support bar is in use). Release the snaps of elastic under the front end,PuII out crotch belt from seat cushion. Release both elastic bands from backrest sides.
  • Page 24 Attaching the waist belt 腰带的安装方法 Remove two of insert plastics buckle from the waist belt. According to the direction of arrow instructions. Pull the waist belt through the 4 slits on the base board with the reverse side(waist belt) facing up. Re-attach the insert plastic buckle and pull it out through relevant slots of seat cushion.
  • Page 25 Maintenance and Cleaning 保养和清洁 • Never apply force on any mechanism or moving parts. • To prevent mildew forming, do not store this product in a wet or humid environment. • Avoid prolonged exposure of the product to rain or snow. •...
  • Page 26 Washing of the seat cushion, front guard cover, shoulder belt, waist belt 座垫、前护栏套、肩带、腰带的洗涤方法 • Hand wash in warm water or machine-wash gently . • When using the washing machine, put the laundries into the washing net before washing. Otherwise a fray and damage may cause. •...
  • Page 27 产品名称及型号:儿童推车 Cozy Light Compact 规格号:724327 灰色 724328 蓝色 724329 红色 康贝(上海)有限公司 www.combi.com.cn 中国(上海)自由贸易试验区英伦路38号四层414室 联系地址:上海市淮海中路200号23楼 咨询电话:021-63852688 邮编:200021 生产厂:东莞康贝童车玩具有限公司 生产厂地址:东莞市塘厦镇蛟乙塘宝石路18号 产地:广东 东莞 适用年龄:出生后1个月至36个月(根据幼儿成长的速度而各有不同) 产品最大承载重量:15公斤 置物篮最大承载重量:5公斤 警告! 切勿近火。 ● 儿童乘坐时必须使用安全带。 ● 当靠背角度少于150度时,不适合6个月以下幼儿使用。 ● 使用前请仔细阅读使用说明书并且妥善保存供以后参照。 ● 如果不按本说明书使用可能会影响儿童安全。 当儿童乘坐时,看护人不要离开。 ● 产品执行标准:GB14748-2006...
  • Page 28 183496020...
