Installation & Operation Manual
ELECTRIC TILTING SKILLETS
30P-STEL (-LX), 40P-STEL (-LX),
30P-STEM (-LX) & 40P-STEM (-LX)
30P-STEL
(Open Leg Base Skillet)
Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury
or death. Read the installation, operating and maintenance instructions thoroughly before installing or
M
R
ANUAL 10148
EV 4 (11/22)
$21.00
servicing this equipment.
CROWN FOOD SERVICE EQUIPMENT
70 Oakdale Road, Downsview (Toronto) Ontario, Canada, M3N 1V9
Telephone: 919-762-1000
(Closed Base Skillet)
WARNING
A Middleby Company
www.crownsteamgroup.com
IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this
manual for the life of the equipment:
Model #: ___________________________
Serial #: ___________________________
Date Purchased: _____________________
30P-STEM
ELECTRIC TILTING SKILLETS
M
ANUAL
S
CO
ECTION

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 30P-STEL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Market Forge Industries 30P-STEL

Summary of Contents for Market Forge Industries 30P-STEL

  • Page 1 Model #: ___________________________ Serial #: ___________________________ Date Purchased: _____________________ Installation & Operation Manual ELECTRIC TILTING SKILLETS 30P-STEL (-LX), 40P-STEL (-LX), 30P-STEM (-LX) & 40P-STEM (-LX) 30P-STEL (Open Leg Base Skillet) 30P-STEM (Closed Base Skillet)

  • Page 2: Important Notes For Installation And Operation

    Safety Precautions Electric Tilting Skillets SAFETY PRECAUTIONS Before installing and operating this equipment, be sure everyone involved in its operation is fully trained and aware of precautions. Accidents and problems can be caused by failure to follow fundamental rules and precautions. The following symbols, found throughout this manual, alert you to potentially dangerous conditions to the operator, service personnel, or to the equipment.

  • Page 3: Table Of Contents

    Electric Tilting Skillets Table of Contents RETAIN THIS MANUAL FOR FUTURE REFERENCE. Table of Contents Important Notes For Installation and Operation ..............2 Service Connections ......................4 Introduction ........................... 5 Installation ..........................6 Operation ..........................8 Cooking Guidelines ......................9 Cleaning ..........................

  • Page 4: Service Connections

    Service Connections Electric Tilting Skillets Service Connections 30P-STEL AND 40P-STEL SHOWN 7434R4 (SHOWN WITH OPTIONAL DRAIN PAN ASSEMBLY) SERVICE CONNECTIONS – ELECTRICAL CONNECTION : To be as specified on data plate. – HOT WATER: 3/8” (10 mm) O.D. tubing to faucet (Optional) –...

  • Page 5: Introduction

    UniVerse Tilting Skillet. Description The Market Forge Industries UniVerse Models 30P-STEL (12 kW input) and 40P-STEL (18 kW input) are electrically operated skillets, tilting type, with 30- and 40-gallon capacities, respectively. They are equipped with a solid-state thermostat and high-limit control with a 100 °F to 450 °F temperature scale.

  • Page 6: Installation

    Installation Electric Tilting Skillets Installation Unpacking IMMEDIATELY INSPECT FOR SHIPPING DAMAGE Immediately after unpacking, check for possible shipping damage. If the tilting skillet is found to be damaged, save the packaging material and contact the carrier within 15 days of delivery. Before installing, verify that the electrical service agrees with the specifications on the rating plate located on the right side panel as you face the front of the skillet.
  • Page 7 Electric Tilting Skillets Installation Electrical Connections WARNING Before performing any maintenance disconnect the electrical power supply and place a tag at the disconnect switch to indicate that you are working on the circuit. NOTICE Do not install in such a manner that a service person cannot remove control box cover. Connect unit to a branch circuit having a voltage and circuit type specified on name plate and of sufficient size to carry load.

  • Page 8: Operation

    Operation Electric Tilting Skillets Operation WARNING The tilting skillet and its parts are hot. Use care when operating, cleaning and servicing the tilting skillet. Before First Use Using a non-corrosive, grease-dissolving commercial cleaner, clean the protective metal oils from all surface parts and the interior of the tilting skillet.

  • Page 9: Cooking Guidelines

    Electric Tilting Skillets Cooking Guidelines COOKING GUIDELINES All Modular and Tubular Leg Models The UniVerse Skillet is one of the most versatile pieces of equipment to be found in any restaurant or institutional kitchen. It enables the cook to stew, simmer, pan-fry, braise, grill, or sauté, and all with a very uniform heat pattern. The figures given below are suggested quantities and temperature settings and estimated numbers of orders per load and per hour.
  • Page 10 Cooking Guidelines Electric Tilting Skillets 30 Per Load 40 Per Load Portion Thermostat Batches Item Size Settings (°F) Per Hour Qty. Portions Qty. Portions VEGETABLES (continued) FRESH (continued) Broccoli 3 oz 25 lb 40 lb Cabbage 3 oz 20 lb 30 lb Carrots 3 oz...
  • Page 11 Electric Tilting Skillets Cooking Guidelines 30 Per Load 40 Per Load Portion Thermostat Batches Item Size Settings (°F) Per Hour Qty. Portions Qty. Portions MEAT-POULTRY (continued) FRANKFURTERS Grilled 2 oz 22 lb 33 lb Boiled 2 oz 16 lb 25 lb PORK Bacon 3 slices...

  • Page 12: Cleaning

    Cleaning Electric Tilting Skillets Cleaning Cleaning Instructions WARNING Disconnect the power supply to the appliance before cleaning or servicing. WARNING Never spray water into electric controls or components! CAUTION The equipment and its parts are hot. Use care when operating, cleaning and servicing. CAUTION Do not use cleaning agents that are corrosive.
  • Page 13 Electric Tilting Skillets Cleaning Stainless Steel To remove normal dirt, grease or product residue from stainless steel, use ordinary soap and water (with or without detergent) applied with a sponge or cloth. Dry thoroughly with a clean cloth. Never use vinegar or any other corrosive cleaner.

  • Page 14: Maintenance

    Maintenance Electric Tilting Skillets Maintenance NOTICE Contact the factory, the factory representative or a local service company to perform maintenance and repairs. WARNING The tilting skillet pan and its parts are hot. Use care when operating, cleaning and servicing the tilting skillet. WARNING Disconnect electrical power supply and place a tag at the disconnect switch to indicate that you are working on the circuit before performing any maintenance.

  • Page 15: Troubleshooting

    Electric Tilting Skillets Troubleshooting Troubleshooting Problem Probable Cause Remedy UNEVEN HEATING. • Defective element. • Replace element. • Uneven torque of element block nuts. • Re-torque element block nuts on bottom of skillet. Torque the first nuts evenly to 30 inch - lb. Holding first nut, torque the second nut to 100 inch - lb.
  • Page 16 Electric Tilting Skillets Electric Tilting Skillets 30P-STEL (-LX), 40P-STEL (-LX), 30P-STEM (-LX) & 40P-STEM (-LX) A product with the Market Forge name incorporates the best in durability and low maintenance. We all recognize, however, that replacement parts and occasional professional service may be necessary to extend the useful life of this appliance.
