How to perform firmware upgrade on Billion 52xx
What you need
• Your Internet access account details from your ISP - this is important as
you will need to have the login details from your ISP after the firmware
upgrade.
• The firmware file – you will need to obtain the correct firmware file from our
website. You can access our eSupport portal via:
http://www.billion.uk.com/esupport
• WinZip – all our firmware are usually zipped in a folder so you will have to
unzip it using WinZip. If you do not have WinZip, you can obtain it free from:
http://www.winzip.com.
Important notes
• Only upgrade if necessary – if your router is working without any problems,
we will recommend you to stay with the existing firmware. There are always
risks that the router might not work if the firmware upgrade failed.
• Always use a wired Ethernet connection – a wired Ethernet connection is
highly recommended when performing firmware upgrade to minimize possible
interruptions.
• Do not disturb or power off the router during firmware upgrade – if the
firmware upgrade process was disturbed you will end up having a dead router.
• Turn off any firewall or Internet security software – as firmware upgrade
process involve uploading the firmware file from your computer to the router,
it is best to turn off any firewall or Internet Security software to avoid possible
conflicts. Please refer to your software supplier on how to turn the software off.
router
Advertisement
Related Manuals for Billion 52 Series
Summary of Contents for Billion 52 Series
- Page 1 How to perform firmware upgrade on Billion 52xx router What you need • Your Internet access account details from your ISP - this is important as you will need to have the login details from your ISP after the firmware upgrade.
-
Page 2: How To Upgrade Your Firmware
How to upgrade your firmware 1) Once you download the correct firmware from our website, please extract it using WinZip to a memorable location of your choice - e.g. desktop. You should see a new folder extracted and there is a file inside that folder called "ras”. 2) Open your browser e.g. - Page 3 6) If you login successfully, you should the router’s home page 7) Click on “Maintenance” > “Firmware to access the firmware upgrade page 8) You will now need to locate the firmware file that we download and extract previously by pressing the “Browse” button.
- Page 4 9) On the new window please browse to the location of the “ras” file, select it and then press “Open”. 10) Now you should be back on the router’s firmware page with the location of the firmware file being added. 11) Press the “UPGRADE”...
- Page 5 12) The firmware is being uploaded to the router now. Please do not interrupt it! 13) The firmware upgrade process will take around 5 minutes to complete. Please do not interrupt the router or you computer during that. The router will restart itself automatically when finished.
- Page 6 15) You will now need to restart the router back to factory default to ensure all updates are applied properly. 16) Login back into the router via http://192.168.1.254 as shown in steps 3 to steps 6. 17) Once you are on the router’s main webpage, Please Goto Maintenance >...
