Summary of Contents for Ava QUAD

  • Page 1 Mounting guide...

  • Page 2: Important Warnings

    Do not clean the camera with harsh detergents, gasoline or chemicals such as acetone. Do not try to repair the unit yourself. Refer all servicing of the camera to Ava or contact a reseller. Do not install the camera during rain, mist or other conditions of high humidity. Water may be trapped inside, causing damage or condensation issues.

  • Page 3: Safety Instructions

    The camera should be connected only to PoE networks without routing to the outside plant. The PoE PSE must be properly grounded. Please contact AVA’s certified dealers (or distributor) for power adapters. For the grounding wire use a green/yellow wire (min. 18AWG), a knurled washer and min. 3.5mm screw.
  • Page 4 IR LEDs Dome cover Top mounting plate Package contains: Quad camera Screws and anchors IR light cover T10 security L-key Alignment sticker Quad • Mounting guide | 4 AVA-QUAD-MG-02 Copyright © 2022, Ava Video Security. All rights reserved.
  • Page 5 Overview Inner view Lens (sensor) module, 3-axis adjustable Status LEDs RJ45 Ethernet port Reset button (only POE+ supported) Cable gland Safety tether wire Quad • Mounting guide | 5 AVA-QUAD-MG-02 Copyright © 2022, Ava Video Security. All rights reserved.
  • Page 6 Preparing to mount the camera For all install options security bit Quad • Mounting guide | 6 AVA-QUAD-MG-02 Copyright © 2022, Ava Video Security. All rights reserved.
  • Page 7 Preparing to mount the camera Quad • Mounting guide | 7 AVA-QUAD-MG-02 Copyright © 2022, Ava Video Security. All rights reserved.
  • Page 8 Option A - Using the ceiling mount Alignment sticker 180mm Drill hole Cable hole Cable hole Drill hole Drill hole Quad • Mounting guide | 8 AVA-QUAD-MG-02 Copyright © 2022, Ava Video Security. All rights reserved.
  • Page 9 Secondary keel ø15cm If needed, add hanging rods to strengthen the ceiling structure. Weight of camera: 2.7 Kg Weight of Recessed kit: 1.1 Kg Quad • Mounting guide | 9 AVA-QUAD-MG-02 Copyright © 2022, Ava Video Security. All rights reserved.
  • Page 10 Use nuts, washers and lock washers as shown, tighten the nut towards the adapter plate and make sure the two nuts close to the bracket rod are loose. Bracket rod Adapter plate Bracket stand Quad • Mounting guide | 1 0 AVA-QUAD-MG-02 Copyright © 2022, Ava Video Security. All rights reserved.
  • Page 11 Assemble the camera top mounting plate to the adapter plate, adjust the position so the camera will be flush to the ceiling and the release button can be pressed. Required: ACQ-REC-KIT Recessed kit Quad • Mounting guide | 1 1 AVA-QUAD-MG-02 Copyright © 2022, Ava Video Security. All rights reserved.
  • Page 12 Note the front indicators indicate the default front side of the camera. Install the mounting plate with the orientation you prefer. Required: ACQ-PEN-HEA Pendant head ACQ-PEN-PIP Pendant pipe 40cm ACQ-MNT-ADA Mounting adapter Quad • Mounting guide | 1 2 AVA-QUAD-MG-02 Copyright © 2022, Ava Video Security. All rights reserved.
  • Page 13 Ø9.5mm or 3/8” Required: ACQ-WAL-MNT Wall mount bracket Quad • Mounting guide | 1 3 AVA-QUAD-MG-02 Copyright © 2022, Ava Video Security. All rights reserved.
  • Page 14 Option D - Using the wall mount Fasten bracket using nuts, washers and lock washers. Secure the top mounting plate. Quad • Mounting guide | 1 4 AVA-QUAD-MG-02 Copyright © 2022, Ava Video Security. All rights reserved.
  • Page 15 Required: ACQ-WAL-MNT Wall mount bracket ACQ-POL-MNT Pole bracket or ACQ-CRN-MNT Corner bracket Quad • Mounting guide | 1 5 AVA-QUAD-MG-02 Copyright © 2022, Ava Video Security. All rights reserved.

  • Page 16: Completing The Camera Installation

    Completing the camera installation Quad • Mounting guide | 1 6 AVA-QUAD-MG-02 Copyright © 2022, Ava Video Security. All rights reserved.
  • Page 17 Completing the camera installation Adjust the image orientation in Ava Aware. 19cm Mind the electrostatic damage by avoiding contact with exposed circuitry. Quad • Mounting guide | 1 7 AVA-QUAD-MG-02 Copyright © 2022, Ava Video Security. All rights reserved.
  • Page 18 Completing the camera installation Replace the two desiccant bags to ensure the camera is free from moisture. security bit Quad • Mounting guide | 1 8 AVA-QUAD-MG-02 Copyright © 2022, Ava Video Security. All rights reserved.
