- Page 1 Mounting guide...
-
Page 2: Important Warnings
Do not clean the camera with harsh detergents, gasoline or chemicals such as acetone. Do not try to repair the unit yourself. Refer all servicing of the camera to Ava or contact a reseller. Quad • Mounting guide | 2... -
Page 3: Safety Instructions
The camera should be connected only to PoE networks without routing to the outside plant. The PoE PSE must be properly grounded. Please contact AVA’s certified dealers (or distributor) for power adapters. For the grounding wire use a green/yellow wire (min. 18AWG), a knurled washer and min. 3.5mm screw. - Page 4 Threaded holes for ceiling-mount or wall Release mounting adapter mount bracket button IR LEDs Dome cover Top mounting plate Package contains: Quad camera Screws and anchors IR light cover T10 security L-key Alignment sticker Quad • Mounting guide | 4...
- Page 5 Overview Inner view Lens (sensor) module, 3-axis adjustable Status LEDs RJ45 Reset button Ethernet port Cable gland Safety tether wire Quad • Mounting guide | 5...
- Page 6 Camera mount - preparation security bit Quad • Mounting guide | 6...
- Page 7 Camera mount - preparation Quad • Mounting guide | 7...
-
Page 8: Ceiling Mount
Ceiling mount Alignment sticker 180mm Drill hole Cable hole Cable hole Drill hole Drill hole Quad • Mounting guide | 8... -
Page 9: In-Ceiling Mount
Cut a hole in the center of the tile with a diameter of 15cm. Hanging rod Main keel Secondary keel ø15cm If needed, add hanging rods to strengthen the ceiling structure. Weight of camera: 2.7 Kg Weight of Recessed kit: 1.1 Kg Quad • Mounting guide | 9... - Page 10 Use nuts, washers and lock washers as shown, tighten the nut towards the adapter plate and make sure the two nuts close to the bracket rod are loose. Bracket rod Adapter plate Bracket stand Quad • Mounting guide | 1 0...
- Page 11 Assemble the camera top mounting plate to the adapter plate, adjust the position so the camera will be flush to the ceiling and the release button can be pressed. Required: ACQ-REC-KIT Recessed kit Quad • Mounting guide | 1 1...
-
Page 12: Pendant Mount
Note the front indicators indicate the default front side of the camera. Install the mounting plate with the orientation you prefer. Required: ACQ-PEN-HEA Pendant head ACQ-PEN-PIP Pendant pipe 40cm ACQ-MNT-ADA Mounting adapter Quad • Mounting guide | 1 2... -
Page 13: Wall Mount
Route the cable along the routing guide poles to form drip loop. and 1 hole for routing cable. cable and use foam tapes or seal foam to ensure the back-end connection is waterproof. Ø9.5mm or 3/8” Required: ACQ-WAL-MNT Wall mount bracket Quad • Mounting guide | 1 3... - Page 14 Wall mount Fasten bracket using nuts, washers and lock washers. Secure the top mounting plate. Quad • Mounting guide | 1 4...
- Page 15 Align the top mounting plate with correct type of screws. the center of the wall mount bracket. Required: ACQ-WAL-MNT Wall mount bracket ACQ-POL-MNT Pole bracket or ACQ-CRN-MNT Corner bracket Quad • Mounting guide | 1 5...
- Page 16 Camera mount - final installation Quad • Mounting guide | 1 6...
- Page 17 Camera mount - final installation Adjust the image orientation in Ava Aware. 19cm Mind the electrostatic damage by avoiding contact with exposed circuitry. Quad • Mounting guide | 1 7...
- Page 18 Camera mount - final installation security bit Quad • Mounting guide | 1 8...
