VL3600 PROFILE IP
CAL-POSITION
Home
During calibration, pan and tilt will move to the center (50%) of travel. Once calibration has completed,
the fixture will move to the current DMX value of pan and tilt.
DMX
During calibration, pan and tilt will move directly to the current DMX value of pan and tilt.
DISPLAY
Orientation
Sets the orientation of the display. Up should be chosen if the fixture is sitting on its base. Down should
be chosen if the fixture is hanging.
On Time
Sets how long the display remains illuminated after the last button touch. Choose from 30 seconds, 5
minutes, 10 minutes, or always on.
FOCUS TRACK
With focus track enabled, once you set a focus (edge) value, running the zoom channel will hold that fo-
cus on your image. If you then adjust the focus channel, it will jump to that position based on the DMX
value. Disabled will cause the lenses to always move based on the DMX values.
FOLLOW SPOT MODE
Enabling Follow Spot Mode allows the fixture to be hand positioned without the use of DMX. All other
functions are still dependent on DMX control. The pan and tilt motors do provide resistance and break-
ing. If you disable Follow Spot Mode, the pan and tilt will return to the correct position based on the
DMX value.
RESET DEFAULTS
Resets all the factory defaults of the fixture. This includes setting the DMX Address to 001. Can also be
done via RDM and via the control channel.
Note: Control channel will not change the current DMX address.
DMX
ADDRESS
Sets the starting DMX address of the fixture. Can also be set via RDM.
DMX MODE
16Bit Enhanced
Includes luminaire timing channels. See DMX map.
16Bit
Omits luminaire timing channels. See DMX map.
