X-317™ Users Manual

Appendix F: Specifications

Power Requirements

Input Voltage:
Current:

10 Mbps Network Speed

Power Supply
9 VDC
12 VDC
24 VDC
100 Mbps Network Speed
Power Supply
9 VDC
12 VDC
24 VDC

Analog Outputs

Number of Channels:
Output Ranges:
Resolution:
Linearity Error:
Current Output (Voltage mode): 10mA max (min load = 1K), 30mA max short circuit
Voltage Output Inaccuracy:
Max Load Capacitance:
Current Output Range:
Current Output Inaccuracy:
Output Compliance Voltage:
Isolated Power Supply:
Isolation:
ESD Protection:
Output Protection:
Output Alarms:
Load Type:
Output at power up:

Connector

Type:
Xytronix Research & Design, Inc.
9-28 VDC
See table below for typical values at 25°C
Outputs = 0V
210 mA
162 mA
92 mA
Outputs = 0V
302 mA
229 mA
126 mA
5 (individually configurable)
0-5V, 0-10V, ±5V, ±10V, 4-20mA (software selectable)
16-bit DAC (0-65535)
±1-count, monotonic DAC
±0.2% FSR, includes offset error, gain error and non-linearity error
(-40 to 65ºC)
20nF (no load), 5nF (1K load)
4-20mA
±0.2% FSR, includes offset error, gain error and non-linearity error
(-40 to 65ºC)
11.50V min (max loop voltage)
Internal DC-DC converter
Galvanic, 1500 VAC
Integrated 15kV protection (IEC61000-4-2)
Integrated over-temperature, open-line and short circuit protection
Open current loop, high internal temperature
Grounded, COM of all 5-channels are connected together
Programmable
12-position, removable, 3.81 mm pitch
(Replacement part number, Phoenix Contact 1803675)
Outputs = 20mA
404 mA
298 mA
163 mA
Outputs = 20mA
498 mA
368 mA
198 m
Appendix F: Specifications
Page 63
