DecoFlex WireFree™ 3-Button Instructions
Item #:1870908 (White)

Product Overview

The DecoFlex WireFree™ 3-Button keypad provides a simple and elegant way to control Somfy-powered RTS interior shades. This
keypad is compatible with all Somfy RTS motors and brings an intuitive single channel control experience to the DecoFlex WireFree
product line.

Control Operation

LED Indicator
OPEN
Press to open drapery/
raise shades.
STOP
When the drapery/shades are moving,
press to stop them at the desired level.
When the drapery/shades are stationary,
press to send to pre-programmed
intermediate "my" position.
CLOSE
Press to close drapery/
lower shades.
Programming Button

Important Notes

Codes: Install in accordance with all local and National Electrical Codes.
Environment: Ambient operating temperature is 41° F to 104° F (5° C to 40° C).
Mounting: Mounting bracket (included) allows for direct mounting to drywall. No junction box required.
Battery: DO NOT use rechargeable batteries. Using improper batteries could damage the DecoFlex keypad.

Dimensions

OPEN
STOP
3.80" 3.28"
[97mm] [83mm]
CLOSE
OPEN
STOP
CLOSE
2.77"
[70mm]
OPEN
STOP
4.51"
[115mm]
CLOSE
Decora Switch Plate
(Switch Plate included)
What's In the Box
• DecoFlex WireFree™ 3-Button keypad
• Instructions
• CR2450 battery
• Mounting bracket
• Decora Switch Plate
• Mounting screws (x2)
.59"
[15mm]
4.51"
2.78"
[115mm]
[71mm]
