Cochlear Nucleus 5
CP810 Sound Processor
Advanced User Interface
Indicator Light
Upper
Button
Earhook
Processor Unit
Battery Module
In this arrangement the battery is
worn on the body – you cannot use
this arrangement with the compact
rechargeable battery module
Microphones
LiteWear Cable
LiteWear Case
Coil
Lower
Button
Accessory Socket Cover
Coil Magnet
Removable Coil
Cable
LiteWear Fixing Aid
Advertisement
Related Manuals for Cochlear Nucleus 5
Summary of Contents for Cochlear Nucleus 5
- Page 1 Cochlear Nucleus 5 CP810 Sound Processor Advanced User Interface Coil Coil Magnet Microphones Indicator Light Upper Button Lower Button Removable Coil Cable Earhook Processor Unit Accessory Socket Cover Battery Module In this arrangement the battery is worn on the body – you cannot use...
- Page 2 All about batteries and the battery module Locking the battery unit on to the processor It is possible to lock the battery module (including the LiteWear option) on to the processor. To do this open the accessory socket cover. The lock is situated below the accessories socket.
- Page 3 Simple and Advanced Interface for the CP810 Simple User Interface You are able to switch on/off, change the program and select the telecoil without using the Remote Assistant Advanced User Interface You are able to switch on/off, change the program and select the telecoil.
- Page 4 Toggle Button for Telecoil Lower Left Soft Key Lower Right Soft Key Scroll Up or Increase Volume Move Right or Increase Sensitivity Cochlear Key – On/Off Home Screen Processor Status Scroll Down or Decrease Volume Move left or decrease sensitivity...
- Page 5 The processor and the Remote Assistant need to be within two metres of each other. You do not need to point the assistant at the processor. Turning the Press and hold down the Cochlear key for a couple of Remote seconds. The screen will light up. To turn it off, press...
- Page 6 Cochlear key. To decrease sensitivity press the silver edge key to the left of the Cochlear key. The default sensitivity setting is usually 12 and is indicated by a small orange square on the screen (for unilateral users).
- Page 7 If the Cochlear key does not work or your Remote Assistant display freezes, you can press the Hard Reset button on the back of the Remote Assistant to reset your assistant Attaching accessories You can attach the following accessories to the processor using the accessories socket: •...
- Page 8 Checking the Coil You can check the coil by putting it on the back of the Remote Assistant. Place the coil on the area indicated. If it is not working, there will be no display on the assistant. An animation will display on the assistant if the coil is receiving sound signals, this is an indication that the coil is transmitting but does not indicate the quality of the...
