INSTRUCTION & MAINTENANCE
MODEL CLS-1000
COLOR LIGHT SIGNAL
FEBRUARY 2023
DOCUMENT NO. SIG-00-21-05
VERSION A
Siemens Mobility, Inc.
One Penn Plaza
Suite 1100
New York, NY 10119-1101
1-800-793-SAFE
www.usa.siemens.com/rail-manuals
Copyright © 2023 Siemens Mobility, Inc.
All Rights Reserved
PRINTED IN U.S.A.

Advertisement

Table of Contents
loading

Summary of Contents for Siemens CLS-1000

  • Page 1 INSTRUCTION & MAINTENANCE MODEL CLS-1000 COLOR LIGHT SIGNAL FEBRUARY 2023 DOCUMENT NO. SIG-00-21-05 VERSION A Siemens Mobility, Inc. One Penn Plaza Suite 1100 New York, NY 10119-1101 1-800-793-SAFE www.usa.siemens.com/rail-manuals Copyright © 2023 Siemens Mobility, Inc. All Rights Reserved PRINTED IN U.S.A.
  • Page 2: Proprietary Information

    WARRANTY INFORMATION Siemens Mobility, Inc. warranty policy is as stated in the current Terms and Conditions of Sale document. Warranty adjustments will not be allowed for products or components which have been subjected to abuse, alteration, improper handling or installation, or which have not been operated in accordance with Seller's instructions.
  • Page 3: Document History

    DOCUMENT HISTORY Release Sections Version Details of Change Date Changed FEB 2023 Initial Release SIG-00-21-05 FEBRUARY 2023 Version No.: A...
  • Page 4: Table Of Contents

    TABLE OF CONTENTS Section Title Page PROPRIETARY INFORMATION ......................ii TRANSLATIONS ............................. ii WARRANTY INFORMATION ........................ii SALES AND SERVICE LOCATIONS ....................... ii FCC RULES COMPLIANCE ........................ii DOCUMENT HISTORY ...........................iii NOTES, CAUTIONS, AND WARNINGS ....................vii ELECTROSTATIC DISCHARGE (ESD) PRECAUTIONS ............... viii GLOSSARY ............................
  • Page 5 LIST OF FIGURES Section Title Page Figure 1-1 CLS-1000 Color Light Signal ....................1-1 Figure 1-2 Mounting Bracket Options ....................1-3 Figure 1-3 Visor Options ........................1-5 Figure 1-4 Dialight LED Module Dimensions ..................1-6 Figure 2-1 LED Alignment ........................2-1 Figure 3-1 Replacement Parts Location ....................
  • Page 6 LIST OF TABLES Section Title Page Table 1-1 Mounting Bracket Part Numbers ..................1-3 Table 1-2 Lens Part Numbers ......................1-4 Table 1-3 Visor Part Numbers ......................1-5 Table 1-4 Dialight LED Module Part Numbers ..................1-6 Table 3-1 Replacement Parts ......................3-1 Table 3-2 Dialight LED Support Bracket Replacement Parts ...............
  • Page 7: Notes, Cautions, And Warnings

    EQUIPMENT. CAUTIONS TAKE PRECEDENCE OVER NOTES AND ALL OTHER INFORMATION, EXCEPT WARNINGS. NOTE Generally used to highlight certain information relating to the topic under discussion. If there are any questions, contact Siemens Industry, Inc. Application Engineering. SIG-00-21-05 FEBRUARY 2023 Version No.: A...
  • Page 8: Electrostatic Discharge (Esd) Precautions

    (ESD) during the handling, shipping, and storage of electronic modules and components. Siemens Industry, Inc. has instituted these practices at its manufacturing facility and encourages its customers to adopt them as well to lessen the likelihood of equipment damage in the field due to ESD.
  • Page 9: Glossary

    GLOSSARY TERM DESCRIPTION American Railway Engineering and Maintenance-of-way Association - An organization that promotes the development AREMA and advancement of both technical and practical knowledge and recommended practices pertaining to the design, construction, and maintenance of railway infrastructure. Light Center Length - The distance between the center of the filament, or arc tube, and a reference plane, usually the bottom of the lamp base.
  • Page 10 This Page Intentionally Left Blank SIG-00-21-05 FEBRUARY 2023 Version No.: A...
  • Page 11: Introduction

    INTRODUCTION INTRODUCTION The Model CLS-1000 is a rear-access Color Light Signal of modular design, allowing multiple units to be easily stacked together. The model CLS-1000 uses LED modules for signal illumination. Each unit measures 10 inches in height, 9 inches in width, and 8 inches in depth.
  • Page 12: Ordering Information

    INTRODUCTION _________________________________________________________________________________________________________ The mounting arrangements available for the CLS-1000 are top of mast mounting, side of wall mounting, or base mounting on 8 x 8, or 6-3/4 x 6-3/4 inch bolt spacing. Mounting bracket assemblies are adjustable for both vertical and horizontal alignment.
  • Page 13: Mounting Brackets

    INTRODUCTION _________________________________________________________________________________________________________ 1.1.1 Mounting Brackets Mounting brackets are of lightweight cast aluminum construction. The top of the mast mounting bracket will be furnished for 5-inch pipe mast mounting unless otherwise specified. The mounting base assemblies are to be used for 6-3/4 x 6-3/4 and 8 x 8 inch bolt spacing. Figure 1-2 Mounting Bracket Options To order, specify the description and part number: Table 1-1 Mounting Bracket Part Numbers...
  • Page 14: Lenses

    INTRODUCTION _________________________________________________________________________________________________________ 1.1.2 Lenses Lenses for the Model CLS-1000 Color Light Signal are available in glass or high-impact plastic. Both lens types provide a full face high-intensity indication light. These lenses meet or exceed applicable AREMA recommended practices. To order, specify diameter, focal length, deflection, color, material, and part number:...
  • Page 15: Visors

    INTRODUCTION _________________________________________________________________________________________________________ 1.1.3 Visors Visors for the Model CLS-10D are available in black, high density, polyethylene plastic, aluminum, or steel. Aluminum and steel visors are painted non-reflective black. Visor assemblies listed below include all appropriate mounting hardware. To order, specify the description and part number: Table 1-3 Visor Part Numbers Description Part Number...
  • Page 16: Led Modules

    INTRODUCTION _________________________________________________________________________________________________________ 1.1.4 LED Modules Replacement LED Module information for the CLS-1000 is as follows: 1.1.4.1 Dialight Modules Figure 1-4 Dialight LED Module Dimensions Table 1-4 Dialight LED Module Part Numbers Description Part Number Module Green LED Wayside 120V 045050-G-120...
  • Page 17: Maintenance

    MAINTENANCE _________________________________________________________________________________________________________ SECTION 2 MAINTENANCE MAINTENANCE LED Alignment Figure 2-1 LED Alignment Use sighting device A, located in the upper left-hand corner of the lamp until, for proper beam alignment. When more than one lamp unit is used, the sighting device will be located in the bottom unit.
  • Page 18: Lens Replacement

    MAINTENANCE _________________________________________________________________________________________________________ Loosen nut D to allow for final vertical and horizontal alignment. Loosen nut F and turn bolt G to rotate upper bracket left or right for proper horizontal alignment. Turn nut E to move the rear of the bracket up or down for proper vertical alignment. Once adjustments have been made, tighten nuts D and F securely.
  • Page 19: Replacement Parts

    REPLACEMENT PARTS _________________________________________________________________________________________________________ SECTION 3 REPLACEMENT PARTS REPLACEMENT PARTS To order specify the description and part number. Table 3-1 Replacement Parts Item Qty. Part Item Qty. Part Description Description Req'd. Number Req'd. Number Washer, Flat, #10 1710-SC Door, CLS-10D 042610 Gasket, Door 104510 Machine Screw, Round Head,...
  • Page 20: Figure 3-1 Replacement Parts Location

    REPLACEMENT PARTS _________________________________________________________________________________________________________ Figure 3-1 Replacement Parts Location SIG-00-21-05 FEBRUARY 2023 Version No.: A...
  • Page 21: Figure 3-2 Led Support Bracket Replacement Parts Location

    REPLACEMENT PARTS _________________________________________________________________________________________________________ Dialight LED Support Bracket Replacement Parts To order specify the description and part number. Table 3-2 Dialight LED Support Bracket Replacement Parts Qty. Description Item No. Part Number Req'd. Plate, Mounting, LED, CLS10 045050-15 MS RH #6-32x50 Self Tapping 002559-PST W LKS, #6 Split SS 001804-ME...
  • Page 22 REPLACEMENT PARTS _________________________________________________________________________________________________________ This Page Intentionally Left Blank SIG-00-21-05 FEBRUARY 2023 Version No.: A...
  • Page 23 NOTES...
  • Page 24 Siemens Mobility, Inc., 2400 Nelson Miller Parkway Louisville, Kentucky 40223 (502) 618-8800...
