Download the App
Download the App from App Store or Google Play by searching the keywords "W120 Alarm".
Add the Hub to the App
Sign up an account, and then sign in the App and follow the instructions on the App to add the Hub to your account.
Add the P70 Camera to the App
Accessories Configuration
Test the pre-programmed accessories with Hub
- RE2300 (Remote Control)
Press any button on the remote control to test the connection.
![]()
- DS2300 (Door/Window Contact)
Set the Hub into Armed status, trigger the door/window contact by separating the magnet and transmitter to test the connection.
![Accessories Configuration - Door/Window Contact]( "Smanos - W120i - Accessories Configuration - Door/Window Contact")
*You can also change the accessory settings and add new accessory in the App.
Installation
Install the Hub and accessories to the right places.
* Please place this unit away from load-bearing walls and operating home appliances, and elevate it along with your modem or router away from the ground, to ensure the best possible connectivity.
For more detailed Instruction Manual, please check Help in "W120 Alarm" app.
Specification
W120 Hub
| Power Supply | DC 12V 500mA |
| Battery | AA 1.5V LR 6 x 4pcs |
| Standby Current | <60 mA |
| Alarm Current | <200 mA |
| Internal Siren | 95dB |
| Expandable Accessories | 10 remote controls, 50 sensors |
| WiFi | IEEE 802.11b/g/n |
| Radio Frequency | 868MHz or 915MHz *Only 868MHz is available for Europe |
| EIRP(dBm).Max | 16.29 |
| ERP(dBm). Max | -8.27 |
| Receiver Category | Category 2 (standard performance level of receiver) |
| Housing Material | PC + ABS Plastic |
| Operating Condition | Temperature 0°C~+55°C (32°F - 131°F) Relative humidity <80% (non-condensing) |
| Dismensions | 117 x 118.5 x 40.5 mm (L x W x H) (4.6 x 4.7 x 1.6 inches) |
Door/ Window Contact
| Power Supply | DC 3V (CR2032 lithium cell battery x 2) |
| Static Current | <2 uA |
| Alarm Current | <22 mA |
| Transmitting Distance | <80 m (open area/no interference) |
| Radio Frequency | 868MHz or 915MHz *Only 868MHz is available for Europe |
| ERP(dBm). Max | -10.26 |
| Housing Material | PC+ABS Plastic |
| Operating Condition | Temperature 0°C~+55°C (32°F - 131°F) Relative humidity <80% (non-condensing) |
| Transmitter Dimensions | 72.5 x 28 x 10 mm (L x W x H) (2.85 x 1.1 x 0.4 inches) |
| Magnet Dimensions | 58 x 14 x 9.5 mm (L x W x H) (2.28 x 0.55 x 0.38 inches) |
Remote Control
| Power Supply | DC 3V (CR2032 lithium cell battery x 1) |
| Transmitting Current | <10 mA |
| Transmitting Distance | <80 m (open area/no interference) |
| Radio Frequency | 868MHz or 915MHz *Only 868MHz is available for Europe |
| ERP(dBm). Max | -10.62 |
| Housing Material | PC + ABS plastic |
| Operating Condition | Temperature -10°C~+55°C (32°F - 131°F) Relative humidity <80% (non-condensing) |
| Dimensions | 71 x 38 x 12 mm (L x W x H) (2.8 x 1.5 x 0.5 inches) |
HD WiFi Camera
| Image sensor | Sony 1/2.9" CMOS sensor |
| Shutter time | 1/50s to 1/100,000s |
| Lens | 2.4mm F2.0 |
| Angle of view | 115° |
| Video compression | H.264 |
| Bit rate | Self-adaption |
| Max. image resolution | 1920 x 1080 |
| Frame rate | 20fps |
| Storage | Built-in microSD™ card slot, up to 32GB |
| Wireless standards | EEE802.11b/g/n |
| Frequency range | 2.4 GHz ~ 2.4835 GHz |
| Channel bandwidth | 20/40MHz Support |
| Operating conditions | Temperature: 0°C - 60°C (32°F - 140°F) Humidity: < 90% (non-condensing) |
| Power supply | DC 5V 1A |
| Power consumption | 5W MAX |
| EIRP(dBm). Max | -17.2 |
| Dimensions (L x W x H) | 80 x 80 x 150 mm (3.15 x 3.15 x 5.91 inches) |
