1/2" Heavy Duty Impact Wrench
SPECIFICATION
Free Speed (rpm)
Square Driver (inch)
Std.Bolt Size (inch)
Air Consumption (cfm)
Max. Torque(ft-ib)
Air Pressure (kg/cm³)
Air Inlet (inch)
Overall Length (mm)
Net Weight (kgs)
(Handle Exhaust)
ST-5544H
7000
1/2"
5/8"
8
400
6.2
1/4"
184
2.7
PNEUMATIC
Test results according to prEN 792-6
Vibration
ISO 8662-7
Sound pressure
No-Load:
Sound power level
1.2 m/s
2
Instantaneous
sound pressure
TOOLS
Noise
Remark
ISO 3744
level 84 dB
Should wear an
approved ear -
protector and
96 dB
gloves while
operating tool.
99 dB
Advertisement
Table of Contents
Related Manuals for Sumake ST-5544H
Summary of Contents for Sumake ST-5544H
- Page 1 PNEUMATIC TOOLS 1/2” Heavy Duty Impact Wrench (Handle Exhaust) ST-5544H SPECIFICATION Test results according to prEN 792-6 Free Speed (rpm) 7000 Vibration Noise Remark ISO 8662-7 ISO 3744 Square Driver (inch) 1/2” Sound pressure Std.Bolt Size (inch) 5/8” level 84 dB...
- Page 2 EC DECLARATION OF CONFORMITY FOR MACHINERY SUMAKE INDUSTRIAL CO.,LTD. Manufacturer: Address: 3F2, NO.202, SEC. 5, Nan-King East Road TAIPEI, TAIWAN herewith declares ST-5544H that: 1/2” Heavy Duty Impact Wrench (Handle Exhaust) - is in conformity with the provisions of the Machinery Directive (Directive 89/392/EEC), as amended, and with national implementing legislation: -and have been tested according to: prEN 792...(relevant part)
- Page 3 Sumake is a manufacturer and exporter of air tools since established. We have devote all our effort in improving quality and tools life. As well as the noise and vibration of tools. Bring all of your working efficiency, profits and enjoy using the tool is our principle.
- Page 4 2-3 Air hose Clean the hose with a blast of compressed air before connecting the hose to air tool. This will prevent both moisture and dust within the hose from entering the tool and causing possible rust or malfunction. To compensate for unusually long hose (over 25 ft), the line pressure should be increased accordingly. 2-4 Inserted tools Use only the socket or adapter which are in good condition for use.
- Page 5 1.The power toll shall not be used in potentially explosive atmospheres. 2.Disconnect the air hose before changing or adjusting any inserted tools. 3.Prevent long hair or loose clothing from drawing in while operate this tool. 4.Keep your body in well balanced position and always wear gloves to reduce the risk of crushing caused by torque between handle and workpiece.
- Page 6 PARTS LIST Parts No. Description Q'ty No. Parts No. Description Q'ty 5544H-01 Motor Housing Assembly 5544H-31 Rear End Plate 5544H-02A Throttle Valve 5544H-32 End Plate Gasket 5544H-03A Throttle Valve Assembly 5544H-33 Motor Clamp Washer 5544H-04 Throttle Valve Spring 5544H-34 Hammer Frame 5544H-05 Exhaust Silcencer 5544H-35...
