SUMAKE
1/2" Heavy Duty Impact Wrench
Specification:
Free Speed
Capacity Bolt Size
Max Torque
Air Consumption
Overall Length
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
PNEUMATIC TOOLS
(Pin Clutch)
ST-5549A
7,000 r/min
5/8" (M16)
400 ft-lb (542 N-m)
15 CFM (430 L/min)
7-3/4" (197 mm)
1/4" (6.35 mm)
3/8" (10 mm)
90 psi (6.3 bar)
5.3 lbs (2.4 kg)
Noise and Vibration:
Vibration
EN ISO 28927-2
Sound Pressure Level
Load:
4.7 m/s²
Sound power level
load: 102.1 dB(A)
Uncertainty
²
K= 1.5 m/s
Noise
EN ISO 15744
Please always
load: 91.1 dB(A)
protector at
environment
noise level > 80
dB(A) due to
risk of impaired
Uncertainty
K= 3dB
ST-5549A-S-1408G-YCF
Remark
wear ear
hearing!
