KA01333D/06/EN/01.17
71377318
Products
Brief Operating Instructions
Proline 100
PROFIBUS DP
Transmitter with
Coriolis sensor
These instructions are Brief Operating Instructions; they are
not a substitute for the Operating Instructions pertaining to
the device.
Transmitter Brief Operating Instructions
Contain information about the transmitter.
Sensor Brief Operating Instructions → 3
Solutions
Services
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Endress+Hauser PROFIBUS DP Proline 100
Summary of Contents for Endress+Hauser PROFIBUS DP Proline 100
- Page 1 Products Solutions Services KA01333D/06/EN/01.17 71377318 Brief Operating Instructions Proline 100 PROFIBUS DP Transmitter with Coriolis sensor These instructions are Brief Operating Instructions; they are not a substitute for the Operating Instructions pertaining to the device. Transmitter Brief Operating Instructions Contain information about the transmitter. Sensor Brief Operating Instructions →...
- Page 2 Proline 100 PROFIBUS DP Order code: XXXXX-XXXXXX Ser. no.: XXXXXXXXXXXX Ext. ord. cd.: XXX.XXXX.XX Serial number www.endress.com/deviceviewer Endress+Hauser Operations App A0023555 Endress+Hauser...
- Page 3 These Brief Operating Instructions are the Transmitter Brief Operating Instructions. The "Sensor Brief Operating Instructions" are available via: • Internet: www.endress.com/deviceviewer • Smart phone/tablet: Endress+Hauser Operations App Detailed information about the device can be found in the Operating Instructions and the other documentation: • Internet: www.endress.com/deviceviewer...
-
Page 4: Table Of Contents
Diagnostic information ............33 Endress+Hauser... -
Page 5: Document Information
Result of a step Visual inspection 1.1.3 Electrical symbols Symbol Meaning Symbol Meaning Direct current Alternating current Direct current and alternating current Ground connection A grounded terminal which, as far as the operator is concerned, is grounded via a grounding system. Endress+Hauser... - Page 6 Allen key Open-ended wrench 1.1.5 Symbols in graphics Symbol Meaning Symbol Meaning 1, 2, 3,... Item numbers … Series of steps A, B, C, ... Views A-A, B-B, C-C, ... Sections Hazardous area Safe area (non-hazardous area) Flow direction Endress+Hauser...
-
Page 7: Basic Safety Instructions
Danger of breakage due to corrosive or abrasive fluids! ‣ Verify the compatibility of the process fluid with the sensor material. ‣ Ensure the resistance of all fluid-wetted materials in the process. ‣ Keep within the specified pressure and temperature range. Endress+Hauser... -
Page 8: Workplace Safety
Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability as minute changes in the temperature, concentration or level of contamination in the process can alter the corrosion resistance properties. -
Page 9: It Security
Mounting the measuring device 4.1.1 Turning the display module The local display is only available with the following device version: Order code for "Display; operation", option B: 4-line; illuminated, via communication The display module can be turned to optimize display readability. Endress+Hauser... - Page 10 Installation Proline 100 PROFIBUS DP Aluminum housing version 3 mm A0023192 Compact and ultra-compact housing versions 8 mm A0023195 Endress+Hauser...
-
Page 11: Electrical Connection
For detailed information about the specification of the connecting cable, see the Operating Instructions for the device. Cable diameter • Cable glands supplied: M20 × 1.5 with cable ⌀ 6 to 12 mm (0.24 to 0.47 in) • Spring terminals: Wire cross-sections 0.5 to 2.5 mm (20 to 14 AWG) Endress+Hauser... - Page 12 Non-hazardous area and Zone 2/Div. 2 Intrinsically safe area 5.1.4 Pin assignment, device plug Supply voltage For use in the non-hazardous area and Zone 2/Div. 2. Assignment DC 24 V Not assigned Not assigned DC 24 V Grounding/shielding Coding Plug/socket Plug A0016809 Endress+Hauser...
- Page 13 In systems without potential matching, the multiple grounding of the cable shield causes mains frequency equalizing currents! Damage to the bus cable shield. ‣ Only ground the bus cable shield to either the local ground or the protective ground at one end. Insulate the shield that is not connected. Endress+Hauser...
- Page 14 Remove dummy plug if present. If the measuring device is supplied without cable glands: Provide suitable cable gland for corresponding connecting cable. If the measuring device is supplied with cable glands: Observe requirements for connecting cables → 11. Endress+Hauser...
-
Page 15: Connecting The Measuring Device
Compact, coated aluminum Compact hygienic, stainless or compact, stainless Cable entry or device plug for signal transmission Cable entry or device plug for supply voltage Ultra-compact hygienic, stainless or ultra-compact, stainless Device plug for signal transmission Device plug for supply voltage Endress+Hauser... - Page 16 Device plug for supply voltage Depending on the housing version disconnect the local display from the main electronics module: Operating Instructions for the device . ‣ Connect the cable in accordance with the terminal assignment or the device plug pin assignment . Endress+Hauser...
-
Page 17: Special Connection Instructions
Hardware settings 5.4.1 Setting the device address PROFIBUS DP The address must always be configured for a PROFIBUS DP/PA device. The valid address range is between 1 and 126. In a PROFIBUS DP/PA network, each address can only be Endress+Hauser... - Page 18 Due to the capacitance load of the user and the line reflections generated as a result, ensure that an external bus terminator is used. It is generally advisable to use an external bus terminator as the entire segment can fail if a device that is terminated internally is defective. Endress+Hauser...
-
Page 19: Ensuring The Degree Of Protection
To guarantee IP66/67 degree of protection, Type 4X enclosure, carry out the following steps after the electrical connection: Check that the housing seals are clean and fitted correctly. Dry, clean or replace the seals if necessary. Tighten all housing screws and screw covers. Firmly tighten the cable glands. Endress+Hauser... -
Page 20: Post-Connection Check
Is the terminal assignment or pin assignment of the connector → 12 correct? If supply voltage is present, is the power LED on the electronics module of the transmitter lit green ? Depending on the device version, is the securing clamp or fixing screw firmly tightened? Endress+Hauser... -
Page 21: Operation Options
Overview of operating options A0017760 Computer with Web browser (e.g. Internet Explorer) or with "FieldCare" operating tool Automation system, e.g. "RSLogix" (Rockwell Automation) and work station for measuring device operation with Add-on Profile Level 3 for "RSLogix 5000" software (Rockwell Automation) Endress+Hauser... -
Page 22: Structure And Function Of The Operating Menu
Furthermore the device data can be managed and the network parameters can be configured. For additional information on the Web server, refer to the Special Documentation for the device Endress+Hauser... - Page 23 Switch off all other network connections such as WLAN. In the event of connection problems: Measuring device: Via CDI-RJ45 service interface Device CDI-RJ45 service interface Measuring device The measuring device has an RJ45 interface. Web server Web server must be enabled; factory setting: ON Endress+Hauser...
- Page 24 The login page appears. If a login page does not appear, or if the page is incomplete, see the Special Documentation for the Web server 6.3.4 Logging on Access code 0000 (factory setting); can be changed by customer Endress+Hauser...
- Page 25 • The structure of the operating menu is the same as for the operating tools Menu For detailed information on the structure of the operating menu, see the Operating Instructions for the measuring device Device status Displays the diagnostic messages currently pending, listed in order of priority Endress+Hauser...
- Page 26 Web server functionality parameter. Navigation "Expert" menu → Communication → Web server Parameter overview with brief description Parameter Description Selection Factory setting Web server functionality Switch the Web server on • Off and off. • HTML Off • On Endress+Hauser...
-
Page 27: Access To The Operating Menu Via The Operating Tool
• Overview of device description files – Current version data for the device – Operating tools • Device master file (GSD) – Manufacturer-specific GSD – Profile GSD • Cyclic data transmission – Block model – Description of the modules Endress+Hauser... -
Page 28: Cyclic Data Transmission
Description of the modules The data structure is described from the perspective of the PROFIBUS master: • Input data: Are sent from the measuring device to the PROFIBUS master. • Output data: Are sent from the PROFIBUS master to the measuring device. Endress+Hauser... - Page 29 Input variable 32961 Mass flow 33122 Volume flow 33093 Corrected volume flow Target fluid mass flow Carrier mass flow Only available with the "Concentration" application package Factory setting Function block Factory setting: TOTAL Totalizer 1, 2 and 3 Mass flow Endress+Hauser...
- Page 30 Selection: totalizer configuration CHANNEL MODETOT value Totalizer configuration 33306 Balancing 33028 Balance the positive flow 32976 Balance the negative flow 32928 Stop totalizing Factory setting Function block Factory setting: Value MODETOT (meaning) Totalizer 1, 2 and 3 0 (balancing) Endress+Hauser...
- Page 31 • 0 (device function not active) • 1 (device function active) Low flow cut off 1430 Verification status Only available with the Heartbeat Verification application package Factory setting Function block Factory setting DI 1 Empty pipe detection DI 2 Low flow cut off Endress+Hauser...
-
Page 32: Commissioning
The Setup menu with its submenus enable fast commissioning of the measuring device. The submenus contain all the parameters required for configuration, such as parameters for measurement or communication. The submenus available in the particular device can vary on account of the device version (e.g. sensor). Endress+Hauser... -
Page 33: Protecting Settings From Unauthorized Access
• In the Web browser: Remedial measures are displayed in red on the home page next to the diagnostic message → 25. • In FieldCare: Remedial measures are displayed on the home page in a separate field below the diagnostic message: see the Operating Instructions for the device Endress+Hauser... - Page 34 Diagnostics 1: C485 Simulation measured vari... Diagnostics Remedy information: Deactivate Simulation (Service... Expert Out of spezification (S) Maintenance required (M) A0021799-EN Status area with status signal Diagnostic information Remedy information with Service ID ‣ Perform the remedial measure displayed. Endress+Hauser...
- Page 36 www.addresses.endress.com...
