18v lithium-ion cordless lawnmower

Advertisement

Quick Links

18V LITHIUM-ION
CORDLESS LAWNMOWER
ASSEMBLY AND
OWNER'S MANUAL
WARNING! Read this manual before operating your VICTA Lawnmower.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MWR 18IN CRVT 18V TWIN and is the answer not in the manual?

Questions and answers

Lyn Serventy
February 28, 2025

How do I remove battery to charge

1 comments:
Mr. Anderson
February 28, 2025

To remove the battery from the Victa MWR 18IN CRVT 18V TWIN for charging:
1. Remove the battery or batteries from the product after use.
2. Do not store the batteries in the product.
3. Place the batteries in the charger for charging.

Refer to the Briggs & Stratton 18V Battery & Charger manual for further details on battery and charger disposal.

This answer is automatically generated

Summary of Contents for Victa MWR 18IN CRVT 18V TWIN

  • Page 1 18V LITHIUM-ION CORDLESS LAWNMOWER ASSEMBLY AND OWNER'S MANUAL WARNING! Read this manual before operating your VICTA Lawnmower.
  • Page 2 IMPORTANT INFORMATION IMPORTANT INFORMATION Details Thank you for purchasing your VICTA product. VICTA prides itself in the quality and performance of all its products. This instruction manual will aid in the assembly, safe operation and maintenance of your product. Please read the following warnings to ensure safety and the long life of your product.
  • Page 3: Table Of Contents

    Table of Contents Safety & Handling General Safety Product Disporal Emergancy Contact Features & Definitions Product Features Assembly Procedures Handle assembly parts Attaching the lower handle Installing Batteries Removing Battery Grasscatcher Assebly Grasscatcher Assebly (Fabric) Operating Instructions Quick Set Up Guide Starting and Stopping Battery Capacity Indicator Height Adjustment...
  • Page 4: General Safety

    General Safety • Keep this manual in a safe place for future reference, and consult it regularly. Ensure other users read this manual and are aware of the product safety risks. • The machine should be operated only with a genuine Briggs & Stratton Lithium-ion battery. When using battery operated machine basic safety precaution should always be followed to reduce the risk of leaking batteries and personal injury.
  • Page 5 Operation • The machine can be powered only with a genuine Briggs & Stratton Lithium-ion battery. When using battery operated machine, basic safety precaution should always be followed to reduce the risk of leaking batteries and personal injury. • Operate the machine only in daylight or in good artificial light. •...
  • Page 6: Product Disporal

    Product Disposal CORRECT DISPOSAL OF THE PRODUCT Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your local authority or retailer for recycling advice. The battery contains material which is hazardous to you and the environment. It must be removed and disposed of separately at a facility that accepts lithium-ion batteries.
  • Page 7: Product Features

    FEATURES DEFINITIONS Product Features Product Features LAWN MOWER 18INCH 18V TWIN BATTERY 1. Victa 18" Steel Lawn Mower 13. Rear Flap 2. 18V Twin Battery Powerhead 14. Height Adjustment Lever 3. Battery Cover 15. Rear Wheel 4. Control Panel 16. Rear Wheel Hubcap 5.
  • Page 8 FEATURES DEFINITIONS Product Features LAWN MOWER 16INCH 18V TWIN BATTERY 12. Grass Catcher Bag 1. Victa 18" Steel Lawn Mower 13. Rear Flap 2. 18V Twin Battery Powerhead 14. Heigh Adjustment Lever 3. Battery Cover 15. Rear Wheel 4. Control Panel 16.
  • Page 9: Handle Assembly Parts

    ASSEMBLY PROCEDURES Handle assembly parts (18Inch Lawn Mower Models) Your lawnmower should include a kit with the following parts. Refer to the product feature pages for your lawn mower's final assembled view. Lower handles 2 Handle Knobs Bail 2 Insulation Brackets Upper handle Bolts M8 x 45...
  • Page 10 ASSEMBLY PROCEDURES Handle assembly parts (16Inch Lawn Mower Models) Your lawnmower should include a kit with the following parts. Refer to the product feature pages for your lawn mower's final assembled view. Looped lower handle 2 Handle Knobs Bail 2 Insulation Brackets Upper handle See note...
  • Page 11: Installing Batteries

    ASSEMBLY PROCEDURES Installing Batteries Note:Refer to figure 1 & 2. • Lift and hold up the battery cover. • Place the batteries in the mower. Align guided ribs on battery with grooves in the product’s battery port. • Make sure the latch on bottom of the battery snaps in place and that the battery is fully seated (will "click"...
  • Page 12: Removing Battery

    ASSEMBLY PROCEDURES Removing Batteries • Release the bail to stop the product. • Remove the safety key. • Press and hold the battery release trigger button at the bottom of the battery. • Slide outward to remove the battery from the product. Do not insert any object into the battery recess other than the battery supplied.
  • Page 13 ASSEMBLY PROCEDURES Grasscatcher - hard/solid type Assembling the grasscatcher Assemble the covers 1A or 1B to the top half of the grasscatcher. Locate the centre protrusion of the mesh into the centre hole on the inside of the grasscatcher top, ensuring the curved edge of the mesh faces the rear handle. Firmly push the mesh into the top half of the grasscatcher, making sure that the four snap hooks engage securely.
  • Page 14 This feature is provided for a seemless and smooth cut. It simulates the high torque and power feeling that the Victa petrol lawn mower is known for. But this can also increase the motor temperature, draw excessive current from the battery and reduce the battery runtime.
  • Page 15: Quick Setup Guide

    OPERATING INSTRUCTIONS Quick Setup Guide 1 - READY • Remove battery or batteries & key • Check if the grass is tall or thick • Check catcher & deck are empty of grass • Check the battery is fully charged Don't adjust the mower with battery or key inserted.
  • Page 16: Starting And Stopping

    OPERATING INSTRUCTIONS Starting & Stopping o START the Mower: • Open the battery cover and insert the safety key into the slot. (See Fig.) • Press and hold the safety lock-out button (1). (See Fig.) • Pull the bail (2) upward to the handle to start the mower and release the safety lock button with feet well away from blades.
  • Page 17: Height Adjustment

    OPERATING INSTRUCTIONS Height Adjustment • Height adjustment allows lawn to be cut at different lengths. Set cut height by adjusting the height lever. STOP the motor before adjusting the cutting height. Remove Safety key before adjusting the cutting height. Mowing Tips A sharp blade will greatly enhance the performance of the mower, especially when cutting high grass.
  • Page 18 OPERATING INSTRUCTIONS Grasscatcher - Fitting 18in & 19in models Fitting the grasscatcher • Stop the engine. • Raise the rear flap. Locate the grasscatcher tongue over the rear axle and insert the grasscatcher under the rear flap. • Lower the rear flap to retain the grasscatcher. Mulching Plug - mulch Capable models only •...
  • Page 19: Emptying Grass Catcher

    Emptying the Grass Catcher • Stop mower, allow blades to completely stop, and remove battery & safety key. • Lift the rear flap. • Lift the grass catcher by its handle to remove from mower. • Empty grass clippings. • Lift the rear flap and reinstall the grass catcher as described earlier in this manual. •...
  • Page 20 Storing the Lawn Mower The following steps should be taken in order to prepare the machine for storage. • Clean the machine as described in the previous section. • Inspect the blade, and replace it or sharpen it, if required (refer to the Maintenance section).
  • Page 21 For Your Safety • Before starting the mower check blades and bolts for damage or wear. • Victa recommends that all maintenance, repair and inspection work be carried out by a Victa Authorised Service Centre. • Work from the grasscatcher flap.
  • Page 22: Blade Replacement

    Blade Replacement For Your Safety • Never use the mower unless the grasscatcher or the guards supplied by the manufacturer are in position. • Before starting the mower check blades and bolts for damage or wear. • If you strike an obstruction, stop the engine and check the blades for damage. Worn and damaged blades are major hazards.
  • Page 23 Blade Bar Replacement Cont'd NOTE: Check all fasteners often, always be sure mower is in safe operating condition. Only use VICTA genuine replacement blades. Replace worn or damaged blades and bolts in sets to preserve balance. 1. Stop the mower and allow the blade to come to a complete stop.
  • Page 24: Battery

    Before carrying out maintenance, remove the batteries and safety key. Never attempt maintenance that is not outlined in this manual. All repair work must be carried out by an Victa Authorised Service Centre. • Never tamper with safety devices. Check them regularly for proper operation.
  • Page 25: Troubleshooting

    Troubleshooting PROBLEM POSSIBLE CAUSE SOLUTION The battery is not charged. Charge the battery . The safety key is defective. Replace the safety key. Grass wrapped on blades, Remove battery, check under deck & The mower does grass catcher jammed. grass catcher for clogged grass. not start.
  • Page 26 TECHNICAL SPECIFICATIONS Specifications PRODUCT SPECIFICAITONS Description MWR 18IN CRVT 18V TWIN MWR 16IN CRVT 18V TWIN Model Number 2691861 2691891 Applicable Batteries B&S 18V 4Ah or greater B&S 18V 4Ah or greater Battery Qty Deck Type Steel Steel Deck Size...
  • Page 27 NOTES...
  • Page 28 ©2021 Briggs & Stratton Australia Pty Ltd No part of this booklet may be reproduced by any means without prior written permission. All information herein is subject to change without notice. VICTA is a registered trademark of Briggs & Stratton Australia. 80098027-A...
