Victa
Lawnmower
Assembly and
Owner's Manual
WARNING! Read this manual before operating your VICTA Lawnmower.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Electric Lawnmower and is the answer not in the manual?

Questions and answers

John marr
February 5, 2025

How do I change the oil

Summary of Contents for Victa Electric Lawnmower

  • Page 1 Victa Lawnmower Assembly and Owner’s Manual WARNING! Read this manual before operating your VICTA Lawnmower.
  • Page 2 IMPORTANTINFORMATION Labels The following warning labels are attached to your mower on purchase. Please read before discarding. 2 Stroke Label Victa 2 Stroke Engine Fuel Oil Ratio 25:1 = 200ml of Oil for 5 Litres of Fuel Victa Formula V 2 Stroke High Performance Motor Oil (fuel oil ratio 50:1) 100ml of Oil to 5 Litres of Unleaded Fuel.
  • Page 3: Table Of Contents

    Table of Contents Important Notes Safety & Handling Assembly Procedures Operating Instructions Maintenance & Care Questions & Answers Warranty National Service Directory Unit Details Safety Instructions Hazards Personal Safety Equipment Grasscatcher Handle Knobs/Toggles Mulching Plug Aerogrip Handle Assembly Assembly Procedure Attaching The Remote Air Filter Housing Height Adjustment Mulching Tips...
  • Page 4: Importantnotes

    IMPORTANTNOTES Congratulations on your purchase of a top quality Victa lawnmower. This instruction manual will aid in the assembly, operation and maintenance of your new lawnmower. Please read carefully ensure safety and the long life of your product. Do not operate the unit before reading this manual. Do not operate before reading the ‘Engine Manual’.
  • Page 5: Safety Instructions

    Safety Instructions Transporting the mower • Turn the engine off, by moving the throttle lever to the 'STOP' position and switching the fuel tap off (where fitted). • Disconnect the spark plug lead and wedge it between the cylinder head fins. •...
  • Page 6 Safety Instructions • Never lift, carry or tilt the mower when the engine is running. • Stop the engine before pushing the mower across gravel, paths or roads. Stop the engine before the mower leaves the lawn. • Stop the engine before adjusting the cutting height. •...
  • Page 7: Personal Safety Equipment

    Hazards The following safety precautions must be strictly observed to avoid the risk of damage or personal injury. • Do not smoke while operating or refuelling the mower. Never add fuel or remove the fuel cap while the engine is running or hot. If the fuel is spilt, do not start the engine. Move the mower away from the area of the spill.
  • Page 8: Assemblyprocedures

    ASSEMBLYPROCEDURES Grasscatcher Assembling the Grasscatcher 1 Assemble the adjustable covers 1A or directional covers 1B to the top half of the grasscatcher (If applicable to your model). Check that all of the snap hooks have engaged securely. 2 Locate the centre protrusion of the mesh into the centre hole on the inside of the catcher top, ensuring the curved edge of the mesh faces the rear handle.
  • Page 9: Handle Knobs/Toggles

    Grasscatcher Fitting the Grasscatcher • Stop the engine. • Raise the rear flap. Locate the grasscatcher tongue over the rear axle and insert the grasscatcher under the rear flap. • Lower the rear flap to retain the grasscatcher . STOP the engine before fitting or removing the grasscatcher. Never use the mower unless the grasscatcher and/or the rear flap are correctly assembled and fitted.
  • Page 10: Mulching Plug

    ASSEMBLYPROCEDURES Mulching Plug • Stop the engine and set the mower height setting. • Mulching is most effective between height settings 4 and 10. • Lift the rear flap and identify the support plate as shown. Note the orientation of the mulching plug.
  • Page 11: Aerogrip Handle Assembly

    Aerogrip Handle Assembly Assembly Procedure 1. Unscrew fastening knobs and outer mating pieces from each side of pivot joint assembly. 2. Lay the upper handle across the engine cowl of the lawnmower, with the bend facing down (see fig 1). 3.
  • Page 12: Attaching The Remote Air Filter Housing

    ASSEMBLYPROCEDURES Attaching The Remote Air Filter Housing 2 Stroke Models Aerogrip handle Screw (Please Note: Do not over tighten) 2 Stroke Models Slide the air filter housing onto the upper handle. Position locating lug into hole in handle and secure with screw (see Fig.3). Be careful not to over tighten, as the plastic thread may be damaged.
  • Page 13: Height Adjustment

    OPERATINGINSTRUCTIONS Height Adjustment Height adjustment allows lawn to be cut at different lengths. • Set cutting height by adjusting the height lever. • For Mulch or Catch models, mulch grass between settings 4 to 10. • A lower setting may be used depending upon conditions. STOP the engine before adjusting the cutting height.
  • Page 14: Cleaning

    Cleaning Before cleaning the mower, ensure the throttle lever is in the 'STOP' position. Turn the fuel tap off, disconnect the spark plug lead and wedge it between the cylinder fins, and disconnect the battery on Keystart models. • Remove grass build up from the air intakes on the top of the mower cowl, around the engine and carburettor, and around the air filter body.
  • Page 15: Blade Replacement

    Text Blade Replacement Model All 19” Steel & Alloy Chassis Models For Your Safety • Never use the mower unless the grasscatcher or the guards supplied by the manufacturer are in position. • Before starting the mower check blades and bolts for damage or wear. •...
  • Page 16: Remote Air Filter Maintenance

    Remote Air Filter Maintenance For correct engine performance and to guard against dust entering the engine, causing rapid wear, the air filter assembly must be clean and maintained in good condition. VICTA recommends that the air filter element and seal ring are replaced annually, or more often in dusty conditions.
  • Page 17 Remote Air Filter Maintenance – Aerogrip handles 1. Examine the air filter hosing for holes, chafing and leaks. Replace it if damaged. 2. Remove the top cover of the air filter housing by squeezing the latch on the underside of the housing and lifting upwards.
  • Page 18: Maintenance Chart

    Maintenance Chart Refer to the following table for routine maintenance. Features Lawnmower Throttle lever Remote Air filter hose Cutting System (Blades) Rear flap Chassis Air filter Engine Cylinder fins Spark plug All accessible fasteners Engine mounting bolts Mulching plug Muffler Grasscatcher Before carrying out maintenance, STOP the engine, disconnect the spark plug lead from the spark plug and wedge it between the...
  • Page 19: Troubleshooting

    Troubleshooting In small engines generally, difficult starting and erratic running is most often caused by a dirty spark plug. If a new spark plug of the correct type does not restore the engine to proper operating condition, the problem may be solved by reference to the chart below. Problem Possible cause Does not start...
  • Page 20: Warranty

    WARRANTY Warranty Consumer Rights The buyer should be aware that in relation to goods which are of a kind ordinarily acquired for personal, domestic or household use or consumption, certain provisions such as the Trade Practices Act, 1974 (Aust) and the Consumer Guarantees Act, 1993 (NZ) apply. The terms set out below do not exclude rights and remedies implied by a statute which are non-excludable and which may be more extensive than those provided by this warranty.
  • Page 21 (cont.) Warranty Conditions (cont.) You should seek independent legal advice to determine whether a claim not covered by the Express Warranty is covered by any warranties implied by law. • Express Warranty applies to the original purchaser only. Proof of purchase date must be provided prior to Express Warranty work.
  • Page 22 NATIONAL SERVICE DIRECTORY NEW SOUTH WALES NSW - SYDNEY METROPOLITAN BEVERLY HILLS 2209 BEVERLY HILLS MOWERS 108 STONEY CREEK ROAD ...02 9570 5771 BLACKTOWN 2148 INDEPENDENT MOWER CENTRE UNIT 6, 12 ROMFORD ROAD...02 9622 5188 CAMDEN 2570 MACARTHUR MOWERS 2 IRONBARK AVENUE ...02 4655 7793 CAMPSIE 2194 HARRISON'S MOWERS 78-80 BEAMISH STREET...02 9789 6061...
  • Page 23 NATIONAL SERVICE DIRECTORY MORUYA 2537 MORUYA MOWER & CHAINSAW CENTRE FORD STREET...02 4474 3322 MUDGEE 2850 BILL'S MUDGEE CHAINSAW CENTRE 10 INDUSTRIAL AVENUE...02 6372 4122 NARRANDERA 2700 EURELLS 16 BOLTON STREET...02 6959 2949 NEWCASTLE 2296 NEWCASTLE CHAINSAWS 158 MAITLAND ROAD, &...
  • Page 24 NATIONAL SERVICE DIRECTORY VICTORIA - COUNTRY ALBURY (NSW) 2640 ALBURY ENG. & MOWER SERVICE 208 BORELLA ROAD...02 6041 1444 BAIRNSDALE 3875 B & J CRANE PTY LTD 92 MCLEOD STREET...03 5152 3008 BALLARAT 3350 HENDERSON MOTOR MOWERS 119 MAIR STREET ...03 5331 1618 BEECHWORTH 3747 BEECHWORTH MACHINERY 30-32 HIGH STREET ...03 5728 2531...
  • Page 25 NATIONAL SERVICE DIRECTORY SANDGATE 4017 SANDGATE MOWER CENTRE 53 RAINBOW STREET ...07 3269 2702 STAFFORD 4053 STAFFORD MOWERS UNIT 1, 6 HARVTON STREET ...07 3356 6459 SUMNER PARK 4074 JINDALEE MOWER CENTRE 7/97 JIJAWS STREET...07 3376 5163 VICTORIA POINT 4165 VICTORIA POINT MOWER CENTRE UNIT 8B, 21-27 BUNKER ROAD...07 3207 0122 WINDSOR...
  • Page 26 NATIONAL SERVICE DIRECTORY SOUTH AUSTRALIA - COUNTRY ALICE SPRINGS (NT) 0871 FIDLER & SCARCE PTY LTD UNIT 4, 31 ELDER STREET ...08 8952 2566 BORDERTOWN 5268 J C & P A HORNE 18 RAMSEY TERRACE...08 8752 1617 CLARE 5453 W.S.B. DISTRIBUTORS 198 MAIN ROAD...08 8842 2177 CLEVE 5640 RAMSEY BROS...
  • Page 27 NOTES...
  • Page 28 ©2004 Victa Lawncare Pty Ltd Victa is a trademark of Victa Ltd. Victa Razor & Aerogrip are registered trademarks of Victa Ltd. All rights reserved. No part of this booklet may be reproduced by any means without prior written permission. All information herein is subject to change without notice. LR00803A...
