SWIMMING POOL HEAT PUMP UNIT
Installation & Instruction Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMHP170 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for atecpool AMHP170

Summary of Contents for atecpool AMHP170

  • Page 1 SWIMMING POOL HEAT PUMP UNIT Installation & Instruction Manual...

  • Page 3: Table Of Contents

    CONTENTS 1. Preface 1.1 Preface 1.2 Safe precautions 2. Specifications 2.1 Performance Data of Swimming Pool Heat Pump Unit 2.2 Dimensions for Swimming Pool Heat Pump Unit 3. Installation and Connection 3.1 Installation of System 3.2 Swimming Pool Heat Pumps Location 3.3 How Close to Your Pool? 3.4 Swimming Pool Heat Pumps Plumbing 3.5 Swimming Pool Heat Pumps Electrical Wiring...

  • Page 4: Preface

    1. PREFACE 1.1 PREFACE In order to provide our customers with quality, reliability and versatility, this product has been made to strict production standards. This manual includes all the necessary information about installation, debugging, discharging and maintenance. Please read this manual carefully before you open or maintain the unit.

  • Page 5: Safe Precautions

    1. PREFACE 1.2 Safety precautions ELECTRICAL POWER MUST BE SWITCHED OFF BEFORE STARTING ANY WORK ON JUNCTION BOXES The aim of this manual is to provide instructions for installation, commissioning, operation. WARNING ! Take care ! The installation, commissioning and The unit should be handled using lifting and maintenance of these machines should be handling equipment appropriate to the unit's...

  • Page 6: Specifications

    2.SPECIFICATION 2.1 Performance data of Swimming Pool Heat Pump Unit *** REFRIGERANT : R410A Unit AMHP170 Cooling Capacity Boost Mode) BTU/h 327645 Cooling Capacity 59.4-73.4 BTU/h 202673-250441 Cooling Power Input 13.81-13.85 Heating Capacity(Boost Mode) BTU/h 597269 Heating Capacity 28.2-130 BTU/h...

  • Page 7: Dimensions For Swimming Pool Heat Pump Unit

    2.SPECIFICATION 2.2 The dimensions for Swimming Pool Heat Pump Unit Model: AMHP170 unit mm Airflow direction 2130 1150...

  • Page 8: Installation And Connection

    3.INSTALLATION AND CONNECTION 3.1 Installation illustration Valve Chlorinator cell Water outlet Water supply Pool Water inlet Sand filter Water pump (or other type filter) Installation items: The factory only provides the main unit and the water unit; the other items in the illustration are necessary spare parts for the water system ,that provided by users or the installer.

  • Page 9: Swimming Pool Heat Pumps Location

    3.INSTALLATION AND CONNECTION 3.2 Swimming Pool Heat Pumps Location The unit will perform well in any outdoor location provided that the following three factors are presented: 1. Fresh Air - 2. Electricity - 3. Pool filter piping The unit may be installed virtually anywhere outdoors. For indoor pools please consult the supplier.

  • Page 10: Swimming Pool Heat Pumps Plumbing

    3.INSTALLATION AND CONNECTION 3.4 Swimming Pool Heat Pumps Plumbing The Swimming Pool Heat Pumps exclusive rated flow titanium heat exchanger requires no special plumbing arrangements except bypass(please set the flow rate according to the nameplate). The water pressure drop is less than 10kPa at max. Flow rate. Since there is no residual heat or flame Temperatures, The unit does not need copper heat sink piping.

  • Page 11: Swimming Pool Heat Pumps Electrical Wiring

    3.INSTALLATION AND CONNECTION 3.5 Swimming Pool Heat Pumps Electrical Wiring NOTE: Although the unit heat exchanger is electrically isolated from the rest of the unit, it simply prevents the flow of electricity to or from the pool water. Grounding the unit is still required to protect you against short circuits inside the unit.

  • Page 12: Usage And Operation

    4.USAGE AND OPERATION 1.Function introduction of line controller Main display area Supplementary Display area Time display area 1 Button function Button Button Function Name Icon Power Using for power on/off, cancel present operation On/off And back to the last operation Time Using for time setting and timing setting Temp unit...
  • Page 13 4.USAGE AND OPERATION 2 Display function Icon Meaning Function Cooling Display at cooling mode Heating Display at heating mode Automatic Display at automatic mode Mode Lighted on when defrosting Defrosting Lighted on when main display area shows inlet water temp Water inlet Lighted on when supplementary display area shows outlet Water outlet...

  • Page 14: Usage Of The Controller

    4.USAGE AND OPERATION Usage of the controller 2.1 Power on/off At the power on state, press for 0.5s to power off, the screen displays units mode, main display area shows OFF; At the power off state, press for 0.5s to power on, the screen displays units mode, main display area shows inlet water temp, supplementary display area shows outlet water temp.
  • Page 15 4.USAGE AND OPERATION Heating icon keeps lighted on, mode switch succeed. 2.3 Target temp setting You can set suitable cooling target temp, heating target temp, automatic mode target temp (Target temp default referring to parameter table) Automatic mode target temp: when the actual inlet water temp higher than the target temp, the units start cooling;...
  • Page 16 4.USAGE AND OPERATION 2.4 Advanced user interface At the advanced user interface, you can set the time of system, switch the temperature from centigrade to fahrenheit, sound on/off, timer setting, status inquiry. On the main interface, press to entrance senior interface. For example: Advanced user interface: Power on main interface:...
  • Page 17 4.USAGE AND OPERATION Press to save the setting of hour place Minute digit flashes Hour digit flashes Press Press to back to set the minute digit Minute digit flashes System time not updated Press to save hour digit setting. Press to go back System time updating finished Hour digit updated...
  • Page 18 4.USAGE AND OPERATION 2.4.2 Timing power on/off and timing low speed setting 1). Timing power on/off setting At the advanced user interface, long press for 2s to enter timer 1 power on setting interface, ON 1 in the timing display area and the time display area will flash (press to change between OFF 1, ON 2, OFF 2 and timing low speed,press , hour digit flashes, the setting method is the same as 2.4.1 System time setting .
  • Page 19 4.USAGE AND OPERATION Press to save hour digit setting minute digit flashes automatically Hour digit flashes Hour digit lighted on, Press minute digit flashes change minute digit Press to save minute digit setting, ON 2 flashes automatically Minute digit flashes Press to skip ON 2 and other timing...
  • Page 20 4.USAGE AND OPERATION Long press for 2s Press to go back ON 1and - -:- - flash Press for 4 times skip the ON 1 OFF 1 ON 2 OFF 2 setting to low speed ON setting Press hour digit flashes Hour digit flashes Mute icon lighted on ON and - -:- - flash...
  • Page 21 4.USAGE AND OPERATION When timing low speed setting finished, mute and timing icons lighted on at the same time: mute and timing icons lighted on at the same time Mute function: same to timing low speed except that the mute function will be turned off after 8h if the users have not turned off it for a long time.
  • Page 22 4.USAGE AND OPERATION Press cancel the ON1 setting of timer1 ON 1 canceled Hour digit flashes ON 1and - -:- - flash Press go back Timing power on of timer 1 has been finished 2.4.4 Switch between Fahrenheit and Celcius At the advanced user interface, press to circularly change between fahrenheit and celcius.
  • Page 23 4.USAGE AND OPERATION 2.4.5 Units running state check At the advanced user interface, long press for 2s to enter running state page, press to circularly change every state. Specific meaning please refer to Running state table . For example: State value Long press to enter state checking page...
  • Page 24 4.USAGE AND OPERATION 2.4.7 Setting boost mode At power on off main interface long press to enter state setting boost mode. At the setting boost state, press to change it boost parameter flashes Long press to enter state setting boost mode Press to back or back to main interface...

  • Page 25: Parameter Table

    4.USAGE AND OPERATION 2.4.8 Fault display When the units break down it will display the relevant code according to the fault reason. Refer to the Fault table for detailed code meaning. For example: Fault code Press to circularly change the fault Fault No.

  • Page 26: Controller Interface Diagram And Definition

    OPERATION AND USE 4.5 Controller interface diagram and definition PC1602...

  • Page 27: Maintenance And Inspection

    5. MAINTENANCE AND INSPECTION Check the water supply device and the release often. You should avoid the condition of no water or air entering into system, as this will influence unit's performance and reliability. You should clear the pool/spa filter regularly to avoid damage to the unit as a result of the dirty of clogged filter.

  • Page 28: Appendix

    6.APPENDIX 6.1 Caution & Warning 1. The unit can only be repaired by qualified installer centre personnel or an authorised dealer(for Europe market). 2. This appliance can used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved(for Europe market).

  • Page 29: Usage Of The Controller

    6.APPENDIX 6.2 Cable specification (1) Single phase unit Nameplate Creepage protector Signal line maximum Phase line Earth line current No more 2 1.5mm 1.5mm 30mA less than 0.1 sec than 10A 2 2.5mm 2.5mm 30mA less than 0.1 sec 10~16A 2 4mm 30mA less than 0.1 sec 16 ~25A...
  • Page 30 Note:...
  • Page 31 Note:...
  • Page 32 Code 20210819-0001...
