SWIMMING POOL HEAT PUMP UNIT
Installation & Instruction Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMHP110 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for atecpool AMHP110

Summary of Contents for atecpool AMHP110

  • Page 1 SWIMMING POOL HEAT PUMP UNIT Installation & Instruction Manual...

  • Page 3: Table Of Contents

    CONTENTS 1. Preface 1.1 Preface 1.2 Safe precautions 2. Specifications 2.1 Performance Data of Swimming Pool Heat Pump Unit 2.2 Dimensions for Swimming Pool Heat Pump Unit 3. Installation and Connection 3.1 Installation of System 3.2 Swimming Pool Heat Pumps Location 3.3 How Close to Your Pool? 3.4 Swimming Pool Heat Pumps Plumbing 3.5 Swimming Pool Heat Pumps Electrical Wiring...

  • Page 4: Preface

    1. PREFACE 1.1 PREFACE In order to provide our customers with quality, reliability and versatility, this product has been made to strict production standards. This manual includes all the necessary information about installation, debugging, discharging and maintenance. Please read this manual carefully before you open or maintain the unit.

  • Page 5: Safe Precautions

    1. PREFACE 1.2 Safety precautions ELECTRICAL POWER MUST BE SWITCHED OFF BEFORE STARTING ANY WORK ON JUNCTION BOXES The aim of this manual is to provide instructions for installation, commissioning, operation. WARNING ! Take care ! The installation, commissioning and The unit should be handled using lifting and maintenance of these machines should be handling equipment appropriate to the unit's...

  • Page 6: Specifications

    2.SPECIFICATION 2.1 Performance data of Swimming Pool Heat Pump Unit *** REFRIGERANT : R410A Unit AMHP110 Cooling Capacity 8.2-18.4 BTU/h 27978-62781 Cooling Power Input 2.02-6.28 Heating Capacity 12.2-65 BTU/h 41626-221780 Heating Power Input 0.76-10.65 Running Current Power Supply 380V~415V~/3PH～/50Hz Compressor Quantity...

  • Page 7: Dimensions For Swimming Pool Heat Pump Unit

    2.SPECIFICATION 2.2 The dimensions for Swimming Pool Heat Pump Unit Model: AMHP110 unit：mm Airflow direction Water outlet Φ63 Drainage Φ32 Water inlet Φ63 1750...

  • Page 8: Installation And Connection

    3.INSTALLATION AND CONNECTION 3.1 Installation illustration Valve Chlorinator cell Water outlet Water supply Pool Water inlet Sand filter Water pump (or other type filter) Installation items: The factory only provides the main unit and the water unit; the other items in the illustration are necessary spare parts for the water system ,that provided by users or the installer.

  • Page 9: Swimming Pool Heat Pumps Location

    3.INSTALLATION AND CONNECTION 3.2 Swimming Pool Heat Pumps Location The unit will perform well in any outdoor location provided that the following three factors are presented: 1. Fresh Air - 2. Electricity - 3. Pool filter piping The unit may be installed virtually anywhere outdoors. For indoor pools please consult the supplier.

  • Page 10: Swimming Pool Heat Pumps Plumbing

    3.INSTALLATION AND CONNECTION 3.4 Swimming Pool Heat Pumps Plumbing The Swimming Pool Heat Pumps exclusive rated flow titanium heat exchanger requires no special plumbing arrangements except bypass(please set the flow rate according to the nameplate). The water pressure drop is less than 10kPa at max. Flow rate. Since there is no residual heat or flame Temperatures, The unit does not need copper heat sink piping.

  • Page 11: Swimming Pool Heat Pumps Electrical Wiring

    3.INSTALLATION AND CONNECTION 3.5 Swimming Pool Heat Pumps Electrical Wiring NOTE: Although the unit heat exchanger is electrically isolated from the rest of the unit, it simply prevents the flow of electricity to or from the pool water. Grounding the unit is still required to protect you against short circuits inside the unit.

  • Page 12: Usage And Operation

    USAGE AND OPERATION 1.Function introduction of line controller Main display area reset Supplementary display area Time display area ） Button function Button Button Function Name Icon Power Using for power on/off, cancel present operation On/off and back to the last operation Time Using for time setting and timing setting Temp unit...
  • Page 13 USAGE AND OPERATION 2）Display function Meaning Function Icon Cooling Display at cooling mode Heating Display at heating mode Automatic Display at automatic mode Mode Defrosting Lighted on when defrosting Lighted on when main display area shows inlet water temp Water inlet Lighted on when supplementary display area shows outlet Water outlet water temp...

  • Page 14: Usage Of The Controller

    USAGE AND OPERATION 2.Usage of the controller 2.1 Power on/off At the power on state, press for 0.5s to power off, the screen displays units mode, main display area shows OFF. At the power off state, press for 0.5s to power on, the screen displays units mode, main display area shows inlet water temp, supplementary display area shows outlet water temp.
  • Page 15 USAGE AND OPERATION 2.2 Mode switch At power on/off main interface, continually press to circularly switch among cooling, heating and automatic mode. ttention : If your units are single cooling or single heating type, the mode switch is invalid. Cooling mode Heating mode Short press to switch the mode...
  • Page 16 USAGE AND OPERATION 2.3 Target temp. setting At power on/off main interface, press and present mode target temp. flashes, press to make the value increase. Press to make the value decrease. Press save the setting and back to power on/off main interface. Press will not save the setting but get back to power on/off main interface.
  • Page 17 USAGE AND OPERATION 2.4 Advanced user interface At the advanced user interface, you can set the time of system, sound on/off, timer setting. At the main interface, press to enter advanced user interface. For example: Power on main interface: Advanced user interface: Press to enter the advanced user interface.
  • Page 18 USAGE AND OPERATION Press to enter the interface of system time setting. Press or no operation for 20s to power on/off back to the interface. Hour digit flashes Press set the hour digit. Press to save the settings of hour digit. Minute digit flashes Hour digit flashes Press...
  • Page 19 USAGE AND OPERATION 2.4.2 Timing power on/off and timing mute setting 1). Timing power on/off setting At the advanced user interface, press for 2s to enter timer 1 power on setting interface, ON 1 in the timing display area and the time display area will flash (press to change among ON1, OFF 1, ON 2, OFF 2 and timing low speed.
  • Page 20 USAGE AND OPERATION Press to save hour digit setting, minute digit flashes automatically. Hour digit flashes Hour digit lights up, Press minute digit flashes change minute digit Press to save minute digit setting, ON 2 flashes automatically. Minute digit flashes Press to return to advanced user interface.
  • Page 21 USAGE AND OPERATION Press for 2s. Press to go back. Press for 4 times，skip the ON 1and - -:- - flash ON 1、OFF 1、ON 2、OFF 2 setting to mute ON setting. Press and then hour digit flashes. Hour digit flashes Mute icon lighted on ON and - -:- - flash Press...
  • Page 22 USAGE AND OPERATION When timing mute setting finished, mute and timing icons lighted on at the same time: mute and timing icons lighted on at the same time Mute function: The same as timing mute, but if the user does not turn off the mute function for a long time, it will turn off after 8 hours.
  • Page 23 USAGE AND OPERATION 2.4.3 Cancel the timing setting The hour or minute must be in flashing when cancel the timing setting. Press to cancel. For example: Press for 2s to enter ON1 of timer 1. ON 1 and the whole Timer 1 timing power on succeed time digit flashes Press...
  • Page 24 USAGE AND OPERATION 2.5 Keyboard lock At power on/off main interface, long press for 5s to lock the keyboard. At the keyboard locked state, long press for 5s to unlock it. Attention: At the lock interface, can only unlock the unit, other operations are invalid. Press to lock or unlock the keyboard.
  • Page 25 USAGE AND OPERATION 2.7 Fault display When the units break down, it will display the relevant code according to the fault reason. Refer to the“Fault table”for detailed code meaning. For example: Fault code Press to circularly change the fault. Fault amount Fault No.

  • Page 26: Parameter List And Breakdown Table

    USAGE AND OPERATION 3. Parameter list and breakdown table (1) Electronic control fault table Can be judged according to the remote controller failure code and troubleshooting Fault Protect/fault Reason Elimination methods display The temp. Sensor is broken Check or change the temp. Sensor Inlet Temp.
  • Page 27 OPERATION AND USE 1. Motor is in locked-rotor state 1.Change a new fan motor 2.The wire connection between 2.Check the wire connection and make sure Fan Motor2 Fault F032 DC-fan motor module and fan they are in good contact motor is in bad contact Frequency conversion board fault table: Fault Protection/fault...

  • Page 28: Parameter Table

    OPERATION AND USE 4. Parameter table Default Remark Meaning 27℃ Heating inlet target temp. Adjustable Cooling inlet target temp. 27℃ Adjustable 27℃ Auto inlet target temp. Adjustable 5. Interface drawing 5.1 Wire control interface diagram and definition Sign Meaning 12V（power +） 485A 485B GND ( power - )
  • Page 29 OPERATION AND USE Main board of the input and output interface instructions below Number Sign Meaning OUT1 Compressor ( output 220-230VAC） OUT2 Water pump ( output 220-230VAC） OUT3 4-way valve ( output 220-230VAC） OUT4 Chassis heating belt OUT5 Electrical heating AC-L Live wire ( input 220-230VAC）...

  • Page 30: Maintenance And Inspection

    5. MAINTENANCE AND INSPECTION Check the water supply device and the release often. You should avoid the condition of no water or air entering into system, as this will influence unit's performance and reliability. You should clear the pool/spa filter regularly to avoid damage to the unit as a result of the dirty of clogged filter.

  • Page 31: Appendix

    6.APPENDIX 6.1 Caution & Warning 1. The unit can only be repaired by qualified installer centre personnel or an authorised dealer(for Europe market). 2. This appliance can used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved(for Europe market).
  • Page 32 6.APPENDIX 6.2 Cable specification (1) Single phase unit Nameplate Creepage protector Signal line maximum Phase line Earth line current No more 2×1.5mm 1.5mm 30mA less than 0.1 sec than 10A 2×2.5mm 2.5mm 30mA less than 0.1 sec 10~16A 2×4mm 30mA less than 0.1 sec 16 ~25A 2×6mm 6 mm...
  • Page 33 Note:...
  • Page 34 Note:...
  • Page 36 Code：20210727-0001...
