TMG -SFM60 Product Manual

Skid steer forestry drum mulcher attachment
Hide thumbs

Advertisement

Quick Links

Download this manual
Skid Steer Forestry Drum Mulcher Attachment
www.tmgindustrial.com (USA)
•
Please read the product manual completely before assembly
•
Check against the parts list to make sure all parts are received
•
Wear proper safety goggles or other protective gears while in assembly
Missing parts or questions on assembly?
Please call: 1-877-761-2819 or email: cs@tmgindustrial.com
Do not return the product to dealer, they are not equipped to handle your
requests
www.tmgindustrial.ca (Canada)
PRODUCT MANUAL
Model:TMG-SFM60
Toll Free:1-877-761-2819

Advertisement

loading
Need help?

Need help?

Do you have a question about the TMG-SFM60 and is the answer not in the manual?

Questions and answers

Related Manuals for TMG TMG-SFM60

Summary of Contents for TMG TMG-SFM60

  • Page 1 PRODUCT MANUAL Skid Steer Forestry Drum Mulcher Attachment Model:TMG-SFM60 • Please read the product manual completely before assembly • Check against the parts list to make sure all parts are received • Wear proper safety goggles or other protective gears while in assembly Missing parts or questions on assembly? Please call: 1-877-761-2819 or email: cs@tmgindustrial.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS TO THE OWNER..........................2/27 SAFETY PRECAUTIONS........................3/27 SKID STEER FORESTRY DRUM MULCHER ATTACHMENT ASSEMBLY.........7/27 OPERATION INSTRUCTIONS......................21/27 MAINTENANCE INSTRUCTIONS.......................23/27 STORAGE INSTRUCTIONS........................26/27 SPECIFICATIONS..........................27/27 www.tmgindustrial.com (USA) www.tmgindustrial.ca (Canada) Toll Free:1-877-761-2819 P 1 / 27...

  • Page 3: To The Owner

    TO THE OWNER GENERAL COMMENTS Congratulations for having this skid steer forestry drum mulcher attachment! Your skid steer forestry drum mulcher attachment was carefully designed and manufactured to give you years of dependable service. Your skid steer forestry drum mulcher attachment will require some minor maintenance(such as cleaning and lubricating) to keep it in top working condition.

  • Page 4: Safety Precautions

    SAFETY PRECAUTIONS The skid steer forestry drum mulcher attachments are designed to be easy to use and maintain. They are operated by the skid steer auxiliary hydraulics. The skid steer forestry drum mulcher attachments mount to the toolbar or quick attach mechanism for easy mounting.
  • Page 5 SAFETY PRECAUTIONS These are common practices that may or may not be applicable to the products described in this manual. www.tmgindustrial.com (USA) www.tmgindustrial.ca (Canada) Toll Free:1-877-761-2819 P 4 / 27...
  • Page 6 SAFETY PRECAUTIONS www.tmgindustrial.com (USA) www.tmgindustrial.ca (Canada) Toll Free:1-877-761-2819 P 5 / 27...
  • Page 7 SAFETY PRECAUTIONS www.tmgindustrial.com (USA) www.tmgindustrial.ca (Canada) Toll Free:1-877-761-2819 P 6 / 27...

  • Page 8: Skid Steer Forestry Drum Mulcher Attachment Assembly

    SKID STEER FORESTRY DRUM MULCHER ATTACHMENT ASSEMBLY www.tmgindustrial.com (USA) www.tmgindustrial.ca (Canada) Toll Free:1-877-761-2819 P 7 / 27...
  • Page 9 SKID STEER FORESTRY DRUM MULCHER ATTACHMENT ASSEMBLY www.tmgindustrial.com (USA) www.tmgindustrial.ca (Canada) Toll Free:1-877-761-2819 P 8 / 27...
  • Page 10 SKID STEER FORESTRY DRUM MULCHER ATTACHMENT ASSEMBLY PART NO. S/N NUMBER PART DESCRIPTION QTYS NOTE 051360-01 Cutting Drum Assembly 051360-02 Bolt M8X16 051360-03 Spring Washer D8 051360-04 Flat Washer D8 051360-05 Mechanical Transmission Assembly 051360-06 Transparent Air tubeφ 12-600 051360-07 Pagoda-Shape Connector G3/8 051360-08 Hose Clampφ...
  • Page 11 SKID STEER FORESTRY DRUM MULCHER ATTACHMENT ASSEMBLY PART NO. S/N NUMBER PART DESCRIPTION QTYS NOTE 051360-19 Flat Washer D16 051360-20 Nut M16 051360-21 Upper Refueling Board 051360-22 Upper Cover Plate 1 051360-23 Hexagon Bolt M8x20 051360-24 Hexagon Bolt M16x50 051360-25 Hydraulic System 051360-26 Hexagon Bolt M8x25...
  • Page 12 SKID STEER FORESTRY DRUM MULCHER ATTACHMENT ASSEMBLY PART NO. S/N NUMBER PART DESCRIPTION QTYS NOTE 051360-38 Hexagon Bolt M10x30 051360-39 Spring Washer D10 051360-40 Flat Washer D10 051360-41 Hexagon Bolt M12x40 051360-42 Hexagon Bolt M16x120 051360-43 Pull Rod 051360-44 Hexagon Bolt M16x90 051360-45 Front Push Bar 051360-46...
  • Page 13 SKID STEER FORESTRY DRUM MULCHER ATTACHMENT ASSEMBLY Cutting Drum Assembly Figure A www.tmgindustrial.com (USA) www.tmgindustrial.ca (Canada) Toll Free:1-877-761-2819 P 12 / 27...
  • Page 14 SKID STEER FORESTRY DRUM MULCHER ATTACHMENT ASSEMBLY PART NO. S/N NUMBER PART DESCRIPTION QTYS NOTE 051360-01-01 Hexagon Bolt M6x25 051360-01-02 Spring Washer D6 051360-01-03 Flat Washer D6 051360-01-04 Seal End Cap A 051360-01-05 O-ring 147x1.8 051360-01-06 Round Nut M65x2 051360-01-07 Cylindrical Roller Bearing 051360-01-08 Left Bearing Seat...
  • Page 15 SKID STEER FORESTRY DRUM MULCHER ATTACHMENT ASSEMBLY PART NO. S/N NUMBER PART DESCRIPTION QTYS NOTE 051360-01-18 Left Drive Shaft 051360-01-19 Cutting Drum 051360-01-20 Cutting Tooth 051360-01-21 Outer Hexagon Bolt M16x60 051360-01-22 Flat Washer D16 051360-01-23 Spring Washer D16 051360-01-24 Right Connecting Shaft 051360-01-25 Sealing Cover 051360-01-26...
  • Page 16 SKID STEER FORESTRY DRUM MULCHER ATTACHMENT ASSEMBLY Mechanical Transmission Assembly Figure B www.tmgindustrial.com (USA) www.tmgindustrial.ca (Canada) Toll Free:1-877-761-2819 P 15 / 27...
  • Page 17 SKID STEER FORESTRY DRUM MULCHER ATTACHMENT ASSEMBLY PART NO. S/N NUMBER PART DESCRIPTION QTYS NOTE 0513-05-01 Synchronous Belt 0513-05-02 Driven Wheel 0513-05-03 Expansion Sleeve Z2-60X90 0513-05-04 Hexagon Bolt M12x45 0513-05-05 Spring Washer D12 0513-05-06 Flat Washer D12 0513-05-07 Rotation Shaft 0513-05-08 Square Steel 0513-05-09...
  • Page 18 SKID STEER FORESTRY DRUM MULCHER ATTACHMENT ASSEMBLY PART NO. S/N NUMBER PART DESCRIPTION QTYS NOTE 0513-05-16 Flat Washer D20 0513-05-17 Bearing End Cover 0513-05-18 O-ring 0513-05-19 Skeleton Seal 0513-05-20 Output Shaft 0513-05-21 Cylindrical Roller Bearing 0513-05-22 Lock Nut 0513-05-23 Stop Gasket 0513-05-24 Bearing Seat 0513-05-25...
  • Page 19 SKID STEER FORESTRY DRUM MULCHER ATTACHMENT ASSEMBLY Hydraulic System Figure C www.tmgindustrial.com (USA) www.tmgindustrial.ca (Canada) Toll Free:1-877-761-2819 P 18 / 27...
  • Page 20 SKID STEER FORESTRY DRUM MULCHER ATTACHMENT ASSEMBLY PART NO. S/N NUMBER PART DESCRIPTION QTYS NOTE 051360-25-01 Pressure Tap 051360-25-02 Manifold Block 051360-25-03 Drain Hose A 051360-25-04 Bulkhead Connector 051360-25-05 End Straight Joint 051360-25-06 Angle one-way valve 051360-25-07 End Straight Joint 051360-25-08 Drain Hose B 051360-25-09...
  • Page 21 SKID STEER FORESTRY DRUM MULCHER ATTACHMENT ASSEMBLY PART NO. S/N NUMBER PART DESCRIPTION QTYS NOTE 051360-25-17 Right Angle Combination Joint 051360-25-18 Pressure Gauge(40MPa) 051360-25-19 Radiator Hose 051360-25-20 Oil Cooled Radiator 051360-25-21 End Straight Joint 051360-25-22 Plug 051360-25-23 Tubular Check Valve 051360-25-24 Straight Combined Connection Joint 051360-25-25...

  • Page 22: Operation Instructions

    OPERATION INSTRUCTIONS The skid steer forestry drum mulcher attachment has the reasonable structure, small volume, flexible use, high efficiency, reliable quality and superior performance. Attach the skid steer forestry drum mulcher attachment to the toolbar or quick attach mechanism of your skid steer loader. START OPERATION A.
  • Page 23 OPERATION INSTRUCTIONS E. During operation, do not lift the mulcher too high, in case the protection chains lose the protective effect on the operator, as the cutting pieces are easy to hurt the operator. F. Do not forward the skid steer loader too fast, as the fast speed not only causes the hydraulic system pressure of the skid steer loader too high, but also casues the high heat.

  • Page 24: Maintenance Instructions

    MAINTENANCE INSTRUCTIONS Regular maintenance on mulcher is the key to remain its long working life and safety work. The maintenance items described below are more important. a. Check all the bolts and nuts whether loosen, and tighten them. b. Check hydraulic system of the mulcher whether leak, replace leaked hose joints or oil hoses timely.
  • Page 25 MAINTENANCE INSTRUCTIONS (d2).The Other Side of Transmission End: Drain the old oil before refill, about 0.15 L at a time (d3).Installation Position of Motor Drain the old oil before refill, about 0.2 L at a time www.tmgindustrial.com (USA) www.tmgindustrial.ca (Canada) Toll Free:1-877-761-2819 P 24 / 27...
  • Page 26 MAINTENANCE INSTRUCTIONS e. Regularly check belt tension, general inspection once every 100 hours. f. Clean up debris and dirt on its cutting drum and other parts after mulcher. g. Be sure to turn off the engine of your skid steer loader when maintain the mulcher, and hang up the "maintenance"...

  • Page 27: Storage Instructions

    STORAGE INSTRUCTIONS 1. Clean all the debris, all mud, dirt and grease. 2. Inspect the unit for bent, loose, cracked, damaged or missing parts, Order any parts required, and make the necessary repairs to avoid delays when starting next season. 3.

  • Page 28: Specifications

    SPECIFICATIONS MODEL TMG-SFM60 TOTAL LENGTH (MM) TOTAL WIDTH (MM) 1860 TOTAL HEIGHT (MM) 1680 TRANSPORT HEIGHT (MM) 1080 WORKING WIDTH (MM) 1550 FLOW RATING (GPM) 24-32 MAX. PRESSURE (PSI) 3045 ≤100 MULCHING DEPTH (MM) NUMBER OF CUTTING BLADES (PCS) WEIGHT(KGS)
