nader NDM2 Series Product Manual page 5

操作方式
7
Operation mode
极数
8
Pole number
脱扣器代号
9
Release form code
附件代号
10
Accessory code
用途代号
11
For Application code
4 极产品中 N 极(中性极)
形式
12
N-pole type of four pole
product below
额定电流
13
Setting current
接线方式
14
Cabling type
地址：上海市浦东新区申江南路 2000 号
文件编号：NDT2920016
M：较高分断型 type M:Less high breaking type
H：高分断型 type C: High breaking type
无代号：手柄直接操作
no code represents direct handle operation
P:电动操作 P: represents motor operation
Z:转动手柄 Z: represents rotary handle operation
2、3、4
0：无脱扣器 0: represents frame only without trip unit
2：仅有瞬时脱扣器 2: represents magnetic only
3：复式脱扣器 3: represents both thermal and matnetic
参见表 1 see table 1
无代号:配电型 no code represents Power distribution
2：电动机保护型 2: represents motor protection
A：N 极不安装过电流脱扣器，且 N 极始终接通
A：N-pole is always close without overload release
B：N 极不安装过电流脱扣器，且 N 极与其它三极一起合分
B：N-pole is open or close together with other three poles and
without overload release
C：N 极安装过电流脱扣器，且 N 极与其它三极一起合分
C：N-pole is open or close together with other three poles and
with overload release
参见表 2 see table 2
无代号：常规产品
No code:Normal product
P：联接排
P:Extended busbar
JK：仅进线端：接线框式
JK：Wire-in end only：wiring frame type
CK：仅出线端：接线框式
CK：Outlet end only：wiring frame type
K：接线框式
K：wiring frame type
Z1：板后接线
Z1:Rear-plate connection
Z2H：插入式板后接线
Z2H: plug-in rear-plate connection
Z2Q：插入式板前接线
Z2Q: plug-in front -plate connection
Z3H：插入式板后接线一体式
Z3H: Integrated plug-in rear-plate connection
Z3Q：插入式板前接线一体式
Z3Q: Integrated plug-in front -plate connection
